Model Kenmore 587.14012400 DISHWASHER – Common Parts &amp; Diagrams

*

Screw, #10-16 x 3/8 WCI 154200601 Contact Us For Availability

1

154331607 Frigidaire Dishrack Assembly Lower In Stock WCI 154331607 $109.04

1

154430501 Frigidaire Dishwasher Door Spring In Stock WCI 154430501 $16.47

1

Panel, control, black WCI 154368303 Contact Us For Availability

1*

154289801 Frigidaire Dishwasher Shield Backorder WCI 154289801 $6.09

1A

154325201 Frigidaire Linkage Spring In Stock WCI 154325201 $16.47

2

154093301 Frigidaire Dishwasher ARM Assembly In Stock WCI 154093301 $1.65

2

5304509753 Frigidaire Silverware Basket In Stock WCI 5304509753 $39.80

2

Bracket, heater, (2) WCI 154479601 Contact Us For Availability

3

5304535380 Frigidaire Upper Dishrack Assembly In Stock WCI 5304535380 $98.16

3#

Timer WCI 154437701 Contact Us For Availability

4

154522902 Frigidaire Dishwasher Wheel and Bus In Stock WCI 154522902 $32.21

4

Screw, 10-16 x 3/8, hex WCI 154200602 Contact Us For Availability

5

5300809927 Frigidaire End Cap In Stock WCI 5300809927 $2.76

6

154597801 Frigidaire Dishwasher Upper Rack Sl In Stock WCI 154597801 $4.01

6

5303943103 Frigidaire Dishwasher P-1 Screw Ki In Stock WCI 5303943103 $13.86

7

5304532229 Frigidaire Dishwasher Lower Rack W In Stock WCI 5304532229 $10.40

7

Door, inner assy WCI 154299004 Contact Us For Availability

8#

154240403 Frigidaire Dishwasher Selector Swit Backorder WCI 154240403 $59.34

8#

Switch, rocker/selector, white WCI 154240401 Contact Us For Availability

9*

154294701 Frigidaire Dishwasher Screw Backorder WCI 154294701 $7.18

154103702 Frigidaire Dishwasher Screw Backorder WCI 154103702 $10.53

154371301 Frigidaire Dishwasher Screw Backorder WCI 154371301 $9.96

Cover, volute WCI 154335301 Contact Us For Availability

Screw, phillips head, bisque WCI 154371303 Contact Us For Availability

11

808326801 Frigidaire Dishwasher Screw Backorder WCI 808326801 $2,263.98

13

154246801 Frigidaire Dishwasher Primary Gaske Backorder WCI 154246801 $38.83

13

154338303 Frigidaire Dishwasher Knob Backorder WCI 154338303 $41.05

13

Knob, timer, white WCI 154338301 Contact Us For Availability

14

Housing, sump WCI 154365903 Contact Us For Availability

15

Screw, leveling WCI 154419301 No Longer Available

16

154246502 Frigidaire Dishwasher Bracket In Stock WCI 154246502 $31.58

Vent assy, static dry WCI 154433001 Contact Us For Availability

Door, white WCI 154359105 Contact Us For Availability

Door, black WCI 154359107 Contact Us For Availability

Cover, junction box WCI 154209601 Contact Us For Availability

20*

Screw, door mtg., (2) WCI 5304428306 Contact Us For Availability

22

154388801 Frigidaire Dishwasher Rinse Aid Dis In Stock WCI 154388801 $33.16

23

5304538466 Frigidaire Hose Clamp Backorder WCI 5304538466 $1.81

24A

154335201 Frigidaire Dishwasher Lower Spray A In Stock WCI 154335201 $32.20

28

154773201 Frigidaire Dishwasher Switch Assemb In Stock WCI 154773201 $51.87

29#

154290204 Frigidaire Dishwasher Thermostat In Stock WCI 154290204 $50.46

30

154241101 Frigidaire Dishwasher Retainer Backorder WCI 154241101 $2.76

30*

154297701 Frigidaire Dishwasher Screw Backorder WCI 154297701 $10.53

40

154348502 Frigidaire Dishwasher Clamp Backorder WCI 154348502 $7.20

40*

154380601 Frigidaire Dishwasher Clamp Assembl In Stock WCI 154380601 $57.66

50

Support, door hinge WCI 154211401 Contact Us For Availability

51

Clamp, drip loop, wire WCI 154320301 Contact Us For Availability

54

154234401 Frigidaire Dishwasher Hose P-1 Backorder WCI 154234401 $52.68

55*

Screw, truss ss, 8 .625 WCI 5303316032 Contact Us For Availability

59

154246901 Frigidaire Dishwasher Rear O-Ring f In Stock WCI 154246901 $52.81

59A

154247001 Frigidaire Dishwasher Pump Gasket S In Stock WCI 154247001 $52.81

60*

Bracket, motor, drain WCI 154426201 Contact Us For Availability

65

5304506525 Frigidaire Dishwasher Filter Assem In Stock WCI 5304506525 $36.00
