Model Electrolux FSC23F7HSB7 REFRIGERATOR – Common Parts &amp; Diagrams

1

241510204 Frigidaire Refrigerator Door Gasket Backorder WCI 241510204 $226.29

2

241510203 Frigidaire Refrigerator Gasket Door In Stock WCI 241510203 $173.08

2

241684701 Frigidaire Refrigerator Ice Auger Backorder WCI 241684701 $166.61

3

241685201 Frigidaire Refrigerator Drive Cam In Stock WCI 241685201 $32.71

4

241515202 Frigidaire Refrigerator Container Backorder WCI 241515202 $74.85

4

WCI 241678703 No Longer Available

4B

241511602 Frigidaire Refrigerator Door Bin In Stock WCI 241511602 $52.68

5

5308000010 Frigidaire Refrigerator Evaporator In Stock WCI 5308000010 $44.94

5

WCI 241516102 WCI 241516102 Contact Us For Availability

6

241515901 Frigidaire Refrigerator Dairy Compa Backorder WCI 241515901 $31.04

6

241516904 Frigidaire Refrigerator Service Cor In Stock WCI 241516904 $28.28

6

241685101 Frigidaire Refrigerator Ice Dispens In Stock WCI 241685101 $40.48

7

241515301 Frigidaire Refrigerator Cover Backorder WCI 241515301 $93.71

7

241515606 Frigidaire Refrigerator Door-Dairy In Stock WCI 241515606 $32.73

7

WCI 5304458382 WCI 5304458382 Contact Us For Availability

8

215474201 Frigidaire Refrigerator Washer Backorder WCI 215474201 $16.59

8

WCI 241680503 WCI 241680503 Contact Us For Availability

9

241518301 Frigidaire Refrigerator Bushing In Stock WCI 241518301 $46.05

10

241688901 Frigidaire Refrigerator Torsion Spr Backorder WCI 241688901 $16.62

10

241726501 Frigidaire Refrigerator Drive Bar In Stock WCI 241726501 $46.00

10A

241719711 Frigidaire Refrigerator Evaporator Backorder WCI 241719711 $85.40

11

5303208309 Frigidaire Refrigerator Plug Hole Backorder WCI 5303208309 $33.28

11

5304458400 Frigidaire Refrigerator Thermal Cu Backorder WCI 5304458400 $48.27

11

WCI 241668503 WCI 241668503 Contact Us For Availability

11A

240443358 Frigidaire Refrigerator Shelf Backorder WCI 240443358 $71.00

13

240581905 Frigidaire Refrigerator Door Stop In Stock WCI 240581905 $44.87

13

5304456665 Frigidaire Refrigerator Thermostat In Stock WCI 5304456665 $98.14

13

809069220 Frigidaire Evaporator Fan Motor In Stock WCI 809069220 $100.27

13A

240581906 Frigidaire Refrigerator Door Stop In Stock WCI 240581906 $50.47

14

WCI 240323957 WCI 240323957 Contact Us For Availability

14A

241547902 Frigidaire Refrigerator Light Switc In Stock WCI 241547902 $19.49

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $14.94

5303918284 Frigidaire Refrigerator Evaporator In Stock WCI 5303918284 $436.59

5304456667 Frigidaire Refrigerator Micro Swit Backorder WCI 5304456667 $67.67

WCI 241534533 WCI 241534533 Contact Us For Availability

16

241559801 Frigidaire Light Socket Refrigerato In Stock WCI 241559801 $50.24

16

5308000110 Frigidaire Refrigerator Evaporator In Stock WCI 5308000110 $48.81

16A

241622802 Frigidaire Refrigerator Light Socke Backorder WCI 241622802 $46.57

17

241679801 Frigidaire Screw Backorder WCI 241679801 $11.09

17

241684503 Frigidaire Ice Crusher Blade In Stock WCI 241684503 $12.72

18

WCI 240536818 WCI 240536818 Contact Us For Availability

19

WCI 5304458378 WCI 5304458378 Contact Us For Availability

20

241675502 Frigidaire Refrigerator Motor Cover Backorder WCI 241675502 $107.06

21

5303918214 Frigidaire Refrigerator Defrost Th In Stock WCI 5303918214 $20.06

21

5304458390 Frigidaire Refrigerator Ice Stripp Backorder WCI 5304458390 $42.02

21A

240598402 Frigidaire Refrigerator Screw Backorder WCI 240598402 $2.76

