Model Electrolux 253.78299897 Refrigerator (Kenmore 25378299897) – Common Parts &amp; Diagrams

1

Refrigerator Freezer Gasket WCI 215608925 Contact Us For Availability

1

Refrigerator Condenser WCI 218787700 Contact Us For Availability

1A

Refrigerator Spacer Tube WCI 5303208866 Contact Us For Availability

1B

Refrigerator Spacer Tube WCI 5303289026 Contact Us For Availability

2

Refrigerator Door Gasket (Black) WCI 218730616 Contact Us For Availability

2

Clip-cond Mt WCI 5303289029 Contact Us For Availability

2

Spring WCI 3206348 Contact Us For Availability

3

Refrigerator Inner Panel WCI 215784001 Contact Us For Availability

3

Refrigerator Ice Maker Decal WCI 3206299 Contact Us For Availability

4

215516220 Frigidaire Refrigerator Door Rack Backorder WCI 215516220 $40.41

4

5303305677 Frigidaire Replacement Filters Fil In Stock WCI 5303305677 $22.61

4

5304469403 Frigidaire Gear Backorder WCI 5304469403 $14.78

5

218758602 Frigidaire Refrigerator Door Rack S In Stock WCI 218758602 $17.31

5

Refrigerator Evaporator Fan Blade WCI 5303292398 Contact Us For Availability

5

Refrigerator Wiring Harness WCI 218965601 Contact Us For Availability

5

Refrigerator Ice Maker Cover Bracket WCI 3206303 Contact Us For Availability

5A

Refrigerator Wiring Harness WCI 218463600 Contact Us For Availability

6

218359202 Frigidaire Refrigerator Screw Backorder WCI 218359202 $7.86

6

Refrigerator Wiring Harness WCI 218966001 Contact Us For Availability

7

5303918277 Frigidaire Refrigerator Ice Maker In Stock WCI 5303918277 $74.22

7

Refrigerator Power Cord WCI 215459201 Contact Us For Availability

7

Refrigerator Dairy Door WCI 5304404061 Contact Us For Availability

8

Refrigerator Wiring Cover WCI 218803400 Contact Us For Availability

8

Spacer WCI 3206312 Contact Us For Availability

8A

Wiring Screw WCI 218754500 Contact Us For Availability

9

Refrigerator Evaporator Fan Motor Bracket, Fr WCI 5303292396 Contact Us For Availability

9

Refrigerator Inner Panel WCI 5303292371 Contact Us For Availability

9

Cam WCI 3206313 Contact Us For Availability

10

Refrigerator Button Plug WCI 5303299154 Contact Us For Availability

10

Clamp WCI 3206315 Contact Us For Availability

11

5303208309 Frigidaire Refrigerator Plug Hole In Stock WCI 5303208309 $31.49

11

Kenmore Pro Refrigerator Ice Maker Thermal Cu WCI 3206319 Contact Us For Availability

11

Refrigerator Panel WCI 5303918037 Contact Us For Availability

11A

Refrigerator Freezer Door Panel WCI 5303918036 Contact Us For Availability

12

Refrigerator Ice Maker Wire Harness WCI 3206349 Contact Us For Availability

12A

Refrigerator Ice Maker Wire Harness Connector WCI 3206321 Contact Us For Availability

