Model Whirlpool 5VEV201NAQ00 VERTICAL FREEZER – Common Parts & Diagrams

1
LINER (NOT A SERVICEABLE PART)
LINER (NOT A SERVICEABLE PART) WPL NP Contact Us For Availability
View on Model
1
PLUG, DOOR
PLUG, DOOR WPL 160121001 Contact Us For Availability
View on Model
2
KNOB, CONTROL
KNOB, CONTROL WPL 382390001 Contact Us For Availability
View on Model
2
RAIL, DOOR
RAIL, DOOR WPL 465451001 Contact Us For Availability
View on Model
4
BASKET, W/STOP
BASKET, W/STOP WPL 482880002 Contact Us For Availability
View on Model
4
VENT PLUG
VENT PLUG WPL 324898007 Contact Us For Availability
View on Model
5
SWITCH, ALARM
SWITCH, ALARM WPL W10496781 Contact Us For Availability
View on Model
5
GASKET, DOOR
GASKET, DOOR WPL 465151004 Contact Us For Availability
View on Model
6
CLIP, EVAP. MOTOR
CLIP, EVAP. MOTOR WPL 13058002 Contact Us For Availability
View on Model
6
BASKET, WIRE
BASKET, WIRE WPL 460064001 Contact Us For Availability
View on Model
6
DOOR ASSEMBLY (INCLUDES INTERIOR DOOR LINER)
DOOR ASSEMBLY (INCLUDES INTERIOR DOOR LINER) WPL 482827079 Contact Us For Availability
View on Model
7
PAN, DRAIN
PAN, DRAIN WPL 482674001 Contact Us For Availability
View on Model
7
DEFROST TIMER
DEFROST TIMER WPL 381329001 Contact Us For Availability
View on Model
8
GASKET, COVER EVAPORATOR (RIGHT)
GASKET, COVER EVAPORATOR (RIGHT) WPL 360180001 Contact Us For Availability
View on Model
8
GASKET, COVER EVAPORATOR (LEFT)
GASKET, COVER EVAPORATOR (LEFT) WPL 360180002 Contact Us For Availability
View on Model
8
SWITCH, LIGHT
SWITCH, LIGHT WPL W10469826 Contact Us For Availability
View on Model
9
LENS, LIGHT
LENS, LIGHT WPL 382391001 Contact Us For Availability
View on Model
10
BIN ASSEMBLY
BIN ASSEMBLY WPL 482576001 Contact Us For Availability
View on Model
11
HANDLE
HANDLE WPL 383029002 Contact Us For Availability
View on Model
12
SHIELD, LIGHT
SHIELD, LIGHT WPL 382392001 Contact Us For Availability
View on Model
12
STOP, DOOR (LOWER)
STOP, DOOR (LOWER) WPL 281124001 Contact Us For Availability
View on Model
13
BOX, CONTROL
BOX, CONTROL WPL 482389003 Contact Us For Availability
View on Model
14
SHELF, UPPER WIRE
SHELF, UPPER WIRE WPL 482634001 Contact Us For Availability
View on Model
15
RELAY
RELAY WPL 235154011 Contact Us For Availability
View on Model
15
AIR DIFFUSER, UPR
AIR DIFFUSER, UPR WPL 482556002 Contact Us For Availability
View on Model
16
SHELF, LOWER WIRE
SHELF, LOWER WIRE WPL 482977001 Contact Us For Availability
View on Model
17
AIR DIFFUSER, LWR
AIR DIFFUSER, LWR WPL 482573002 Contact Us For Availability
View on Model
19
OVERLOAD
OVERLOAD WPL 234286027 Contact Us For Availability
View on Model
23
BOLT, COMPRESSOR
BOLT, COMPRESSOR WPL 282082001 Contact Us For Availability
View on Model
25
EXCHANGER, HEAT
EXCHANGER, HEAT WPL W10474982 Contact Us For Availability
View on Model
28
CONDENSER
CONDENSER WPL W10451952 Contact Us For Availability
View on Model
29
SCREW
SCREW WPL 324838048 Contact Us For Availability
View on Model
NI
TAPE, VINYL (3/4 X 108``)
TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability
View on Model
NI
REFINISHING MATERIAL (ENAMEL, WHITE (1 QT. UN
REFINISHING MATERIAL (ENAMEL, WHITE (1 QT. UN WPL 799344 Contact Us For Availability
View on Model