240328203 Frigidaire Refrigerator Door Hinge In Stock WCI 240328203 $16.62

240457701 Frigidaire Refrigerator Freezer Doo In Stock WCI 240457701 $44.35

240597220 Frigidaire Sensor In Stock WCI 240597220 $3.67

WCI 5304458375 WCI 5304458375 Contact Us For Availability

22C

240328404 Frigidaire Refrigerator Upper Door In Stock WCI 240328404 $16.64

218513300 Frigidaire Refrigerator Compressor Backorder WCI 218513300 $33.26

241512901 Frigidaire Refrigerator Sensor Cove Backorder WCI 241512901 $65.45

241649003 Frigidaire Refrigerator Drip Tray In Stock WCI 241649003 $48.25

241684001 Frigidaire Refrigerator Front Plate Backorder WCI 241684001 $117.03

WCI 240402702 WCI 240402702 Contact Us For Availability

24

241685703 Frigidaire Refrigerator Lighted Wat In Stock WCI 241685703 $124.59

24A

241682303 Frigidaire Refrigerator Actuator Backorder WCI 241682303 $154.35

25

240555002 Frigidaire Refrigerator Screw #8-32 Backorder WCI 240555002 $10.50

25

240599301 Frigidaire Refrigerator Crisper Dra In Stock WCI 240599301 $76.55

25

WCI 240491503 WCI 240491503 Contact Us For Availability

26

240351061 Frigidaire Refrigerator Crisper Pan In Stock WCI 240351061 $83.99

26

241690602 Frigidaire Refrigerator Screw In Stock WCI 241690602 $7.35

26

241697502 Frigidaire Defrost Drain Pan Backorder WCI 241697502 $123.03

26A

240362201 Frigidaire Refrigerator Humidity Co Backorder WCI 240362201 $54.34

27

240351240 Frigidaire Refrigerator Crisper Pan In Stock WCI 240351240 $151.58

30

241688401 Frigidaire Ice Door Bracket In Stock WCI 241688401 $38.83

30

241707709 Frigidaire Refrigerator Starter Backorder WCI 241707709 $58.80

30A

241688501 Frigidaire Refrigerator Door Center In Stock WCI 241688501 $39.37

30B

241688601 Frigidaire Refrigerator Door Insula In Stock WCI 241688601 $43.75

30C

241688701 Frigidaire Refrigerator Door Seal In Stock WCI 241688701 $29.95

33

241684802 Frigidaire Refrigerator Spacer Backorder WCI 241684802 $6.61

34

240405201 Frigidaire Refrigerator Grommet In Stock WCI 240405201 $13.71

34

241689802 Frigidaire Refrigerator Spacer Backorder WCI 241689802 $6.09

35

241689301 Frigidaire Refrigerator Rotary Damp Backorder WCI 241689301 $51.55

35A

241684303 Frigidaire Refrigerator Fixed Blade Backorder WCI 241684303 $12.72

35B

241684203 Frigidaire Refrigerator Fixed Blade Backorder WCI 241684203 $13.29

36

WCI 241680301 WCI 241680301 Contact Us For Availability

37

242161202 Frigidaire Refrigerator Trim-Cabine In Stock WCI 242161202 $6.09

37A

241684107 Frigidaire Refrigerator Ice Crusher Backorder WCI 241684107 $16.07

37B

241684108 Frigidaire Washer Poly V-Belt Backorder WCI 241684108 $16.07

37C

241684109 Frigidaire Ice Crusher Blade Backorder WCI 241684109 $16.07

38

240327207 Frigidaire Refrigerator Upper Hinge Backorder WCI 240327207 $44.92

38

WCI 241708102 WCI 241708102 Contact Us For Availability

38A

241689106 Frigidaire Refrigerator Micro Switc In Stock WCI 241689106 $6.09

38C

241708306 Frigidaire Refrigerator Control Boa Backorder WCI 241708306 $379.15

39

240367603 Frigidaire Refrigerator Shelf Trim Backorder WCI 240367603 $58.25

39

241688801 Frigidaire Refrigerator Hinge Pin Backorder WCI 241688801 $33.82

40

WCI 5304458401 WCI 5304458401 Contact Us For Availability

41

241550801 Frigidaire Refrigerator Shelf Mount Backorder WCI 241550801 $46.57

41

241689001 Frigidaire Refrigerator Actuator Sp In Stock WCI 241689001 $17.18

41

WCI 241637601 WCI 241637601 Contact Us For Availability