13

Refrigerator Door Stop WCI 5303289522 Contact Us For Availability

13

Refrigerator Ice Maker Thermostat WCI 3206322 Contact Us For Availability

13

Refrigerator Heat Exchange WCI 218168602 Contact Us For Availability

13A

215474201 Frigidaire Refrigerator Washer Backorder WCI 215474201 $13.64

13A

Refrigerator Door Stop WCI 215030018 Contact Us For Availability

240438003 Frigidaire Refrigerator Bracket and Backorder WCI 240438003 $12.06

240494003 Frigidaire Refrigerator Button Plug In Stock WCI 240494003 $12.59

5309918806 Frigidaire Refrigerator Light Swit Backorder WCI 5309918806 $16.26

5317842502 Frigidaire Defrost Heater Assembly Backorder WCI 5317842502 $99.21

Refrigerator Ice Maker Motor Screw WCI 3206323 Contact Us For Availability

5304456667 Frigidaire Refrigerator Micro Swit Backorder WCI 5304456667 $64.04

Refrigerator Light Bulb, 25-watt WCI 215812200 Contact Us For Availability

Refrigerator Evaporator WCI 5303321220 Contact Us For Availability

Ff Panel WCI 5303918035 Contact Us For Availability

15A

Refrigerator Light Bulb WCI 218708700 Contact Us For Availability

15A

Refrigerator Panel WCI 5303918034 Contact Us For Availability

16

5308000110 Frigidaire Refrigerator Evaporator In Stock WCI 5308000110 $42.93

16

Refrigerator Receptacle WCI 5308000129 Contact Us For Availability

16

Support WCI 3206326 Contact Us For Availability

16A

218906802 Frigidaire Light Lamp Socket In Stock WCI 218906802 $15.24

16A

Refrigerator Light Socket WCI 5303299157 Contact Us For Availability

17

241798231 Frigidaire Refrigerator Ice Maker A In Stock WCI 241798231 $145.94

17

Refrigerator Evaporator Insulation WCI 5316651102 Contact Us For Availability

17

Refrigerator Control Box WCI 215932906 Contact Us For Availability

17A

Refrigerator Nut Anchor WCI 5308016567 Contact Us For Availability

Refrigerator Door Handle (Charcoal Gray) WCI 218779903 Contact Us For Availability

Refrigerator Temperature Complete Knob WCI 5304414917 Contact Us For Availability

Refrigerator Insulation WCI 5303292407 Contact Us For Availability

Ejector WCI 3206328 Contact Us For Availability

18A

Refrigerator Temperature Complete Knob WCI 5304414918 Contact Us For Availability

18A

Refrigerator Door Handle WCI 218779806 Contact Us For Availability

19

Refrigerator Rocker Switch WCI 5303286905 Contact Us For Availability

19

Refrigerator Spacer Tube WCI 218631200 Contact Us For Availability

19

Bearing WCI 3206330 Contact Us For Availability

20

Refrigerator Insulation WCI 5303292406 Contact Us For Availability

20

Screw WCI 3206331 Contact Us For Availability

20A

Insulation P WCI 5303292405 Contact Us For Availability

21

5303917954 Frigidaire Refrigerator Defrost Li In Stock WCI 5303917954 $24.43

21

Refrigerator Electronic Control WCI 5304403880 Contact Us For Availability

21

Ice Stripper WCI 3206332 Contact Us For Availability

21A

Refrigerator Screw WCI 5303001260 Contact Us For Availability

21A

Refrigerator Door Stop Screw, #10-16 x 3/4-in WCI 218578600 Contact Us For Availability

