Model Frigidaire FHE35BZEMW0 WASHER – Common Parts & Diagrams

3
Cover, splash tub, recirculating
Cover, splash tub, recirculating WCI 137351500 Contact Us For Availability
View on Model
3A
Shield, tub cover
Shield, tub cover WCI 137419200 No Longer Available
View on Model
4
Hinge Bar, rh, FSW
Hinge Bar, rh, FSW WCI 137454800 Contact Us For Availability
View on Model
4A
Hinge Bar, lh, FSW
Hinge Bar, lh, FSW WCI 137454900 Contact Us For Availability
View on Model
5
Grommet, hinge, FSW
Grommet, hinge, FSW WCI 137456300 Contact Us For Availability
View on Model
6
Hose, dispenser out
Hose, dispenser out WCI 137469800 Contact Us For Availability
View on Model
6
Panel, lid glass, white
Panel, lid glass, white WCI 137330210 Contact Us For Availability
View on Model
6
Harness, upper prog sel
Harness, upper prog sel WCI 137348800 Contact Us For Availability
View on Model
7
Cover, dispenser, soft
Cover, dispenser, soft WCI 137189048 Contact Us For Availability
View on Model
7A
Cup, dispenser, soft
Cup, dispenser, soft WCI 137176448 Contact Us For Availability
View on Model
8
Cover, bearing
Cover, bearing WCI 137363400 Contact Us For Availability
View on Model
9
Striker, lid, TLW
Striker, lid, TLW WCI 137512000 No Longer Available
View on Model
11
Wash Plate
Wash Plate WCI 137494000 Contact Us For Availability
View on Model
12
Tub, Spin, H+ w/o lint fil
Tub, Spin, H+ w/o lint fil WCI 137492800 Contact Us For Availability
View on Model
16
Trunnion, large
Trunnion, large WCI 137470000 Contact Us For Availability
View on Model
17
Console, shell J, white
Console, shell J, white WCI 137054110 Contact Us For Availability
View on Model
18
Tub, splash, air dome/bearng
Tub, splash, air dome/bearng WCI 137326201 Contact Us For Availability
View on Model
19
Tub Seal Kit
Tub Seal Kit WCI 137547700 Contact Us For Availability
View on Model
21
Grommet, seal
Grommet, seal WCI 137272000 Contact Us For Availability
View on Model
21
Bracket, hinge
Bracket, hinge WCI 137278500 Contact Us For Availability
View on Model
22
Leg, Dome & Brackets, assembly
Leg, Dome & Brackets, assembly WCI 137513900 No Longer Available
View on Model
23
Spring, vertical, black
Spring, vertical, black WCI 137497110 Contact Us For Availability
View on Model
24
Spring, horizontal
Spring, horizontal WCI 137532600 Contact Us For Availability
View on Model
24A
Base, motor control
Base, motor control WCI 137469200 Contact Us For Availability
View on Model
25
Retainer, spring
Retainer, spring WCI 137507100 Contact Us For Availability
View on Model
27
Retainer, insert, spring
Retainer, insert, spring WCI 137491600 Contact Us For Availability
View on Model
35
Snubber Ring
Snubber Ring WCI 5308002385 Contact Us For Availability
View on Model
38
Base, 27, FSW, washed
Base, 27, FSW, washed WCI 137493201 Contact Us For Availability
View on Model
40#
Motor, intl washer
Motor, intl washer WCI 137326001 Contact Us For Availability
View on Model
42
Panel, front, FSW, white
Panel, front, FSW, white WCI 137363110 Contact Us For Availability
View on Model
42
Hose, recir pump inlt
Hose, recir pump inlt WCI 137364100 Contact Us For Availability
View on Model
45*
Cushion, drain hose, base
Cushion, drain hose, base WCI 131663500 Contact Us For Availability
View on Model
50
Lock, Lid, external switch
Lock, Lid, external switch WCI 137368600 Contact Us For Availability
View on Model
52
Hinge Stop, w/Lub, FSW
Hinge Stop, w/Lub, FSW WCI 137532911 Contact Us For Availability
View on Model
52A
Hinge Stop, w/Lub, FSW
Hinge Stop, w/Lub, FSW WCI 137532901 Contact Us For Availability
View on Model
54
Bexel, dispenser-bl/sf
Bexel, dispenser-bl/sf WCI 137271648 Contact Us For Availability
View on Model
55
Spring, lid assist
Spring, lid assist WCI 137534000 No Longer Available
View on Model
67
Cap, wash plate
Cap, wash plate WCI 137193200 Contact Us For Availability
View on Model
