Model Whirlpool ART5400L ELECTRIC RANGE – Common Parts & Diagrams
07 - STORAGE DRAWER ASSY
02 - CAVITY ASSY
05 - OVEN ASSY
01 - BACKGUARD ASSY
06 - OVEN DOOR ASSY
03 - ELECTRICAL COMPONENTS
04 - MAIN TOP ASSY
Common parts from model Whirlpool ART5400L ELECTRIC RANGE
1
RUNNER STORAGE DWR-LH WPL 0314664 Contact Us For Availability
1
TUBE-VENT WPL 0315297 Contact Us For Availability
1
BRKT, MAINTOP (PAINTED) WPL Y0314891 Contact Us For Availability
1
COVER, METAL BACKGUARD WPL 0315107 Contact Us For Availability
1
END CAP, LT (BLK) WPL 309458B Contact Us For Availability
1
SOCKET, OVEN LIGHT WPL Y0088674 Contact Us For Availability
2
DRAWER, STORAGE (WHT) WPL 309622W Contact Us For Availability
2
COVER, CHIP WPL Y0315022 Contact Us For Availability
2
PANEL, SIDE (ALM) WPL 306081L Contact Us For Availability
2
SPACER, HANDLE (BLK) WPL 309882B Contact Us For Availability
2
BULB, LIGHT WPL Y0042175 Contact Us For Availability
2
LIMITER WPL 10061018 Contact Us For Availability
3
RUNNER STORAGE DWR-RH WPL Y0314665 Contact Us For Availability
3
OVEN SHELL, NSC ELEC WPL 315086CG Contact Us For Availability
3
BRACE, LEVELING LEG (RT) WPL 314885B Contact Us For Availability
3
LIGHT, INDICATOR (OVEN) WPL Y07606700 Contact Us For Availability
3
BUSHING, HANDLE (BLK) WPL 309461B Contact Us For Availability
3
CAGE, OVEN LIGHT WPL Y0315057 Contact Us For Availability
3
BRKT, ELEMENT WPL Y0315354 Contact Us For Availability
4
RIVET, POP WPL Y0076357 Contact Us For Availability
4
CAPILLARY HOLE COVER WPL Y0063351 Contact Us For Availability
4
TRACK, STORAGE DWR LH WPL Y0314662 Contact Us For Availability
4
THERMOSTAT, ELEC NSC WPL Y0315050 Contact Us For Availability
4
TRIM, UPPER DOOR WPL 309456B Contact Us For Availability
5
TRACK, STORAGE DWR RH WPL 0314663 Contact Us For Availability
5
CLOCK (BLACK) WPL Y07707900 Contact Us For Availability
5
SCREW, No.10-24X11/4 (TRS PH HD) WPL Y0309973 Contact Us For Availability
5
LIMITER WPL 10061017 Contact Us For Availability
6
LINER, DRAWER PANEL (WHT) WPL 309179W Contact Us For Availability
6
KIT, DOOR HINGE(LH-HS) WPL Y0314572 Contact Us For Availability
6
END CAP, UL RH WPL 315076B Contact Us For Availability
6
BACKER, DOOR (NSC ELEC) WPL 315393CG Contact Us For Availability
7
PANEL, DRAWER (ALM) WPL 309177L Contact Us For Availability
7
KIT, DOOR HINGE(RH-SS) WPL Y0314573 Contact Us For Availability
7
SWITCH, ROCKER WPL Y0063997 Contact Us For Availability
7
INSULATION,DOOR-SUB BACKER WPL 0062614 Contact Us For Availability
7
SPRING, ELEMENT WPL Y0306683 Contact Us For Availability
8
PAN, BROILER WPL Y0308138 Contact Us For Availability
8
SEE NOTE FRONT FRAME NSC ELECTRIC, CHARCOAL G WPL Y00000000 Contact Us For Availability
8
KNOB THERMOSTAT WPL Y07708500 Contact Us For Availability
8
GASKET, OVEN DR 82`` WPL Y0300432 Contact Us For Availability
8
SCREW, SHOULDER WPL 0306212 Contact Us For Availability
9
RETAINER, INSULATION (BOTTOM) WPL Y0309061 Contact Us For Availability
