Model Electrolux FGEF3036TDD RANGE/OVEN, ELECTRIC, FREESTANDING, 30 INCH – Common Parts &amp; Diagrams

2

5304527989 Frigidaire Liner Backorder WCI 5304527989 $21.06

3

5303935377 Frigidaire Door Trim Kit In Stock WCI 5303935377 $45.46

4

316350403 Frigidaire Range Glass Backorder WCI 316350403 $138.06

4

5304516891 Frigidaire Range Panel Backorder WCI 5304516891 $115.40

4A

316355602 Frigidaire Glass In Stock WCI 316355602 $145.47

5

316272900 Frigidaire Oven Leg Levelling Plast In Stock WCI 316272900 $10.53

5A

5304509869 Frigidaire Oven Leveling Leg Assem In Stock WCI 5304509869 $12.28

6

316406328 Frigidaire Shield Backorder WCI 316406328 $63.75

6

316496201 Frigidaire Oven Rack In Stock WCI 316496201 $73.67

7

316405600 Frigidaire Insulation Backorder WCI 316405600 $59.91

7

316407402 Frigidaire Range Drawer Glide In Stock WCI 316407402 $14.94

8

PANEL, OVEN BOTTOM WCI 316400601 No Longer Available

8

5304503232 Frigidaire Oven Inner Door Glass In Stock WCI 5304503232 $82.90

8

807047202 Frigidaire Range Glide Assembly Backorder WCI 807047202 $9.42

8A

BASE, BAKE ELEMENT WCI 316411106 Contact Us For Availability

9

LINER, OVEN DOOR WCI 316423707 No Longer Available

9

PAN, BROILEROPTIONAL ACCESS0RY WCI 316081900 Contact Us For Availability

10

5304507924 Frigidaire Oven Screw In Stock WCI 5304507924 $5.55

10

INSERT, BROILER PANOPTIONAL ACCESS0RY WCI 316082000 Contact Us For Availability

12

316405000 Frigidaire Oven Seal In Stock WCI 316405000 $109.08

12

316445500 Frigidaire Oven Switch Backorder WCI 316445500 $47.16

13A

5304508926 Frigidaire Oven Temperature Contro In Stock WCI 5304508926 $58.48

14

316022500 Frigidaire Oven Warmer Drawer Zone In Stock WCI 316022500 $42.23

14

316116400 Frigidaire Oven Light Socket In Stock WCI 316116400 $49.48

15

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $22.72

15

318178110 Frigidaire Oven Range 6" Surface El In Stock WCI 318178110 $64.96

15

5304493644 Frigidaire Range Cap Backorder WCI 5304493644 $48.81

15A

316530001 Frigidaire Oven Element In Stock WCI 316530001 $184.91

15A

5304493646 Frigidaire Range Cap In Stock WCI 5304493646 $48.81

15B

316282103 Frigidaire Range Element In Stock WCI 316282103 $200.47

15C

140273621015 Frigidaire Warmer Element, Radia Backorder WCI 140273621015 $27.98

16

316552801 Frigidaire Range Glass Backorder WCI 316552801 $27.71

16

5304513242 Frigidaire Oven Smooth Top Glass R Backorder WCI 5304513242 $449.77

16

5304524341 Frigidaire Lens In Stock WCI 5304524341 $20.29

17

316087500 Frigidaire Oven Retainer Backorder WCI 316087500 $44.37

17

5304504811 Frigidaire Glass Spacer In Stock WCI 5304504811 $18.29

18

316405800 Frigidaire Assembly Latch Backorder WCI 316405800 $47.16

18

316580800 Frigidaire Hinge Bracket Backorder WCI 316580800 $7.20

19

PANEL, BACKGUARD, BLACK STAINLESS WCI 5304509317 Contact Us For Availability

20

5304511270 Frigidaire Range Clock In Stock WCI 5304511270 $271.28

20

SPACER, DOOR, RH WCI 316353002 Contact Us For Availability

20A

316419378 Frigidaire Range Overlay Backorder WCI 316419378 $17.73

20A

SPACER, DOOR, LH WCI 316353003 Contact Us For Availability

21

316408000 Frigidaire Oven Clip Assembly Backorder WCI 316408000 $13.29

21

316533801 Frigidaire Oven Plate Backorder WCI 316533801 $5.05

22

316286300 Frigidaire Bodyside Bracket Backorder WCI 316286300 $13.86

23

316575948 Frigidaire Range Hinge Backorder WCI 316575948 $27.19

25

316406200 Frigidaire Oven Shield Assembly Backorder WCI 316406200 $64.34

26A

316498200 Frigidaire Oven Bracket Backorder WCI 316498200 $38.24

