Model Samsung MD800WC/XAA Microwave – Common Parts & Diagrams
CONTROL PANEL/DOOR ASSEMBLY
BODY/CAVITY/ELEMENTS
INTERNAL CONTROLS/LATCH ASY/BASE
BLOWER MOTOR
Common parts from model Samsung MD800WC/XAA Microwave
1
Motor Assembly SMG DE96-00333A Contact Us For Availability
2
Decoration SMG DE64-00899B Contact Us For Availability
2
Latch Body SMG DE66-00132A Contact Us For Availability
2
Fan Blade SMG DE31-90054A Contact Us For Availability
3
Assy-key M SMG DE96-00344A Contact Us For Availability
3
Microwave Blower Cover SMG DE63-00238A Contact Us For Availability
4
Control Panel SMG DE64-00894A Contact Us For Availability
4
(NSP) CUSHION B SMG N/P Contact Us For Availability
4A
Control Panel SMG DE64-00894B Contact Us For Availability
5
Window SMG DE64-00897A Contact Us For Availability
5
Bracket SMG DE97-00436A Contact Us For Availability
6
PCB Assembly SMG RAS-K2LED-01 Contact Us For Availability
6A
Switch SMG DE34-00194B Contact Us For Availability
7
Magnetron Cover SMG DE63-00195A Contact Us For Availability
7
Insulation SMG DE62-00047A Contact Us For Availability
8
Air Cover SMG DE63-00194A Contact Us For Availability
8
Bracket Piece SMG DE61-00522A Contact Us For Availability
9
ASSY-MAGNETRON SMG OM75S(20)ERHN Contact Us For Availability
13
Bracket-mg SMG DE61-00616A Contact Us For Availability
16A
Outer Panel SMG DE64-00889B Contact Us For Availability
17
Cap SMG DE67-00189A Contact Us For Availability
17
Trans H.v SMG DE26-00100A Contact Us For Availability
18
Base Plate SMG DE61-00520A Contact Us For Availability
20
Wire Assembly SMG DE96-00339A Contact Us For Availability
× ![]()