21C

Screw/pan Hd WCI 218871701 Contact Us For Availability

215774918 Frigidaire Refrigerator Button Plug Backorder WCI 215774918 $6.81

Refrigerator Door Hinge Bushing WCI 5303289320 Contact Us For Availability

Refrigerator Tube WCI 218660701 Contact Us For Availability

Comp Mountng WCI 218811100 Contact Us For Availability

Arm WCI 3206333 Contact Us For Availability

215846602 Frigidaire Refrigerator 8-Hour Defr In Stock WCI 215846602 $23.29

218513300 Frigidaire Refrigerator Compressor In Stock WCI 218513300 $31.49

Refrigerator Drain Tube WCI 215266301 Contact Us For Availability

Screw WCI 3206334 Contact Us For Availability

23A

Defrost Cover WCI 215277000 Contact Us For Availability

23B

5304455649 Frigidaire Refrigerator Screw Backorder WCI 5304455649 $12.59

23C

Defrost Shield WCI 5303289058 Contact Us For Availability

24

5304456675 Frigidaire Refrigerator Lever Arm Backorder WCI 5304456675 $49.34

24

Refrigerator Drain Tube Seal WCI 5303207353 Contact Us For Availability

25

Refrigerator Crisper Cover WCI 215216648 Contact Us For Availability

25

Bolt Compres WCI 218773500 Contact Us For Availability

25

Screw WCI 3206336 Contact Us For Availability

25A

Refrigerator Crisper Trim WCI 5304404320 Contact Us For Availability

26

Refrigerator Crisper Pan WCI 5303292386 Contact Us For Availability

26

Refrigerator Egg Bin WCI 3204522 Contact Us For Availability

26

Screw WCI 3206337 Contact Us For Availability

27

Screw WCI 3206338 Contact Us For Availability

28

Screw WCI 3206339 Contact Us For Availability

29

5304475098 Frigidaire Refrigerator Compressor In Stock WCI 5304475098 $391.97

29

Refrigerator Washer WCI 215003200 Contact Us For Availability

29

Screw WCI 3206340 Contact Us For Availability

29A

Refrigerator Door Hinge Washer WCI 215314301 Contact Us For Availability

30

5304491583 Frigidaire Freezer Start Relay and Backorder WCI 5304491583 $77.30

30

Screw WCI 3206341 Contact Us For Availability

31

Refrigerator Deli Drawer WCI 5303304632 Contact Us For Availability

31

Insulator WCI 3206342 Contact Us For Availability

32

Bale Wire WCI 218888601 Contact Us For Availability

32

Refrigerator Ice Maker Fill Switch Bracket WCI 3206343 Contact Us For Availability

33

Spring WCI 3206344 Contact Us For Availability

34

5303212918 Frigidaire Refrigerator Control Backorder WCI 5303212918 $72.44

34

Light Bumper WCI 218783202 Contact Us For Availability

34

Screw WCI 3206345 Contact Us For Availability

35

Refrigerator Door Hinge Bracket, Center WCI 218220103 Contact Us For Availability

35

Screw WCI 3206346 Contact Us For Availability

36

Refrigerator Door Hinge Pin, Center WCI 215095900 Contact Us For Availability

36

Refrigerator Glass Shelf WCI 215406134 Contact Us For Availability

36

Cover WCI 3206347 Contact Us For Availability

37

Technical Data Sheet WCI 5303320544 Contact Us For Availability

37A

Refrigerator Door Handle Trim, Lower (Gray) WCI 218779312 Contact Us For Availability

