Model Samsung AW08ECB8/XAA-00 Room Air Conditioner – Common Parts & Diagrams
AIR CONDITIONER
Common parts from model Samsung AW08ECB8/XAA-00 Room Air Conditioner
1-1
Panel SMG DB64-00916A Contact Us For Availability
1-2
Air Grille SMG DB64-00917A Contact Us For Availability
1-3
Blade-vs SMG DB66-00556A Contact Us For Availability
1-4
Blade Valve SMG DB66-00555A Contact Us For Availability
1-5
Link Blade SMG DB66-00558A Contact Us For Availability
1-6
Air Filter SMG DB63-00810C Contact Us For Availability
1-7
Frame Blade SMG DB61-01530A Contact Us For Availability
2
Lever Damper SMG DB66-00557B Contact Us For Availability
4
Evaporator SMG DB96-09123A Contact Us For Availability
5
PLATE-EVAP SMG DB70-00696A Contact Us For Availability
6
Flange Nut SMG DB60-30004A Contact Us For Availability
7
Blower SMG DB67-50078D Contact Us For Availability
8
az0 SMG DB61-02863A Contact Us For Availability
9
CASE EVAP- SMG DB94-01131B Contact Us For Availability
10
Assy Partiti SMG DB62-04769A Contact Us For Availability
11
Seal Cover SMG DB31-00215A Contact Us For Availability
12
Fan Motor SMG DB67-50077A Contact Us For Availability
13
Room Air Conditioner Outdoor Fan Blade SMG DB60-30020A Contact Us For Availability
14
Flange Nut SMG DB61-01532A Contact Us For Availability
15
Case Condenser SMG DB96-09122A Contact Us For Availability
16
Condenser SMG DB92-00113C Contact Us For Availability
17
Assy Shutt SMG DB90-03154C Contact Us For Availability
18
Cabinet Assembly SMG DC64-00048H Contact Us For Availability
19
SHUTTER ANGLE UPPER SMG DB92-00112C Contact Us For Availability
20
Shutter SMG DB62-05686A Contact Us For Availability
21
Tube SMG DB96-09131A Contact Us For Availability
22
Assy Tube Su SMG 39B078HSAEA Contact Us For Availability
23
Rcp,39,h,r22 SMG 6021-001142 Contact Us For Availability
24
Nut-hexago SMG DB63-00765A Contact Us For Availability
25
Gasket SMG DB63-00762B Contact Us For Availability
26
r/c SMG DB60-00319A Contact Us For Availability
27
COVER TERM SMG DB63-00764A Contact Us For Availability
28
Nut Washer SMG DB35-00082G Contact Us For Availability
30
Relay Protector SMG DB96-09124A Contact Us For Availability
31
Room Air Conditioner Remote Control SMG DB90-01255B Contact Us For Availability
32
Assy Tube Ca SMG DB97-30156C Contact Us For Availability
33
Base Assembly SMG DB61-30219F Contact Us For Availability
34-1
Bracket SMG DB61-01535B Contact Us For Availability
34-2
Control Box SMG DB61-01536B Contact Us For Availability
34-4
Case Control SMG DB26-00088A Contact Us For Availability
34-6
Transformer SMG DB93-04822C Contact Us For Availability
34-10
Power Assembly SMG DB93-05815K Contact Us For Availability
34-11
Thermistor SMG DB64-00918A Contact Us For Availability
34-12
Main PCB SMG DB64-02067A Contact Us For Availability
× ![]()