28

316528700 Frigidaire Insulation Assembly Backorder WCI 316528700 $69.87

29

807047102 Frigidaire Oven Front Drawer Glide In Stock WCI 807047102 $17.45

37

316490000 Frigidaire Oven Range Temperature S In Stock WCI 316490000 $49.04

39

316554009 Frigidaire Oven Handle Backorder WCI 316554009 $145.33

40

316552401 Frigidaire Range Bracket Backorder WCI 316552401 $21.08

43

316282700 Frigidaire Oven Screw Backorder WCI 316282700 $7.74

44

316517600 Frigidaire Oven Spacer Backorder WCI 316517600 $9.42

46

316557300 Frigidaire Range Indicator Light Le In Stock WCI 316557300 $16.08

51

316355300 Frigidaire Insulation Backorder WCI 316355300 $5.55

52

316461700 Frigidaire Oven Clip Assembly In Stock WCI 316461700 $9.37

52

5304520272 Frigidaire Top Cap Backorder WCI 5304520272 $134.21

54

316436000 Frigidaire Range Surface Element Sw In Stock WCI 316436000 $57.52

54A

316530101 Frigidaire Range Switch Assembly Backorder WCI 316530101 $110.98

54B

316238201 Frigidaire Range Switch In Stock WCI 316238201 $66.97

56

316234045 Frigidaire Oven Shield Backorder WCI 316234045 $48.79

57

316283600 Frigidaire Range Cover In Stock WCI 316283600 $8.87

58

316403802 Frigidaire Insulation Backorder WCI 316403802 $86.51

58A

316406602 Frigidaire Insulation Backorder WCI 316406602 $94.86

58B

316406500 Frigidaire Insulation Backorder WCI 316406500 $69.35

59

316208401 Frigidaire Range VentTube Backorder WCI 316208401 $141.98

59A

316208304 Frigidaire Oven Tube Backorder WCI 316208304 $62.67

62

5303935271 Frigidaire Oven Terminal Block In Stock WCI 5303935271 $46.97

63

5304536404 Frigidaire Strap Backorder WCI 5304536404 $1.58

66

316203301 Frigidaire Oven Broil Element In Stock WCI 316203301 $144.73

67

316413800 Frigidaire Oven Range Bake Element In Stock WCI 316413800 $191.95

68

316404002 Frigidaire Support Assembly Backorder WCI 316404002 $6.38

71

316283204 Frigidaire Range Shield Backorder WCI 316283204 $41.02

86

316441300 Frigidaire Receptacle In Stock WCI 316441300 $17.18

87

316081200 Frigidaire Oven Bracket Backorder WCI 316081200 $59.36

88

316203500 Frigidaire Oven Rod Backorder WCI 316203500 $56.58

89

5304528973 Frigidaire Motor In Stock WCI 5304528973 $48.09

106

316404100 Frigidaire Oven Bracket Backorder WCI 316404100 $46.59

107

316026701 Frigidaire Oven Cover Assembly Backorder WCI 316026701 $290.34

108

316256100 Frigidaire Range Fan Motor In Stock WCI 316256100 $163.76

109

318398302 Frigidaire Stove Oven Range Convect In Stock WCI 318398302 $32.21

111

316136600 Frigidaire Oven Range Lock Nut Backorder WCI 316136600 $14.94

316021105 Frigidaire Oven Screw Backorder WCI 316021105 $8.85

316021109 Frigidaire Oven Screw In Stock WCI 316021109 $15.49

316089500 Frigidaire Oven Screw In Stock WCI 316089500 $10.53

316418901 Frigidaire Oven Screw Backorder WCI 316418901 $11.09

5303285179 Frigidaire Oven Door Screw Backorder WCI 5303285179 $10.53

5303289910 Frigidaire Oven Screw Backorder WCI 5303289910 $4.41

WCI 316580267 WCI 316580267 Contact Us For Availability

HARNESS, SURFACE UNITS WCI 5304511285 Contact Us For Availability

WCI 316089501 WCI 316089501 Contact Us For Availability

316001017 Frigidaire Screw Backorder WCI 316001017 $2.24

316247300 Frigidaire Oven Catalyst Backorder WCI 316247300 $77.61

316418900 Frigidaire Oven Screw Backorder WCI 316418900 $11.09

5308014215 Frigidaire Oven Screw In Stock WCI 5308014215 $1.65

NIB

316205500 Frigidaire Oven Nut In Stock WCI 316205500 $8.87

NIC

316542203 Frigidaire Insulator Backorder WCI 316542203 $6.09
