Model Samsung NE63B8211SS/AA-00 ELECTRIC RANGE – Common Parts & Diagrams
COOKTOP ASSY
DRAWER ASSY
CONTROL BOX ASSY
DOOR ASSY
CAVITY ASSY
MECHANICAL PARTS ASSY
Common parts from model Samsung NE63B8211SS/AA-00 ELECTRIC RANGE
1
ASSY CAVITY-COATING SMG DG94-03527E Contact Us For Availability
1
ASSY MECHANICAL PARTS SMG DG90-01071B Contact Us For Availability
1-1
ASSY DOOR E SMG DG94-03598A Contact Us For Availability
1-1-1
CAVITY DRAWER SMG DG61-02022A Contact Us For Availability
1-1-1
Inner Frame SMG DG61-00121C Contact Us For Availability
1-1-2
PANEL DRAWER SMG DG64-00913A Contact Us For Availability
1-1-2
BAFFLE DOOR SMG DG62-00293A Contact Us For Availability
1-1-3
CHASSIS PANEL-DRAWER SMG DG64-00925H Contact Us For Availability
1-1-3
Frame Cover SMG DG63-00077C Contact Us For Availability
1-1-4
ASSY SLIDER (2) SMG DG94-03764A Contact Us For Availability
1-1-6
ASSY DOOR E-COATING SMG DG94-03605A Contact Us For Availability
1-2
ASSY PEDESTAL SMG DG94-04255A Contact Us For Availability
1-2
SUPPORT FRAME-BOTTOM (4) SMG DG61-01993A Contact Us For Availability
1-2-3
BRACKET-LEG (2) SMG DG61-01990A Contact Us For Availability
1-2-3
ASSY SUPPORT GLASS SMG DG94-03608A Contact Us For Availability
1-2-4
CHASSIS DOOR-UP SMG DG64-01071A Contact Us For Availability
1-2-5
SUPPORT FRAME (2) SMG DG61-01957A Contact Us For Availability
1-2-6
SHIELD DRAWER SMG DG63-00721A Contact Us For Availability
1-2-7
COVER HEATER-TOP SMG DG63-00725A Contact Us For Availability
1-2-7
ASSY TRIM-LEFT SMG DG94-03606A Contact Us For Availability
1-2-8
ASSY TRIM PEDESTAL SMG DG94-04126A Contact Us For Availability
1-2-8
ASSY TRIM-RIGHT SMG DG94-03607A Contact Us For Availability
1-2-9
ASSY BASE PLATE-DRAWER SMG DG94-03469A Contact Us For Availability
1-2-9-1
BASE DRAWER-RIGHT SMG DG61-01875A Contact Us For Availability
1-2-9-2
BASE DRAWER-LEFT SMG DG61-01876A Contact Us For Availability
1-2-9-3
BASE DRAWER-REAR SMG DG61-01877A Contact Us For Availability
1-3-1
COVER BACK SMG DG63-00677A Contact Us For Availability
1-3-7
BRACKET SHIE SMG DG61-02009A Contact Us For Availability
1-4
Ne63B8411S,240Vac SMG DG94-04393A Contact Us For Availability
1-4-1
ASSY COOKTOP CASE-MODULE SMG DG61-02012A Contact Us For Availability
1-4-2
SPRING ETC (10) SMG DG94-04093A Contact Us For Availability
1-4-5
Fan Motor SMG DG63-00716A Contact Us For Availability
1-4-6
COVER AIR-LE SMG DG63-00717A Contact Us For Availability
1-4-13
COVER FILTER SMG DG61-02011A Contact Us For Availability
2
ASSY VENT-MAIN SMG DG94-03531A Contact Us For Availability
2
ASSY COOKTOP PARTS SMG DG90-01273D Contact Us For Availability
2-1
Mesh Filter SMG DG63-00148A Contact Us For Availability
2-2
ASSY VENT COATING SMG DG94-03706A Contact Us For Availability
2-3-2
SPACER PANEL (4) SMG DG61-01944B Contact Us For Availability
2-3-4
BRACKET GUIDE SMG DG63-00691A Contact Us For Availability
2-3-5
COVER DISPLAY SMG DG63-00715A Contact Us For Availability
2-3-6
GASKET-RUBBER SMG DG64-00919E Contact Us For Availability
2-3-7
CHASSIS PANEL SMG DG67-00215A Contact Us For Availability
2-3-8
CAP-RIGHT SMG DG67-00216A Contact Us For Availability
3
ASSY COVER HEATER SMG DG94-03533A Contact Us For Availability
3
ASSY CAVITY PARTS SMG DG90-01022Q Contact Us For Availability
3-2
BRACKET HEATER-SUB SMG DG61-01938A Contact Us For Availability
4
ASSY BRACKET HEATER SMG DG94-03534A Contact Us For Availability
5
Range Oven Light Bulb SMG DG97-00083A No Longer Available
6
ASSY ACCESSORY PARTS SMG DG90-01086P Contact Us For Availability
6-3
ASSY PACKING ACCESSORY SMG DG98-02125H Contact Us For Availability
8
BAFFLE DOOR (2) SMG DG62-00292A Contact Us For Availability
9
ADIABATIC-MAIN SMG DG62-00304A Contact Us For Availability
11
ASSY COVER BACK-MAIN SMG DG94-03517C Contact Us For Availability
11-2
ADIABATIC-REAR SMG DG62-00302D Contact Us For Availability
11-4
COVER BACK-MAIN SMG DG63-00702A Contact Us For Availability
17
Range Terminal Block Grounding Strap Plate SMG DG66-00071A Contact Us For Availability
19-1
COVER ADIABA SMG DG63-00684B Contact Us For Availability
26
ASSY DUCT SMG DG96-00889A Contact Us For Availability
× ![]()
