Model Samsung NE63T8311SS/AA-04 ELECTRIC RANGE – Common Parts & Diagrams
DRAWER ASSY
CONTROL BOX ASSY
CAVITY ASSY
MAIN ASSY
COOKTOP ASSY
DOOR ASSY
Common parts from model Samsung NE63T8311SS/AA-04 ELECTRIC RANGE
1
ASSY CAVITY-COATING SMG DG94-03527D Contact Us For Availability
1
ASSY MECHANICAL PARTS SMG DG90-01071B Contact Us For Availability
1
ASSY COOKTOP SMG DG94-03476E Contact Us For Availability
1-1
ASSY DOOR E SMG DG94-03598A Contact Us For Availability
1-1-1
BRACKET ELEC SMG DG61-02007A Contact Us For Availability
1-1-1
Inner Frame SMG DG61-00121C Contact Us For Availability
1-1-2
BRACKET BARRIER SMG DG61-01893A Contact Us For Availability
1-1-2
BAFFLE DOOR SMG DG62-00293A Contact Us For Availability
1-1-3
BRACKET GUIDE-LOW SMG DG61-01996A Contact Us For Availability
1-1-3
Frame Cover SMG DG63-00077C Contact Us For Availability
1-1-4
BRACKET GUIDE-LOW SMG DG61-01999A Contact Us For Availability
1-1-6
ASSY DOOR E-COATING SMG DG94-03605A Contact Us For Availability
1-1-8
ASSY COOKTOP FRAME SMG DG94-03622C Contact Us For Availability
1-2
SUPPORT FRAME-BOTTOM (4) SMG DG61-01993A Contact Us For Availability
1-2-3
ASSY SUPPORT GLASS SMG DG94-03608A Contact Us For Availability
1-2-4
CHASSIS DOOR-UP SMG DG64-00926A Contact Us For Availability
1-2-7
ASSY TRIM-LEFT SMG DG94-03606A Contact Us For Availability
1-2-8
ASSY TRIM-RIGHT SMG DG94-03607A Contact Us For Availability
1-3
ADIABATIC SMG DG62-00298A Contact Us For Availability
1-4
COVER ADIABATIC SMG DG63-00675A Contact Us For Availability
1-4-2
BRACKET PANEL SMG DG61-01944B Contact Us For Availability
1-4-3
COVER DISPLAY SMG DG63-00691A Contact Us For Availability
1-4-4
CHASSIS PANEL SMG DG64-00919B Contact Us For Availability
1-4-5
CAP-RIGHT SMG DG67-00215A Contact Us For Availability
1-4-6
CAP-LEFT SMG DG67-00216A Contact Us For Availability
1-4-7
ASSY TOUCH SMG DG96-00776A Contact Us For Availability
1-4-9
GASKET-RUBBER SMG DG63-00715A Contact Us For Availability
1-5
ASSY COOKTOP BURNER SMG DG94-03691E Contact Us For Availability
1-5-1
HOLDER LAMP-LED SMG DG61-01871A Contact Us For Availability
1-5-2
INDICATOR-LAMP SMG DG64-00909A Contact Us For Availability
1-5-6
BRACKET BOTTOM-LEFT SMG DG61-00803A Contact Us For Availability
1-5-7
BRACKET HEATER SMG DG61-01967A Contact Us For Availability
1-5-9
BRACKET BOTTOM-RIGHT SMG DG61-00808A Contact Us For Availability
2
ASSY VENT-MAIN SMG DG94-03531A Contact Us For Availability
2
ASSY CAVITY PARTS SMG DG90-01022D Contact Us For Availability
2
ASSY ACCESSORY PARTS SMG DG90-01086F Contact Us For Availability
2-1
Mesh Filter SMG DG63-00148A Contact Us For Availability
2-2
ASSY VENT COATING SMG DG94-03706A Contact Us For Availability
2-2
ASSY PACKING ACCESSORY SMG DG98-02125E Contact Us For Availability
3
ASSY COVER HEATER SMG DG94-03533A Contact Us For Availability
3
ASSY DRAWER MAIN-MODULE SMG DG90-01208A Contact Us For Availability
3-2
BRACKET HEATER-SUB SMG DG61-01938A Contact Us For Availability
4
ASSY BRACKET HEATER SMG DG94-03534A Contact Us For Availability
4
ASSY COOKTOP PARTS SMG DG90-01064E Contact Us For Availability
5
Range Oven Light Bulb SMG DG97-00083A No Longer Available
8
BAFFLE DOOR (2) SMG DG62-00292A Contact Us For Availability
9
ADIABATIC-MAIN SMG DG62-00304A Contact Us For Availability
11
ASSY COVER BACK-MAIN SMG DG94-03517B Contact Us For Availability
11-2
ADIABATIC-REAR SMG DG62-00302D Contact Us For Availability
11-4
ASSY COVER BACK SMG DG94-03519B Contact Us For Availability
17-1
BRACKET COVER SMG DG61-01937A Contact Us For Availability
19
LATCH-ROD SMG DG66-00071A Contact Us For Availability
× ![]()