9
KNOB, INFINITE SWITCH WPL Y07708501 Contact Us For Availability
9
PAD, OV DR W/WINDOW WPL 314693CG Contact Us For Availability
10
INSULATION,WRAPPER WPL Y0315069 Contact Us For Availability
10
LEG,LEVELING xxx WPL 314187B Contact Us For Availability
10
END CAP, UL LH WPL 315075B Contact Us For Availability
10
WINDOW ASSY., EHT344 WPL 0302003 Contact Us For Availability
10
ELEMENT, RIBBON (1200 WATTS) WPL Y0314909 Contact Us For Availability
11
BRACKET, OVEN CAVITY WPL Y0058852 Contact Us For Availability
11
BRACE, LEVELING LEG (LT) WPL 314884B Contact Us For Availability
11
PANEL, BKGD-AMANA WPL 07708903 Contact Us For Availability
11
SCREW, No.8-18 X 3/8 P HEX WSH T WPL Y0309016 Contact Us For Availability
11
LIMITER WPL 10061016 Contact Us For Availability
12
CLIP, CAPILLARY WPL 01052001 Contact Us For Availability
12
RETAINER, INSULATION (SIDE) WPL 0304282 Contact Us For Availability
12
RIVET, POP WPL Y0302648 Contact Us For Availability
12
BRKT, HINGE STRAP MTG WPL Y0306150 Contact Us For Availability
13
INSUL, TOP/REAR WPL Y0315070 Contact Us For Availability
13
RETAINER, REAR INSUL. WPL 0309081 Contact Us For Availability
13
BUMPER, RUBBER WPL Y0309627 Contact Us For Availability
13
HINGE, STRAP WPL 0314373 Contact Us For Availability
14
PLATE, MAIN INLET WIRE WPL 0058311 Contact Us For Availability
14
SCREW No.8-18 X .375 (BL) WPL Y0303777 Contact Us For Availability
14
ASSY,MAINTOP/GLASS(ALMOND) WPL 315119L Contact Us For Availability
15
COVER, REAR WPL Y0307342 Contact Us For Availability
15
END CAP, RT (BLK) WPL 309457B Contact Us For Availability
16
ACCESS PLATE, REAR WPL Y0058435 Contact Us For Availability
16
GLASS, OV DR SM/W ELEC WPL 315043B Contact Us For Availability
17
CABLE, CLIP ESM WPL Y0091587 Contact Us For Availability
17
SUPPORT, GLASS (BLK) WPL 309460B Contact Us For Availability
18
HANDLE, OVEN DOOR (BLK) WPL 309624B Contact Us For Availability
NI
EXT., VENT WPL Y0315298 Contact Us For Availability
NI
SCREW CABINET TRIM WPL Y0041813 Contact Us For Availability
NI
BRACKET WPL Y0301028 Contact Us For Availability
NI
ANCHOR, PLASTIC WPL Y0301555 Contact Us For Availability
NI
SCREW No.8-18X.375 AB WPL 0041801 Contact Us For Availability
NI
WASHER HANDLE MOUNTING WPL 0041937 Contact Us For Availability
NI
INTERNAL LOCK WASHER No.6 WPL 0041948 Contact Us For Availability
NI
SUPPORT, BKGD (LH) WPL 0306589 Contact Us For Availability
NI
SUPPORT, BKGD (RH) WPL 0306590 Contact Us For Availability
NI
SCREW 6-32X3/16 SLO COOK SW WPL Y0041778 Contact Us For Availability
NI
RETAINER, DOOR GLASS WPL Y0052629 Contact Us For Availability
NI
HEX NUT No.10-32 NICKEL WPL 0306381 Contact Us For Availability
NI
SCREW, GROUNDING WPL Y0072270 Contact Us For Availability
NI
SCREW, No.8-32 X3/8 P TRS HD LP WPL Y0052031 Contact Us For Availability
NI
SCREW, No.8-18 X 7/8 PPH WPL Y0076035 Contact Us For Availability
NI
CLAMP, TUBE (1/2``) WPL Y0307456 Contact Us For Availability
× ![]()
