Model LG Z50P3 – Common Parts & Diagrams
Diagram 0
Diagram 1
Common parts from model LG Z50P3
121
Speaker,Tweeter LGE EAB30826001 Contact Us For Availability
200
PDP,Module-XGA LGE EAJ36420207 Contact Us For Availability
201
Hand Insert PCB Assembly LGE EBR37004101 Contact Us For Availability
202
Hand Insert PCB Assembly LGE EBR37010001 Contact Us For Availability
203
Hand Insert PCB Assembly LGE EBR37010101 Contact Us For Availability
204
Hand Insert PCB Assembly LGE EBR37010301 Contact Us For Availability
205
Hand Insert PCB Assembly LGE EBR37011101 Contact Us For Availability
206
Hand Insert PCB Assembly LGE EBR37011201 Contact Us For Availability
207
Hand Insert PCB Assembly LGE EBR36906201 Contact Us For Availability
208
Hand Insert PCB Assembly LGE EBR36906701 Contact Us For Availability
240
SUPPORTER LGE 4980900101C Contact Us For Availability
250
SUPPORTER LGE 4980900102C Contact Us For Availability
300
Cover Assembly LGE ACQ30250002 Contact Us For Availability
301
SUPPORTER LGE 4980900103B Contact Us For Availability
302
SUPPORTER LGE 4980900104B Contact Us For Availability
303
SUPPORTER LGE 4980900105B Contact Us For Availability
304
SUPPORTER LGE 4980900106B Contact Us For Availability
305
Filter LGE 5230V00025C Contact Us For Availability
400
Cover Assembly,Rear LGE ACQ32761704 Contact Us For Availability
430
Base Assembly LGE 3501900004J Contact Us For Availability
431
Cover LGE 35509K0101D Contact Us For Availability
501
Plate Assembly LGE 3301900089S Contact Us For Availability
502
Plate Assembly LGE 3301900094W Contact Us For Availability
520
Hand Insert PCB Assembly,Main LGE EBR41354501 Contact Us For Availability
560
PCB Assembly,Sub LGE 68719SM157D Contact Us For Availability
570
PCB Assembly LGE EBR32645103 Contact Us For Availability
590
Filter,AC Line LGE 6200J000115 Contact Us For Availability
600
Chassis Assembly LGE EBT32644903 Contact Us For Availability
601
Chassis Assembly LGE 31419SN904H Contact Us For Availability
601
BRACKET ASSEMBLY LGE 4811900021A Contact Us For Availability
602
SHIELD LGE 48149V0003B Contact Us For Availability
A
CONNECTOR ASSEMBLY LGE 6631T20031J Contact Us For Availability
A
PCB Assembly,Sub LGE 68719SM156B Contact Us For Availability
A
Chassis Assembly LGE EBT41354301 Contact Us For Availability
A
Box LGE 3890V01371U Contact Us For Availability
A
Box LGE MAY38995502 Contact Us For Availability
A
FIXER LGE 4972V00178A Contact Us For Availability
A
CONNECTOR ASSEMBLY LGE 6631900012D Contact Us For Availability
A
LGE 6631V39016G LGE 6631V39016G Contact Us For Availability
A
Cable,Assembly LGE 68509A0004E Contact Us For Availability
A
Harness,Single LGE EAD35682504 Contact Us For Availability
A
Manual,Owners LGE MFL34797040 Contact Us For Availability
A2
Remote Controller LGE 6710900010P Contact Us For Availability
A21
Cover LGE 3550V00590A Contact Us For Availability
AR2206
