Model Electrolux 72-3981-00-06 RANGE – Common Parts &amp; Diagrams

*10351

SCREW-HANDLE WCI 5303281651 Contact Us For Availability

*10352

WCI 3131622 WCI 3131622 Contact Us For Availability

*10352

WCI 3205396 WCI 3205396 Contact Us For Availability

WCI 19100220009 WCI 19100220009 Contact Us For Availability

SHIELD-HEAT WCI 3131620 Contact Us For Availability

WCI 3200834 WCI 3200834 Contact Us For Availability

ANTI-TIP BRKT WCI 3934056 Contact Us For Availability

FSTNR-TEE NUT LEVELING LEG WCI 5303288460 Contact Us For Availability

WCI 3131621 WCI 3131621 Contact Us For Availability

WCI 5308010401 WCI 5308010401 Contact Us For Availability

WCI 316013300 WCI 316013300 Contact Us For Availability

STRIKE U/O DOOR ALIGN WCI 316012800 Contact Us For Availability

INSUL-WOOL WCI 3200498 Contact Us For Availability

BRKT-CONNEC MTG WCI 3200500 Contact Us For Availability

INSUL O/U UPPER WCI 3200509 Contact Us For Availability

INSUL WOOL WCI 3200511 Contact Us For Availability

RETAINER OVEN BURNR UPPER WCI 3200519 Contact Us For Availability

WCI 3204440 WCI 3204440 Contact Us For Availability

WCI 5303283669 WCI 5303283669 Contact Us For Availability

WCI 5303291042 WCI 5303291042 Contact Us For Availability

1

THERMOSTAT-OVEN UPR WCI 5303269995 Contact Us For Availability

1

SPACER, B/S (8) WCI 3014099 Contact Us For Availability

1

WCI 5303210379 WCI 5303210379 Contact Us For Availability

1

WCI 08011721 WCI 08011721 Contact Us For Availability

2

3051163 Frigidaire Oven Range Rear Broiler Dr In Stock WCI 3051163 $8.11

2

WCI 08011722 WCI 08011722 Contact Us For Availability

2

BAFFLE-OVN BURNER WCI 3131284 Contact Us For Availability

2

WCI 5308037896 WCI 5308037896 Contact Us For Availability

2

HINGE-DOOR ASSY WCI 3051166 Contact Us For Availability

3

5304534000 Frigidaire Cord Backorder WCI 5304534000 $24.38

3

BULB-FLUOR WCI 3131275 Contact Us For Availability

3

WCI 5303270076 WCI 5303270076 Contact Us For Availability

3

WCI 08067935 WCI 08067935 Contact Us For Availability

3

GLASS DOOR FRNT WCI 5303284806 Contact Us For Availability

4

5303208655 Frigidaire Reflector Assembly Backorder WCI 5303208655 $45.46

4

ROD-MAIN SUPPORT (2) WCI 316066900 Contact Us For Availability

4

WCI 3131290 WCI 3131290 Contact Us For Availability

4

SWITCH SELECTOR 5 POS WCI 5303212678 Contact Us For Availability

4

WCI 5303935001 WCI 5303935001 Contact Us For Availability

4

WCI 08011665 WCI 08011665 Contact Us For Availability

5

Backorder WCI 154079601 $0.34

5

5303284616 Frigidaire Range Bulb Clip Thermos In Stock WCI 5303284616 $7.92

5

HINGE-TOP LH WCI 08067746 Contact Us For Availability

5

WCI 5303208656 WCI 5303208656 Contact Us For Availability

5

WCI 5303211043 WCI 5303211043 Contact Us For Availability

6

BRKT-GLASS (2) WCI 5303209510 Contact Us For Availability

6

WCI 5303271044 WCI 5303271044 Contact Us For Availability

6

WIRE GLASS RETAINER WCI 3204585 Contact Us For Availability

6

WCI 5303284809 WCI 5303284809 Contact Us For Availability

6

WCI 5303290772 WCI 5303290772 Contact Us For Availability

6

GLASS-OVN LITE LENS WCI 08011668 Contact Us For Availability

7

5304524341 Frigidaire Lens In Stock WCI 5304524341 $20.29

7

WCI 5303209513 WCI 5303209513 Contact Us For Availability

7

WCI 5303271041 WCI 5303271041 Contact Us For Availability

7

FSTNR-CLOCK WCI 08011713 Contact Us For Availability

7