42

240578902 Frigidaire Screw Mounting Hinge Backorder WCI 240578902 $11.07

43

241720601 Frigidaire Refrigerator Extension In Stock WCI 241720601 $16.05

43

5304499445 Frigidaire Refrigerator Roller Ass Backorder WCI 5304499445 $18.27

45

241500303 Frigidaire Refrigerator Screw Backorder WCI 241500303 $2.96

45B

241676001 Frigidaire Refrigerator E-Ring Sole Backorder WCI 241676001 $54.88

45C

241676101 Frigidaire Refrigerator Solenoid-Ac Backorder WCI 241676101 $50.46

46

WCI 241684402 WCI 241684402 Contact Us For Availability

47

241513001 Frigidaire Refrigerator Shelf Mount In Stock WCI 241513001 $62.86

47

241731801 Frigidaire Refrigerator Control Rod Backorder WCI 241731801 $11.09

47A

240350603 Frigidaire Glass Shelf Backorder WCI 240350603 $90.42

48

241511701 Frigidaire Refrigerator Door Bin In Stock WCI 241511701 $52.35

48

241684602 Frigidaire Refrigerator Control Rod Backorder WCI 241684602 $83.77

49

241505301 Frigidaire Refrigerator Shelf Bin-D In Stock WCI 241505301 $59.88

49

241515001 Frigidaire Refrigerator Basket Slid Backorder WCI 241515001 $147.52

49

WCI 241676501 WCI 241676501 Contact Us For Availability

49A

241505501 Frigidaire Refrigerator Door Bin In Stock WCI 241505501 $77.66

49B

WCI 241514901 WCI 241514901 Contact Us For Availability

50

WCI 241511101 No Longer Available

50

241675601 Frigidaire Refrigerator Solenoid Gu Backorder WCI 241675601 $62.67

50

WCI 241508401 WCI 241508401 Contact Us For Availability

51

241514501 Frigidaire Refrigerator Basket Hang Backorder WCI 241514501 $57.69

51

WCI 241676301 WCI 241676301 Contact Us For Availability

51A

241514701 Frigidaire Refrigerator Glass Shelf Backorder WCI 241514701 $49.90

52

241514601 Frigidaire Refrigerator Basket Hang Backorder WCI 241514601 $59.88

52

241684901 Frigidaire Refrigerator Fixed Blade Backorder WCI 241684901 $22.19

52A

241514801 Frigidaire Refrigerator Glass Shelf Backorder WCI 241514801 $318.41

53

241690402 Frigidaire Refrigerator Spiral Pin Backorder WCI 241690402 $14.94

54

241532401 Frigidaire Refrigerator Channel In Stock WCI 241532401 $18.24

54

241685001 Frigidaire Auger Nut Backorder WCI 241685001 $15.51

55

241690306 Frigidaire Refrigerator Washer Backorder WCI 241690306 $38.83

56

241689201 Frigidaire Refrigerator Micro Switc Backorder WCI 241689201 $10.50

56

241690201 Frigidaire Refrigerator E-Ring Backorder WCI 241690201 $14.97

58

218781101 Frigidaire Handle Screw In Stock WCI 218781101 $10.79

60

WCI 241510301 WCI 241510301 Contact Us For Availability

61

241639502 Frigidaire Refrigerator Condenser F In Stock WCI 241639502 $16.05

64

5304455846 Frigidaire Refrigerator Clamp In Stock WCI 5304455846 $8.31

68

241525101 Frigidaire Refrigerator Ice Chute Backorder WCI 241525101 $60.13

70

241515801 Frigidaire Refrigerator Compartment Backorder WCI 241515801 $139.21

70

WCI 241504601 WCI 241504601 Contact Us For Availability

79

218755402 Frigidaire Refrigerator Set Screw In Stock WCI 218755402 $4.86

80

218755504 Frigidaire Refrigerator Shoulder Sc In Stock WCI 218755504 $10.50

81

5304455650 Frigidaire Refrigerator Screw Backorder WCI 5304455650 $11.09

82

5304418225 Frigidaire Refrigerator Roller P-1 In Stock WCI 5304418225 $35.90

82

5304453707 Frigidaire Oven Screw In Stock WCI 5304453707 $11.64

83

5304455655 Frigidaire Refrigerator Rivet Backorder WCI 5304455655 $28.21

86

240409302 Frigidaire Refrigerator Condenser T Backorder WCI 240409302 $49.36

87