Resistor,Array LGE EBC32260405 Contact Us For Availability
C104
Capacitor,AL,Radial LGE 0CE4763F618 Contact Us For Availability
C1012
CAPACITOR,FIXED CERA LGE 0CK105CD56A Contact Us For Availability
C1041
CAPACITOR,FIXED CERA LGE 0CK475CC94A Contact Us For Availability
C1060
Capacitor,Ceramic,Chip LGE 0CH2122K516 Contact Us For Availability
C3057
Capacitor,Ceramic,Ch LGE 0CK106DC67A Contact Us For Availability
C4001
CAPACITOR,FIXED CERA LGE 0CK334CF56A Contact Us For Availability
C4008
CAPACITOR,FIXED CERA LGE 0CC270CK41A Contact Us For Availability
C4012
CAPACITOR,FIXED ELEC LGE 0CE227WF6DC Contact Us For Availability
C4015
CAPACITOR,FIXED CERA LGE 0CC221CK41A Contact Us For Availability
C4058
Capacitor,AL,Chip LGE EAE30840201 Contact Us For Availability
C4063
Capacitor,AL,Chip LGE EAE30840401 Contact Us For Availability
C4083
Capacitor,AL,Chip LGE EAE30840301 Contact Us For Availability
C4099
Capacitor,Ceramic,Chip LGE 0CK224CFG6A Contact Us For Availability
C4100
Capacitor,Ceramic,Chip LGE 0CK153CK51A Contact Us For Availability
C4101
Capacitor,Ceramic,Chip LGE 0CC561CK41A Contact Us For Availability
C4102
CAPACITOR,FIXED CERA LGE 0CK476FD67A Contact Us For Availability
C4138
CAPACITOR,FIXED ELECTROLYTIC LGE 0CE107WF6DC Contact Us For Availability
C4140
CAPACITOR,FIXED CERA LGE 0CK103CK56A Contact Us For Availability
C4143
Capacitor,Ceramic,Ch LGE 0CK225DD66A Contact Us For Availability
C5045
CAPACITOR,FIXED CERA LGE 0CK222CK56A Contact Us For Availability
C5062
Capacitor,Ceramic,Chip LGE 0CH2474F566 Contact Us For Availability
C5073
Capacitor,Ceramic,Ch LGE 0CK104BF56A Contact Us For Availability
C6012
CAPACITOR,FIXED ELEC LGE 0CE226WF6DC Contact Us For Availability
C6029
CAPACITOR,FIXED ELEC LGE 0CE476WH6DC Contact Us For Availability
C7021
CAPACITOR,FIXED CERA LGE 0CK225DH94A Contact Us For Availability
C7029
Capacitor,Ceramic,Chip LGE 0CK105DH56A Contact Us For Availability
C7038
Capacitor,Ceramic,Chip LGE 0CC470CK41A Contact Us For Availability
C7044
Capacitor,AL,Chip LGE 0CE106WH6DC Contact Us For Availability
C7045
Capacitor,AL,Chip LGE 0CE107WK6DC Contact Us For Availability
C7054
CAPACITOR,FIXED ELEC LGE 0CE106WFKDC Contact Us For Availability
C7151
CAPACITOR,FIXED CERA LGE 0CK104CK56A Contact Us For Availability
C7154
Capacitor,Ceramic,Ch LGE 0CK474DK56A Contact Us For Availability
C7158
CAPACITOR,FIXED ELEC LGE 0CE227WJ6DC Contact Us For Availability
D4001
DIODE,RECTIFIERS LGE 0DRSE00038A Contact Us For Availability
D4006
LED LGE 0DL233309AC Contact Us For Availability
D4007
DIODE,RECTIFIER LGE 0DR340009AA Contact Us For Availability
D4008
DIODE,SWITCHING LGE 0DSIH00018A Contact Us For Availability
D5015
DIODE,ZENERS LGE 0DZRM00178A Contact Us For Availability
D7004
DIODE,ZENERS LGE 0DZRM00218A Contact Us For Availability
IC1001
IC,Data Controller LGE 0IPRP00702A Contact Us For Availability
IC2002
IC,SDRAM LGE 0IMMRIH038B Contact Us For Availability
IC3001
