Model Whirlpool GI15NDXTB4 ICE CUBE MAKER – Common Parts &amp; Diagrams

1

Box, Control WPL 2185738 Contact Us For Availability

2

WP2310139 Whirlpool Refrigerator Transformer Backorder WPL WP2310139 $218.99

3

2185677 Whirlpool Refrigerator Pump Cover Backorder WPL 2185677 $61.51

3

WP2188935 Whirlpool Refrigerator Fan Blade In Stock WPL WP2188935 $56.99

3

ASSEMBLY, SWITCH (ALSO ORDER No.4) WPL 2304121 Contact Us For Availability

4

2185678 Whirlpool Refrigerator Spacer Backorder WPL 2185678 $6.97

4

W10863947 Whirlpool Refrigerator Tube In Stock WPL W10863947 $49.99

4

OVERLAY WPL W10206461 Contact Us For Availability

5

W11204894 Whirlpool Refrigerator Bracket Backorder WPL W11204894 $45.11

5

WPW10218037 Whirlpool Refrigerator Evaporator In Stock WPL WPW10218037 $468.58

5

WPW10226156-includeCORE Whirlpool WPW10226156 Backorder WPL WPW10226156-includeCORE $332.69

6

W11566407 Whirlpool Pump In Stock WPL W11566407 $86.74

6

WP2149705 Whirlpool Refrigerator Door Switch In Stock WPL WP2149705 $27.81

6

WP489442 Whirlpool Refrigerator Screw Backorder WPL WP489442 $6.83

7

Wire Assy-Active Overlay Jumper WPL 2187585 Contact Us For Availability

7

TUBE, RESERVOIR PUMP WPL 2313851 Contact Us For Availability

8

A201435 Whirlpool Refrigerator Clip Backorder WPL A201435 $5.85

8

WP2310092 Whirlpool Refrigerator Pump Harness In Stock WPL WP2310092 $105.99

9

A201441 Whirlpool Refrigerator Shim Backorder WPL A201441 $5.85

9

Pump Assembly WPL 2313702 Contact Us For Availability

9

Bulb WPL 745362 Contact Us For Availability

10

WP2151652 Whirlpool Refrigerator Button Plug In Stock WPL WP2151652 $14.52

11

W10136999 Whirlpool Refrigerator Nut Backorder WPL W10136999 $5.85

12

WPW10503764 Whirlpool Refrigerator Thermistor In Stock WPL WPW10503764 $84.86

13

2185825 Whirlpool Refrigerator Clamp Backorder WPL 2185825 $55.55

13

2217367 Whirlpool Refrigerator Door Gasket Backorder WPL 2217367 $59.85

13

WP2185625 Whirlpool Refrigerator Water Pan Backorder WPL WP2185625 $117.74

14

WP2185626 Whirlpool Refrigerator Hose Backorder WPL WP2185626 $71.89

14

WP489503 Whirlpool Refrigerator Clamp Backorder WPL WP489503 $7.20

15

WP2217294 Whirlpool Refrigerator Door Gasket Backorder WPL WP2217294 $172.67

15

WP2313890 Whirlpool Overflow Hose Backorder WPL WP2313890 $50.03

15

WPW10206473 Whirlpool Refrigerator Coil Solen Backorder WPL WPW10206473 $130.99

16

2185640 Whirlpool Refrigerator Sleeve Backorder WPL 2185640 $31.24

16

2313604 Whirlpool Refrigerator Guide Backorder WPL 2313604 $34.38

17

WP2187629 Whirlpool Refrigerator Wire Jumper Backorder WPL WP2187629 $90.20

17

BRACKET, FRONT WPL 2313603 Contact Us For Availability

17

REAR WPL W10136175 Contact Us For Availability

18

8201791 Whirlpool Air Conditioner Spacer Backorder WPL 8201791 $17.09

18

WP489443 Whirlpool Refrigerator Screw Backorder WPL WP489443 $4.82

18

WPW10136197 Whirlpool Refrigerator Start Devi In Stock WPL WPW10136197 $124.99

19

2185681 Whirlpool Refrigerator Harness Backorder WPL 2185681 $89.54

WP2208493B Whirlpool Refrigerator Handle In Stock WPL WP2208493B $122.68

WP2208493W Whirlpool Refrigerator Handle Backorder WPL WP2208493W $97.76

WP2313635 Whirlpool Refrigerator Thermistor In Stock WPL WP2313635 $73.99

WP759113 Whirlpool Refrigerator Gas Valve Backorder WPL WP759113 $225.71

WPW10217922 Whirlpool Tube In Stock WPL WPW10217922 $96.99

21

WP2310169 Whirlpool Refrigerator Harness Backorder WPL WP2310169 $88.98

21

Plate WPL 2301979 Contact Us For Availability

24

WP2313624 Whirlpool Refrigerator Condenser In Stock WPL WP2313624 $222.46

25

W10532250 Whirlpool Refrigerator Foam Pad Backorder WPL W10532250 $6.96

26

2185691 Whirlpool Refrigerator Channel Backorder WPL 2185691 $10.19

26

W10852725 Whirlpool Refrigerator Grommet In Stock WPL W10852725 $5.99

26

WP3400886 Whirlpool Refrigerator Screw Backorder WPL WP3400886 $4.82

27

Badge (Whpl.Gold) WPL W10175320 Contact Us For Availability

28

WP2185989 Whirlpool Refrigerator Tube Backorder WPL WP2185989 $73.93

28

WP2313637 Whirlpool Cutting Grid Assembly In Stock WPL WP2313637 $235.99

29

4387020 Whirlpool Refrigerator Grid In Stock WPL 4387020 $40.99

29

8281197 Whirlpool Refrigerator Screw Backorder WPL 8281197 $5.51

30

2185570 Whirlpool Refrigerator Panel Backorder WPL 2185570 $68.79

31

WP8281196 Whirlpool Screw In Stock WPL WP8281196 $5.99

31

Thumbscrew WPL 8281228 Contact Us For Availability

32

WP2324334 Whirlpool Refrigerator Water Pan In Stock WPL WP2324334 $108.66

33

WP3400884 Whirlpool Refrigerator Screw Backorder WPL WP3400884 $4.82

34

2185712 Whirlpool Refrigerator Hinge Pin Backorder WPL 2185712 $33.58

34

WP2185696 Whirlpool Cap In Stock WPL WP2185696 $19.99

35

WP3400909 Whirlpool Refrigerator Nut In Stock WPL WP3400909 $4.82

40

2185927 Whirlpool Refrigerator Holder Backorder WPL 2185927 $57.91

46

W11624957 Whirlpool Refrigerator Top Gasket Backorder WPL W11624957 $85.13

47

WP2185571B Whirlpool Refrigerator Grille Backorder WPL WP2185571B $154.78

48

WP489474 Whirlpool Refrigerator Screw Backorder WPL WP489474 $4.92

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $31.99

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $79.99

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $82.11

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $86.15

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $75.04

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $111.80

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $66.99

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability
