ZEK958SM1SS

Model ZEK958SM1SS – Common Parts & Diagrams

Common parts from model ZEK958SM1SS

WB27T10904 GE Oven Control ERC DDHE 27 MG

WB27T10904 GE Oven Control ERC DDHE 27 MG Out of Stock GEN WB27T10904 $406.83

WB64T10067 GE Oven Fan Assembly

WB64T10067 GE Oven Fan Assembly In Stock GEN WB64T10067 $92.85

WB02T10289 GE Oven Stirrer Fan Blade

WB02T10289 GE Oven Stirrer Fan Blade In Stock GEN WB02T10289 $18.69

WB27T10568 GE Oven Range Control Board

WB27T10568 GE Oven Range Control Board Out of Stock GEN WB27T10568 $77.71

WB02X10833 GE Oven Badge Monogram Small

WB02X10833 GE Oven Badge Monogram Small Out of Stock GEN WB02X10833 $78.91

WB35T10061 GE Oven Door Insulation Side

WB35T10061 GE Oven Door Insulation Side Out of Stock GEN WB35T10061 $7.17

WB56T10133 GE Oven Retainer Insulation

WB56T10133 GE Oven Retainer Insulation Out of Stock GEN WB56T10133 $58.41

WB32T10012 GE Oven Gasket Oven Door

WB32T10012 GE Oven Gasket Oven Door In Stock GEN WB32T10012 $56.09

WB01T10022 GE Oven Bumper Door

WB01T10022 GE Oven Bumper Door Out of Stock GEN WB01T10022 $7.54

WB01T10052 GE Oven Foam Tape-D

WB01T10052 GE Oven Foam Tape-D Out of Stock GEN WB01T10052 $7.54

WB57T10311 GE Oven Door Outer Assembly 27 (SS

WB57T10311 GE Oven Door Outer Assembly 27 (SS Out of Stock GEN WB57T10311 $957.45

WB24T10081 GE Oven High Limit Thermostat

WB24T10081 GE Oven High Limit Thermostat In Stock GEN WB24T10081 $32.19

WB24T10082 GE Oven Switch High LMT Upper OV

WB24T10082 GE Oven Switch High LMT Upper OV Out of Stock GEN WB24T10082 $41.26

WB24T10080 GE Oven Bake TCO

WB24T10080 GE Oven Bake TCO In Stock GEN WB24T10080 $22.04

WB24T10096 GE Oven Switch Limit Bimetal

WB24T10096 GE Oven Switch Limit Bimetal Out of Stock GEN WB24T10096 $11.15

WB24T10143 GE Oven Switch Limit

WB24T10143 GE Oven Switch Limit Out of Stock GEN WB24T10143 $67.46

WB63T10127 GE Oven Wrapper Oven CAV Assembly

WB63T10127 GE Oven Wrapper Oven CAV Assembly Out of Stock GEN WB63T10127 $201.83

FRAME FRONT

FRAME FRONT Out of Stock GEN WB63T10123 $106.20

RETAINER INSLN SDE

RETAINER INSLN SDE Out of Stock GEN WB63T10125 $45.67

RETAINER INSLN BTM

RETAINER INSLN BTM Out of Stock GEN WB63T10082 $50.71

COVER WIRE UPR RR

COVER WIRE UPR RR Out of Stock GEN WB02T10357 $44.07

INSULATION TOP BCK & BTM

INSULATION TOP BCK & BTM Out of Stock GEN WB35T10174 $81.24

INSULATION TOP & SIDES

INSULATION TOP & SIDES Out of Stock GEN WB35T10175 $91.33

WB48T10060 GE Oven Rack Oven (GY)

WB48T10060 GE Oven Rack Oven (GY) Out of Stock GEN WB48T10060 $96.46

WB48T10089 GE Oven Broiler Pan (XL)