IC,Analog Switch LGE EAN30267601 Contact Us For Availability
IC4001
IC,Tx/Rx LGE EAN39038801 Contact Us For Availability
IC4006
IC,PERIPHERALS LGE 0IPRPFA015B Contact Us For Availability
IC4008
IC,LDO Voltage Regul LGE 0IPMGS1006B Contact Us For Availability
IC4010
IC,KEC LGE 0IKE702900G Contact Us For Availability
IC4011
IC,MICRO CONTROLLER LGE 0IMCRRH001A Contact Us For Availability
IC4012
IC,MICRO CONTROLLER LGE 0IMCRAL021A Contact Us For Availability
IC4014
IC,MICRO CONTROLLER LGE 0IMCRAL006A Contact Us For Availability
IC4016
IC,Voltage Regulator LGE EAN32662801 Contact Us For Availability
IC4017
IC,DC,DC Converter LGE EAN31513601 Contact Us For Availability
IC4018
IC,POWER MANAGEMENT LGE 0IPMG78391A Contact Us For Availability
IC5001
IC,Analog Switch LGE EAN30744301 Contact Us For Availability
IC5002
IC,Analog Switch LGE EAN30744401 Contact Us For Availability
IC5003
IC,SONY LGE 0ISO206900A Contact Us For Availability
IC5004
IC,PERIPHERALS LGE 0IPRPCI016A Contact Us For Availability
IC6002
IC,PERIPHERALS LGE 0IPRPNS054A Contact Us For Availability
IC6003
IC,MITSUBISHI LGE 0IMI623200B Contact Us For Availability
IC6004
IC,MICRO CONTROLLER LGE 0IMCRTH002A Contact Us For Availability
IC6006
IC,POWER MANAGEMENT LGE 0IPMGKE032A Contact Us For Availability
IC7001
IC,CRYSTAL SEMICONDUCTOR LGE 0ICB533100A Contact Us For Availability
IC7005
IC,MEMORIES LGE 0IMMRCS012B Contact Us For Availability
IC7013
IC,EEPROM LGE 0IMMRAL014D Contact Us For Availability
IC7015
IC,Receiver LGE 0IPRP00623A Contact Us For Availability
IC7017
IC,Audio Amplifier LGE 0IPRP00700A Contact Us For Availability
J4001
Jack,Complex LGE 6612J10024A Contact Us For Availability
J4004
JACK,PHONE LGE 6612F00099A Contact Us For Availability
J5007
Jack,RCA LGE 6612J10006K Contact Us For Availability
L2001
Filter,Bead LGE EAM38769502 Contact Us For Availability
L4007
FILTER(CIRC),EMC LGE 6200J000123 Contact Us For Availability
L4019
INDUCTOR,CHIP LGE 0LC2000005K Contact Us For Availability
L4021
Filter,Bead LGE 6210TCE001E Contact Us For Availability
L4022
COIL,CHOKE LGE 6140TBZ047B Contact Us For Availability
L7026
FILTER(CIRC),EMC LGE 0LCML00003B Contact Us For Availability
L7032
COIL,ENERGY RECOVERY LGE 6140VR0008A Contact Us For Availability
L7044
FILTER(CIRC),EMC LGE 6210TCE001S Contact Us For Availability
LD101
LED LGE 0DL200000CA Contact Us For Availability
P7004
CONNECTOR (CIRC),D-S LGE 6630G70016A Contact Us For Availability
PA101
REMOTE CONTROLLER RE LGE 6712000011B Contact Us For Availability
R6066
Resistor,Carbon Film LGE 0RD0272H609 Contact Us For Availability
SW105
SWITCH TACT LGE 140-313B Contact Us For Availability
TU4001
Tuner,Analog/Digital LGE EBL32758001 Contact Us For Availability
VR7002
VARISTOR LGE 6102W5V016A Contact Us For Availability
X7001
CRYSTAL LGE 6202TST001A Contact Us For Availability
ZD1001
Diode,Zener LGE 0DZDI00078A Contact Us For Availability
× ![]()
