Model Electrolux FGEF3035RFG RANGE/OVEN, ELECTRIC, FREESTANDING, 30 INCH – Common Parts &amp; Diagrams

1

SHIELD, REAR WALL WCI 316557600 Contact Us For Availability

2

5304527989 Frigidaire Liner Backorder WCI 5304527989 $21.06

4

316452758 Frigidaire Range Outer Door Glass Backorder WCI 316452758 $141.69

4

5304511907 Frigidaire Range Panel Backorder WCI 5304511907 $51.80

5

316272900 Frigidaire Oven Leg Levelling Plast In Stock WCI 316272900 $10.53

5A

5304509869 Frigidaire Oven Leveling Leg Assem In Stock WCI 5304509869 $12.28

6

316406328 Frigidaire Shield Backorder WCI 316406328 $63.75

6

316496201 Frigidaire Oven Rack In Stock WCI 316496201 $73.67

7

316405600 Frigidaire Insulation Backorder WCI 316405600 $59.91

7

316407402 Frigidaire Range Drawer Glide In Stock WCI 316407402 $14.94

8

5304490938 Frigidaire Glide Assembly In Stock WCI 5304490938 $10.53

8

5304503232 Frigidaire Oven Inner Door Glass In Stock WCI 5304503232 $82.90

8

PANEL, OVEN BOTTOM WCI 316505601 Contact Us For Availability

8A

316505701 Frigidaire Range Base Backorder WCI 316505701 $178.79

8B

316506000 Frigidaire Range Bracket Backorder WCI 316506000 $3.33

9

LINER, OVEN DOOR WCI 316423707 No Longer Available

9

PAN, BROILEROPTIONAL ACCESS0RY WCI 316081900 Contact Us For Availability

10

SCREW, HANDLE MTG., 10-24 X 1.75", (2) WCI 316439500 Contact Us For Availability

10

INSERT, BROILER PANOPTIONAL ACCESS0RY WCI 316082000 Contact Us For Availability

12

316405000 Frigidaire Oven Seal In Stock WCI 316405000 $109.08

12

316445500 Frigidaire Oven Switch Backorder WCI 316445500 $47.16

13

WCI 5304513908 WCI 5304513908 Contact Us For Availability

13A

5304508926 Frigidaire Oven Temperature Contro In Stock WCI 5304508926 $58.48

14

316022500 Frigidaire Oven Warmer Drawer Zone In Stock WCI 316022500 $42.23

14

316116400 Frigidaire Oven Light Socket In Stock WCI 316116400 $49.48

15

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $22.72

15

318178110 Frigidaire Oven Range 6" Surface El In Stock WCI 318178110 $64.96

15A

5304533520 Frigidaire Element In Stock WCI 5304533520 $65.08

15B

316282101 Frigidaire Oven Element In Stock WCI 316282101 $190.96

15C

5304521951 Frigidaire Element Backorder WCI 5304521951 $5.75

16

316552801 Frigidaire Range Glass Backorder WCI 316552801 $27.71

16

5304524341 Frigidaire Lens In Stock WCI 5304524341 $20.29

17

316087500 Frigidaire Oven Retainer Backorder WCI 316087500 $44.37

17

5304504811 Frigidaire Glass Spacer In Stock WCI 5304504811 $18.29

18

316405800 Frigidaire Assembly Latch Backorder WCI 316405800 $47.16

18

316580800 Frigidaire Hinge Bracket Backorder WCI 316580800 $7.20

19

316572418 Frigidaire Range Panel In Stock WCI 316572418 $193.10

20

316284100 Frigidaire Range Spacer Assembly In Stock WCI 316284100 $20.82

20

5304510064 Frigidaire Range Control Board and In Stock WCI 5304510064 $278.67

20A

316419353 Frigidaire Oven Overlay In Stock WCI 316419353 $27.17

21

316408000 Frigidaire Oven Clip Assembly Backorder WCI 316408000 $13.29

21

316546605 Frigidaire Range Cap In Stock WCI 316546605 $52.34

22

316286300 Frigidaire Bodyside Bracket Backorder WCI 316286300 $13.86

23

316575948 Frigidaire Range Hinge Backorder WCI 316575948 $27.19

25

316406200 Frigidaire Oven Shield Assembly Backorder WCI 316406200 $64.34

26A

316498200 Frigidaire Oven Bracket Backorder WCI 316498200 $38.24

29