GUSSET-OVEN DOOR WCI 08011727 Contact Us For Availability

7

GSKT OVEN LIGHT WCI 3200506 Contact Us For Availability

8

CHANNEL-HNG WCI 316007002 Contact Us For Availability

8

WCI 5303271043 WCI 5303271043 Contact Us For Availability

8

WCI 5303284810 WCI 5303284810 Contact Us For Availability

8

CHANNEL U/O DOOR FRAME WCI 316013100 Contact Us For Availability

8

WCI 08011669 WCI 08011669 Contact Us For Availability

9

WCI 5303272852 WCI 5303272852 Contact Us For Availability

9

COVER HNG. CUTOUT (2) WCI 3131570 Contact Us For Availability

9

WCI 08011729 WCI 08011729 Contact Us For Availability

9

WCI 5303211084 WCI 5303211084 Contact Us For Availability

9

WCI 5303271042 WCI 5303271042 Contact Us For Availability

9

TRIM-FRAME CONTROL PANEL WCI 316013200 Contact Us For Availability

9

SEAL DOOR (4) WCI 5303934092 Contact Us For Availability

INSUL OVEN DOOR WCI 5303209514 Contact Us For Availability

BRACKET BURNER MTG WCI 3200277 Contact Us For Availability

SHIELD-HEAT UPPER WCI 5303270104 Contact Us For Availability

WCI 5303284804 WCI 5303284804 Contact Us For Availability

SPACER-U/O DOOR WCI 3051302 Contact Us For Availability

SCREW-HANDLE (2) WCI 5303212671 Contact Us For Availability

WCI 316066200 WCI 316066200 Contact Us For Availability

WCI 3131313 WCI 3131313 Contact Us For Availability

WCI 3131472 WCI 3131472 Contact Us For Availability

GLIDE-OVEN BTM WCI 3131616 Contact Us For Availability

11A

WCI 08067992 WCI 08067992 Contact Us For Availability

WCI 5303209512 WCI 5303209512 Contact Us For Availability

VALVE, TOP, 3 POS, (4) WCI 316020401 Contact Us For Availability

WCI 08067754 WCI 08067754 Contact Us For Availability

WCI 5303284811 WCI 5303284811 Contact Us For Availability

WCI 3200488 WCI 3200488 Contact Us For Availability

WCI 5303284812 No Longer Available

SWITCH-IGNITER, (4) WCI 316032000 Contact Us For Availability

WCI 5303269499 WCI 5303269499 Contact Us For Availability

WCI 5303209517 WCI 5303209517 Contact Us For Availability

WCI 08011674 WCI 08011674 Contact Us For Availability

5303935068 Frigidaire Flat Igniter In Stock WCI 5303935068 $118.07

WCI 5303211085 WCI 5303211085 Contact Us For Availability

FSTNR-PUSH ON WCI 08067776 Contact Us For Availability

RACK-OVEN, FLAT WCI 08011675 Contact Us For Availability

14A

STUD SPACER (2) (NON-ILLUSTRATED) WCI 08067978 Contact Us For Availability

15

COLLAR-GLASS WCI 316067600 Contact Us For Availability

15

WCI 08011680 WCI 08011680 Contact Us For Availability

WCI 316066603 WCI 316066603 Contact Us For Availability

WCI 316029405 WCI 316029405 Contact Us For Availability

PNL B/S RIGHT (WHITE) WCI 3051263 Contact Us For Availability

PNL B/S RIGHT (ALMOND) WCI 3051264 Contact Us For Availability

WCI 5303269987 WCI 5303269987 Contact Us For Availability

WCI 5303269989 WCI 5303269989 Contact Us For Availability

5303131601 Frigidaire Oven Seal Backorder WCI 5303131601 $273.99

WCI 5303208640 WCI 5303208640 Contact Us For Availability

WCI 5303209316 WCI 5303209316 Contact Us For Availability

SHIELD-WOOL U/O SIDE WCI 5303208706 Contact Us For Availability

18

3131903 Frigidaire Door/Drawer Bumper Backorder WCI 3131903 $40.48

18

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $22.72

18

TUBE-VALVE TO REGUL WCI 316065003 Contact Us For Availability

19

316116400 Frigidaire Oven Light Socket In Stock WCI 316116400 $49.48

19