241688302 Frigidaire Refrigerator Bearing Pla Backorder WCI 241688302 $15.51

87A

241688301 Frigidaire Refrigerator Bearing Pla Backorder WCI 241688301 $15.51

89

5304520905 Frigidaire Assembly Cover Refriger Backorder WCI 5304520905 $54.36

92

241710601 Frigidaire Refrigerator Screw In Stock WCI 241710601 $10.53

97

241532005 Frigidaire Refrigerator Water Tank Backorder WCI 241532005 $110.37

100

240326304 Frigidaire Refrigerator Cover Backorder WCI 240326304 $57.71

101

218493101 Frigidaire Refrigerator Screw In Stock WCI 218493101 $10.00

115

5303918899 Frigidaire Damper Control Assembly In Stock WCI 5303918899 $58.18

116

241518601 Frigidaire Refrigerator Damper Seal In Stock WCI 241518601 $7.20

120

241691701 Frigidaire Refrigerator Ice Cream S Backorder WCI 241691701 $58.86

121

241504701 Frigidaire Refrigerator Ice Cream S Backorder WCI 241504701 $50.49

122

WCI 241504702 WCI 241504702 Contact Us For Availability

126

241674401 Frigidaire Refrigerator Channel Backorder WCI 241674401 $37.17

126A

241674402 Frigidaire Refrigerator Channel Backorder WCI 241674402 $33.82

136

241657702 Frigidaire Refrigerator Rack Backorder WCI 241657702 $58.41

138

WCI 240397301 WCI 240397301 Contact Us For Availability

139

240396002 Frigidaire Refrigerator Primary Bas In Stock WCI 240396002 $99.76

149

242204504 Frigidaire Shroud Assembly Backorder WCI 242204504 $28.28

198

240397401 Frigidaire Refrigerator Retainer As Backorder WCI 240397401 $46.57

199

240398401 Frigidaire Refrigerator Filter Rele Backorder WCI 240398401 $43.24

199

WCI 240397501 WCI 240397501 Contact Us For Availability

201

WCI 241504102 WCI 241504102 Contact Us For Availability

218252201 Frigidaire Refrigerator Screw Backorder WCI 218252201 $11.07

218515403 Frigidaire Refrigerator Grille Clip Backorder WCI 218515403 $22.73

218976418 Frigidaire Refrigerator Water Inlet Backorder WCI 218976418 $50.49

218976421 Frigidaire Refrigerator Water Inlet Backorder WCI 218976421 $16.05

240346701 Frigidaire Refrigerator Foam Seal T In Stock WCI 240346701 $23.27

240349801 Frigidaire Refrigerator Clip Backorder WCI 240349801 $14.99

240359403 Frigidaire Refrigerator Fan Shroud Backorder WCI 240359403 $2.76

240362101 Frigidaire Refrigerator Crisper Cov In Stock WCI 240362101 $34.37

240363602 Frigidaire Refrigerator Shoulder Sc Backorder WCI 240363602 $9.96

240542901 Frigidaire Water Valve Cap Backorder WCI 240542901 $12.28

240561701 Frigidaire Refrigerator Seal Backorder WCI 240561701 $16.07

241510802 Frigidaire Refrigerator Wiring Harn Backorder WCI 241510802 $32.71

241519401 Frigidaire Refrigerator Clip Backorder WCI 241519401 $6.61

241522901 Frigidaire Refrigerator Electrical Backorder WCI 241522901 $85.99

241550701 Frigidaire Refrigerator Shelf Mount In Stock WCI 241550701 $13.29

241583301 Frigidaire Refrigerator Air Deflect Backorder WCI 241583301 $36.59

241806601 Frigidaire Refrigerator Water Conne In Stock WCI 241806601 $50.28

241850615 Frigidaire Ice Maker Fill Tube Asse In Stock WCI 241850615 $27.17

241914702 Frigidaire Refrigerator Ice Contain In Stock WCI 241914702 $199.54

5303321321 Frigidaire Refrigerator Black Touc In Stock WCI 5303321321 $16.66

5303918256 Frigidaire Refrigerator Heater Kit In Stock WCI 5303918256 $461.95

5303918327 Frigidaire Refrigerator Heat Excha In Stock WCI 5303918327 $216.33

WCI 5303918222 WCI 5303918222 Contact Us For Availability

WCI 241519902 WCI 241519902 Contact Us For Availability

WCI 241686201 WCI 241686201 Contact Us For Availability