807047102 Frigidaire Oven Front Drawer Glide In Stock WCI 807047102 $17.45

31

KNOB, TOP VALVE, STAINLESS WCI 5304500283 Contact Us For Availability

37

316490000 Frigidaire Oven Range Temperature S In Stock WCI 316490000 $49.04

39

316554010 Frigidaire Stainless Steel Handle In Stock WCI 316554010 $129.25

40

316552401 Frigidaire Range Bracket Backorder WCI 316552401 $21.08

42

316400701 Frigidaire Range Shield Backorder WCI 316400701 $118.70

44

316517600 Frigidaire Oven Spacer Backorder WCI 316517600 $9.42

46

316557300 Frigidaire Range Indicator Light Le In Stock WCI 316557300 $16.08

52

316461700 Frigidaire Oven Clip Assembly In Stock WCI 316461700 $9.37

53

5304532042 Frigidaire Door Filler Shield Backorder WCI 5304532042 $18.84

54

316436000 Frigidaire Range Surface Element Sw In Stock WCI 316436000 $57.52

54B

316238201 Frigidaire Range Switch In Stock WCI 316238201 $66.97

55

316408300 Frigidaire Range Bracket Backorder WCI 316408300 $15.51

56

316234045 Frigidaire Oven Shield Backorder WCI 316234045 $48.79

57

316283600 Frigidaire Range Cover In Stock WCI 316283600 $8.87

58A

316406604 Frigidaire Insulation Backorder WCI 316406604 $51.01

59

316208401 Frigidaire Range VentTube Backorder WCI 316208401 $141.98

59A

316208304 Frigidaire Oven Tube Backorder WCI 316208304 $62.67

62

5303935271 Frigidaire Oven Terminal Block In Stock WCI 5303935271 $46.97

63

5304536404 Frigidaire Strap Backorder WCI 5304536404 $1.58

66

316203301 Frigidaire Oven Broil Element In Stock WCI 316203301 $144.73

67

316505500 Frigidaire Range Element In Stock WCI 316505500 $174.88

68

316404002 Frigidaire Support Assembly Backorder WCI 316404002 $6.38

71

316283204 Frigidaire Range Shield Backorder WCI 316283204 $41.02

86

316441300 Frigidaire Receptacle In Stock WCI 316441300 $17.18

87

316081200 Frigidaire Oven Bracket Backorder WCI 316081200 $59.36

88

316203500 Frigidaire Oven Rod Backorder WCI 316203500 $56.58

89

5304528973 Frigidaire Motor In Stock WCI 5304528973 $48.09

106

316404100 Frigidaire Oven Bracket Backorder WCI 316404100 $46.59

107

316026701 Frigidaire Oven Cover Assembly Backorder WCI 316026701 $290.34

108

316256100 Frigidaire Range Fan Motor In Stock WCI 316256100 $163.76

109

318398302 Frigidaire Stove Oven Range Convect In Stock WCI 318398302 $32.21

111

316136600 Frigidaire Oven Range Lock Nut Backorder WCI 316136600 $14.94

316021105 Frigidaire Oven Screw Backorder WCI 316021105 $8.85

316021109 Frigidaire Oven Screw In Stock WCI 316021109 $15.49

316089500 Frigidaire Oven Screw In Stock WCI 316089500 $10.53

316282700 Frigidaire Oven Screw Backorder WCI 316282700 $7.74

316418901 Frigidaire Oven Screw Backorder WCI 316418901 $11.09

316580280 Frigidaire Range Harness Backorder WCI 316580280 $138.10

5303285179 Frigidaire Oven Door Screw Backorder WCI 5303285179 $10.53

5303289910 Frigidaire Oven Screw Backorder WCI 5303289910 $4.41

WCI 316089501 WCI 316089501 Contact Us For Availability

316001017 Frigidaire Screw Backorder WCI 316001017 $2.24

316247300 Frigidaire Oven Catalyst Backorder WCI 316247300 $77.61

316418900 Frigidaire Oven Screw Backorder WCI 316418900 $11.09

316533801 Frigidaire Oven Plate Backorder WCI 316533801 $5.05

5308014215 Frigidaire Oven Screw In Stock WCI 5308014215 $1.65

NIB

316205500 Frigidaire Oven Nut In Stock WCI 316205500 $8.87

NIC

316542203 Frigidaire Insulator Backorder WCI 316542203 $6.09