WB48T10089 GE Oven Broiler Pan (XL) Out of Stock GEN WB48T10089 $52.04

WB44T10109 GE Oven Element Bake Assembly (210

WB44T10109 GE Oven Element Bake Assembly (210 Out of Stock GEN WB44T10109 $85.60

WB44T10099 GE Oven Element Broil Assembly

WB44T10099 GE Oven Element Broil Assembly In Stock GEN WB44T10099 $109.84

WB49X29679 GE Range Halogen Bulb Kit

WB49X29679 GE Range Halogen Bulb Kit In Stock GEN WB49X29679 $41.77

WB25T10096 GE Oven Lamp Halogen Assembly

WB25T10096 GE Oven Lamp Halogen Assembly Out of Stock GEN WB25T10096 $40.70

WB25T10027 GE Oven Lens Oven Lamp

WB25T10027 GE Oven Lens Oven Lamp Out of Stock GEN WB25T10027 $13.12

WB10T10076 GE Oven Receiver Hinge

WB10T10076 GE Oven Receiver Hinge Out of Stock GEN WB10T10076 $15.40

WB20T10024 GE Oven Probe Thermistor

WB20T10024 GE Oven Probe Thermistor In Stock GEN WB20T10024 $63.85

WB10T10108 GE Oven Hinge Right Door

WB10T10108 GE Oven Hinge Right Door Out of Stock GEN WB10T10108 $95.90

WB10T10109 GE Oven Hinge Left Door

WB10T10109 GE Oven Hinge Left Door Out of Stock GEN WB10T10109 $101.21

VENT INLET DUCT

VENT INLET DUCT Out of Stock GEN WB28T10212 $32.92

TUBE VNT ASM

TUBE VNT ASM Out of Stock GEN WB28T10213 $37.70

WB38X33650 GE Vent Tube

WB38X33650 GE Vent Tube Out of Stock GEN WB38X33650 $15.90

WB2X9152 GE Oven Cover

WB2X9152 GE Oven Cover Out of Stock GEN WB2X9152 $25.94

WB44X31764 GE Convection Heating Element

WB44X31764 GE Convection Heating Element Out of Stock GEN WB44X31764 $27.32

WB55T10086 GE Oven Window Pack

WB55T10086 GE Oven Window Pack Out of Stock GEN WB55T10086 $227.21

WB02T10363 GE Cover Electrical Top

WB02T10363 GE Cover Electrical Top Out of Stock GEN WB02T10363 $36.37

PAN REFLECTOR

PAN REFLECTOR Out of Stock GEN WB49T10016 $73.54

PAN REFLECTOR SIDE

PAN REFLECTOR SIDE Out of Stock GEN WB49T10017 $9.03

WB26T10043 GE Oven Motor PSC Convection

WB26T10043 GE Oven Motor PSC Convection In Stock GEN WB26T10043 $194.58

SUPPORT OVEN

SUPPORT OVEN Out of Stock GEN WB26T10046 $9.03

WB27T10662 GE Oven Capacitor

WB27T10662 GE Oven Capacitor Out of Stock GEN WB27T10662 $7.54

WB18T10225 GE Oven Conduit Wire Assembly

WB18T10225 GE Oven Conduit Wire Assembly Out of Stock GEN WB18T10225 $101.21

WB1K5200 GE Oven SCREW 340531

WB1K5200 GE Oven SCREW 340531 Out of Stock GEN WB1K5200 $7.54

WB1X536 GE Oven Screw

WB1X536 GE Oven Screw Out of Stock GEN WB1X536 $9.21

WB01T10110 GE Oven Screw 8-18X.450 AB FLT20 S

WB01T10110 GE Oven Screw 8-18X.450 AB FLT20 S Out of Stock GEN WB01T10110 $7.54

WB1X1137 GE Oven Screw-10AB

WB1X1137 GE Oven Screw-10AB Out of Stock GEN WB1X1137 $7.54

WB1X1130 GE Oven Screw-10-32

WB1X1130 GE Oven Screw-10-32 Out of Stock GEN WB1X1130 $7.54

WB02T10324 GE Oven Screw 6-20 GXB IHXW 3/8 NI

WB02T10324 GE Oven Screw 6-20 GXB IHXW 3/8 NI Out of Stock GEN WB02T10324 $7.54

WH2X930 GE Screw

WH2X930 GE Screw In Stock GEN WH2X930 $6.09

WB1K5173 GE Oven Screw ST 8-18 X 3/4" Black

WB1K5173 GE Oven Screw ST 8-18 X 3/4" Black Out of Stock GEN WB1K5173 $7.54

WB1K5174 GE Oven Washer

WB1K5174 GE Oven Washer Out of Stock GEN WB1K5174 $7.54

WB1X5573 GE Oven Washer

WB1X5573 GE Oven Washer Out of Stock GEN WB1X5573 $7.54

WB02T10017 GE Oven Nut

WB02T10017 GE Oven Nut Out of Stock GEN WB02T10017 $9.21

WB18T10371 GE Oven Ribbon Connector GLS TCH

WB18T10371 GE Oven Ribbon Connector GLS TCH Out of Stock GEN WB18T10371 $82.52

WB1X5572 GE Oven Nut

WB1X5572 GE Oven Nut Out of Stock GEN WB1X5572 $21.19

WB01T10017 GE Oven Screw 8-18 AB IHW 3/8 S NS

WB01T10017 GE Oven Screw 8-18 AB IHW 3/8 S NS Out of Stock GEN WB01T10017 $7.54

WB01T10008 GE Oven Screw 10-32 TR

WB01T10008 GE Oven Screw 10-32 TR In Stock GEN WB01T10008 $6.09

WB01T10101 GE Oven Screw 1/4-28 HXW 7/8 ZN

WB01T10101 GE Oven Screw 1/4-28 HXW 7/8 ZN Out of Stock GEN WB01T10101 $9.77
