  • Electrolux 970254390 Parts List

Model Electrolux 970254390 UPRIGHT FREEZER – Common Parts & Diagrams

*
Insulation, 24", drain tube
Insulation, 24", drain tube WCI 297001704 Contact Us For Availability
View on Model
*
Sleeve, suction line
Sleeve, suction line WCI 216502500 Contact Us For Availability
View on Model
*
Screw, anchor, #8, white
Screw, anchor, #8, white WCI 297048000 Contact Us For Availability
View on Model
5
Harness-main
Harness-main WCI 297237600 Contact Us For Availability
View on Model
9
Breaker Kit w/corners, 28", top and bottom
Breaker Kit w/corners, 28", top and bottom WCI 297200200 Contact Us For Availability
View on Model
19
Gasket, evap cover
Gasket, evap cover WCI 216204900 Contact Us For Availability
View on Model
19
Insulator-evap, styrofoam, LH
Insulator-evap, styrofoam, LH WCI 297078801 Contact Us For Availability
View on Model
26
Ramp, door closer
Ramp, door closer WCI 216503300 Contact Us For Availability
View on Model
26
Gasket, secondary
Gasket, secondary WCI 216524301 Contact Us For Availability
View on Model
32
Valve, breather
Valve, breather WCI 5309950074 Contact Us For Availability
View on Model
32
Clamp, elec cont mtg, compressor
Clamp, elec cont mtg, compressor WCI 297051100 Contact Us For Availability
View on Model
34
Shield-light
Shield-light WCI 297184400 Contact Us For Availability
View on Model
34
Sleeve-compressor
Sleeve-compressor WCI 5306594529 Contact Us For Availability
View on Model
37A
Trim-handle, 1.34", gray
Trim-handle, 1.34", gray WCI 218771203 Contact Us For Availability
View on Model
59A
Stop-basket, (2)
Stop-basket, (2) WCI 216486500 Contact Us For Availability
View on Model
64
Plug-button, hole filler, door base
Plug-button, hole filler, door base WCI 216403700 Contact Us For Availability
View on Model
72
Grille/Kickplate, 28", white
Grille/Kickplate, 28", white WCI 297199000 Contact Us For Availability
View on Model
172
Button-handle mtg, dovetail
Button-handle mtg, dovetail WCI 218397000 No Longer Available
View on Model