WCI 3160625002 WCI 3160625002 Contact Us For Availability

19

SWITCH-OVEN LITE DOOR WCI 5303202622 Contact Us For Availability

20

5303208499 Frigidaire Gas Safety Valve In Stock WCI 5303208499 $484.52

20

WCI 5303131289 WCI 5303131289 Contact Us For Availability

20

WCI 5303290773 WCI 5303290773 Contact Us For Availability

21

316091600 Frigidaire Oven Bracket Backorder WCI 316091600 $53.82

21

SHIELD-WALL REAR WCI 316014401 Contact Us For Availability

21

FLUE BACK U/O WCI 3200505 Contact Us For Availability

22

5303935125 Frigidaire Pressure Regulator Backorder WCI 5303935125 $345.55

22

WCI 316014301 WCI 316014301 Contact Us For Availability

22

PNL-TOP U/O WCI 3131625 Contact Us For Availability

23

NUT, SPECIAL WCI 3013279 Contact Us For Availability

23

CLIP-WIRE WCI 3011813 Contact Us For Availability

23

WCI 08067732 WCI 08067732 Contact Us For Availability

24

IGNITER-UPPER OVEN WCI 5303200508 Contact Us For Availability

24

WCI 3131931 WCI 3131931 Contact Us For Availability

24

HINGE-DOOR-TOP WCI 3131613 Contact Us For Availability

25

316542102 Frigidaire Flue Gasket Backorder WCI 316542102 $8.85

25

BURNER-UPPER OVEN WCI 3200502 Contact Us For Availability

25

WCI 3203082 WCI 3203082 Contact Us For Availability

25A

SHIELD-LATCH (NON-ILLUSTRATED) WCI 3131593 Contact Us For Availability

25B

WCI 08013188 WCI 08013188 Contact Us For Availability

26

WCI 3131623 WCI 3131623 Contact Us For Availability

26

WCI 3203218 WCI 3203218 Contact Us For Availability

27

WCI 5303015453 WCI 5303015453 Contact Us For Availability

27

WCI 316065000 WCI 316065000 Contact Us For Availability

28

TUBE-REGUL MANF WCI 316065005 Contact Us For Availability

28

WCI 5303131357 WCI 5303131357 Contact Us For Availability

29

IGNITER-TOP BURNER (4) WCI 3200276 Contact Us For Availability

29

WCI 08067757 WCI 08067757 Contact Us For Availability

30

WCI 3011597 WCI 3011597 Contact Us For Availability

31

BURNER-TOP (4) WCI 316057100 Contact Us For Availability

31

SHIELD-FRONT WCI 5303271047 Contact Us For Availability

32

WCI 5303208636 WCI 5303208636 Contact Us For Availability

32

SHIELD-OVN TOP WCI 3131314 Contact Us For Availability

33

WCI 3200836 WCI 3200836 Contact Us For Availability

34

WCI 5303269543 WCI 5303269543 Contact Us For Availability

34A

WCI 5303269545 WCI 5303269545 Contact Us For Availability

35

SCREW-LEVELING WCI 5303203397 Contact Us For Availability

36

316067902 Frigidaire Oven Rack Backorder WCI 316067902 $73.09

37

WCI 5303131356 WCI 5303131356 Contact Us For Availability

38

PAN-BROILER WCI 5303013568 Contact Us For Availability

39

BTTM-OVEN WCI 5303300701 Contact Us For Availability

39A

316064600 Frigidaire Oven Support Backorder WCI 316064600 $13.86

40

316282700 Frigidaire Oven Screw Backorder WCI 316282700 $7.74

40A

WCI 08067961 WCI 08067961 Contact Us For Availability

40B

WCI 316034200 WCI 316034200 Contact Us For Availability

40C

08067973 Frigidaire 0 Insulation Backorder WCI 08067973 $40.48

40D

INSUL WOOL TOP (NON-ILLUSTRATED) WCI 3131304 Contact Us For Availability

40E

INSUL WRAP (NON-ILLUSTRATED) WCI 3200833 Contact Us For Availability

40F

WCI 08068018 WCI 08068018 Contact Us For Availability

42

3051162 Frigidaire Oven Range Front Broiler D In Stock WCI 3051162 $6.60

43

WCI 5303208642 WCI 5303208642 Contact Us For Availability

43A

TUBE-POST RH WCI 5303208643 Contact Us For Availability