37AB

Refrigerator Door Handle Trim Cap WCI 218776501 Contact Us For Availability

37AC

Tri Snap WCI 218776600 Contact Us For Availability

38

Envelope WCI 5303207445 Contact Us For Availability

39

Trim-frzr Sh WCI 5303284480 Contact Us For Availability

39

Refrigerator Electronic Harness WCI 5303289065 Contact Us For Availability

39A

Trim-full Sh WCI 215217539 Contact Us For Availability

41

5308000039 Frigidaire Refrigerator Screw Backorder WCI 5308000039 $8.91

42

Refrigerator Deli Drawer Hanger WCI 215002301 Contact Us For Availability

42A

Refrigerator Deli Drawer Slide Rail WCI 215002401 Contact Us For Availability

43

5303001199 Frigidaire Refrigerator Wiring Har Backorder WCI 5303001199 $48.81

43A

Refrigerator Screw WCI 218897001 Contact Us For Availability

44

5308000133 Frigidaire Refrigerator Clamp Backorder WCI 5308000133 $8.39

45

5304455651 Frigidaire Refrigerator Screw In Stock WCI 5304455651 $9.96

45

Refrigerator Screw WCI 218769200 Contact Us For Availability

46

5303001193 Frigidaire Refrigerator Clamp Backorder WCI 5303001193 $12.06

46

Refrigerator Crisper Drawer Front WCI 218278402 Contact Us For Availability

47

Refrigerator Glass Shelf WCI 218498162 Contact Us For Availability

48

Nut WCI 5308000200 Contact Us For Availability

49

215441502 Frigidaire Refrigerator Door Bin Backorder WCI 215441502 $124.68

51

Air Duct WCI 215132809 Contact Us For Availability

51

Fill Tube WCI 215811600 Contact Us For Availability

51A

Insulation WCI 215133200 Contact Us For Availability

51B

Insulation WCI 215133300 Contact Us For Availability

52

Refrigerator Ice Maker Fill Tube WCI 215454600 Contact Us For Availability

52

Control Damper WCI 215132901 Contact Us For Availability

52A

Refrigerator Air Damper WCI 215133000 Contact Us For Availability

54

Duct-meat Ke WCI 215133100 Contact Us For Availability

54

Cabinet Rail WCI 5303289027 Contact Us For Availability

54A

Rail-compr S WCI 5303289311 Contact Us For Availability

54B

Cabinet Rail WCI 5303289292 Contact Us For Availability

55

Refrigerator Run Capacitor WCI 218909902 Contact Us For Availability

55

Refrigerator Water Valve WCI 218959401 Contact Us For Availability

55A

240542901 Frigidaire Water Valve Cap Backorder WCI 240542901 $13.11

56

Compressor Insert WCI 218769300 Contact Us For Availability

57

Wiring Clip WCI 218247300 Contact Us For Availability

58

218781101 Frigidaire Handle Screw In Stock WCI 218781101 $12.20

58

240555002 Frigidaire Refrigerator Screw #8-32 In Stock WCI 240555002 $9.96

59

240442708 Frigidaire Refrigerator Screw - #10 In Stock WCI 240442708 $5.76

59

Refrigerator Shroud Condenser WCI 5303289031 Contact Us For Availability

59

Sleeve WCI 5303001191 Contact Us For Availability

59A

Cap Mullion WCI 215069518 Contact Us For Availability

59A

SEAL - FOAM, COND FAN SHROUD WCI 215226700 Contact Us For Availability

59B

Refrigerator Screw Mullion WCI 218188500 Contact Us For Availability

60

5304455852 Frigidaire Refrigerator Screw Backorder WCI 5304455852 $9.44

60

Refrigerator Condenser Fan Motor WCI 215501901 Contact Us For Availability

61

218721500 Frigidaire Refrigerator Leveling Br Backorder WCI 218721500 $54.06

61

Blade-cond F WCI 5303289032 Contact Us For Availability

61A

Refrigerator Nut WCI 215004700 Contact Us For Availability

61B

Grommet WCI 215004800 Contact Us For Availability

64

5304455846 Frigidaire Refrigerator Clamp In Stock WCI 5304455846 $7.86

66

Refrigerator Wine Rack WCI 5304402116 Contact Us For Availability

67

Front-meat P WCI 218278702 Contact Us For Availability

72

Refrigerator Door Handle Mounting Grommet WCI 218397000 No Longer Available

73

218396700 Frigidaire Door Handle Mounting Blo In Stock WCI 218396700 $39.05

74

215503203 Frigidaire Refrigerator Door Handle In Stock WCI 215503203 $5.24

77

Washer WCI 5303001216 Contact Us For Availability

81

5304455650 Frigidaire Refrigerator Screw Backorder WCI 5304455650 $10.49

100

Refrigerator Crisper Drawer Cover Support Stu WCI 5303288973 Contact Us For Availability

114

Refrigerator Door Switch WCI 5303299156 Contact Us For Availability

119

Refrigerator Air Duct Cap WCI 215132700 Contact Us For Availability

120

Seal-refr To WCI 218019201 Contact Us For Availability

121

Cable Damper WCI 215364001 Contact Us For Availability

121A

Refrigerator Nut WCI 215209400 Contact Us For Availability

122

Air De Block WCI 218561202 Contact Us For Availability

122A

Air De Block WCI 218561204 Contact Us For Availability

123

215005101 Frigidaire Refrigerator Screw Backorder WCI 215005101 $11.01

129

Refrigerator Deli Drawer Roller WCI 5303299152 Contact Us For Availability

129A

Refrigerator Drawer Roller Bearing WCI 5303299153 Contact Us For Availability

145

Refrigerator Clip WCI 218660800 Contact Us For Availability

218769500 Frigidaire Use and Care Label Backorder WCI 218769500 $3.66

Refrigerator Door Insulation WCI 5303917276 Contact Us For Availability

Refrigerator Liner Button Hole Plug WCI 5308016571 Contact Us For Availability

Refrigerator Hot Tube Repair Kit WCI 5303917214 Contact Us For Availability

Refrigerator Seal WCI 215339100 Contact Us For Availability

Refrigerator Seal WCI 215359900 Contact Us For Availability

SPACER-AIR CHANNEL WCI 21584800 Contact Us For Availability

Refrigerator Cleaner WCI 218490900 Contact Us For Availability

Refrigerator Service Data Sheet WCI 218901800 Contact Us For Availability

Refrigerator Owner's Manual WCI 218971600 Contact Us For Availability

Refrigerator Parts Catalog WCI 5995332243 Contact Us For Availability
