Model LG Z42LC2DA – Common Parts & Diagrams
Diagram 0
Diagram 1
Common parts from model LG Z42LC2DA
5
Screw,Taptite LGE FAB30013210 Contact Us For Availability
020
LCD(LIQUID CRYSTAL D LGE 6304FLP363A Contact Us For Availability
020
LCD,Module-TFT LGE EAJ31412701 Contact Us For Availability
030
Cover Assembly,Rear LGE ACQ31676314 Contact Us For Availability
040
Base Assembly LGE 3043900034U Contact Us For Availability
050
PWB(PCB) ASSEMBLY,SU LGE 68719ST913A Contact Us For Availability
061
Speaker,Tweeter LGE EAB30825601 Contact Us For Availability
070
PCB Assembly,Sub LGE 68719ST914B Contact Us For Availability
080
Cover Assembly LGE 35519K0030C Contact Us For Availability
090
Plate Assembly LGE 49519S0036X Contact Us For Availability
100
FILTER(CIRC),EMC LGE 6200J000152 Contact Us For Availability
110
SMPS LGE 6709900017C Contact Us For Availability
120
Chassis Assembly LGE EBT30604801 Contact Us For Availability
130
PCB Assembly,Sub LGE 68719STA37B Contact Us For Availability
140
Plate LGE 49509K0173R Contact Us For Availability
150
COVER LGE 35509K0197A Contact Us For Availability
200N
Inverter Assembly LGE EAY40322401 Contact Us For Availability
200N
Inverter Assembly LGE EAY40323101 Contact Us For Availability
200T
Time Control LGE EAT40320101 Contact Us For Availability
200T
Time Control LGE EAT40320001 Contact Us For Availability
201N
Inverter Assembly LGE EAY40322501 Contact Us For Availability
201N
Inverter Assembly LGE EAY40323201 Contact Us For Availability
A1
Manual LGE 38289U0527H Contact Us For Availability
A2
Remote Controller LGE 6710900010P Contact Us For Availability
A3
Power Cord LGE 6410TUW007A Contact Us For Availability
A21
Cover LGE 3550V00590A Contact Us For Availability
AR3021
Resistor,Array LGE 0RJ1001C687 Contact Us For Availability
AR6004
Resistor,Chip LGE 0RJ0222C692 Contact Us For Availability
AR7002
Filter,Bead LGE EAM38769509 Contact Us For Availability
C1
Harness,Single LGE 6631900121B Contact Us For Availability
C2
Harness,Single LGE 6631900120B Contact Us For Availability
C3
CONNECTOR ASSEMBLY LGE 6631900048A Contact Us For Availability
C5
CONNECTOR ASSEMBLY LGE 6631900012E Contact Us For Availability
C6
CONNECTOR ASSEMBLY LGE 6631T25020L Contact Us For Availability
C7
CONNECTOR ASSEMBLY LGE 6631T25019T Contact Us For Availability
C8
CONNECTOR ASSEMBLY LGE 6631T20020V Contact Us For Availability
C9
Harness,Single LGE 6631900013J Contact Us For Availability
C10
Cable,Assembly LGE EAD54642601 Contact Us For Availability
C11
CONNECTOR ASSEMBLY LGE 6631T20041A Contact Us For Availability
C12
CONNECTOR ASSEMBLY LGE 6631T11020Z Contact Us For Availability
C13
CONNECTOR ASSEMBLY LGE 6631900092B Contact Us For Availability
C102
Capacitor,Ceramic,Chip LGE 0CH5101K416 Contact Us For Availability
C103
Capacitor,AL,Chip LGE EAE34990901 Contact Us For Availability
C1057
CAPACITOR,FIXED CERA LGE 0CK103CK56A Contact Us For Availability
C1061
Capacitor,Ceramic,Chip LGE 0CH2122K516 Contact Us For Availability
C2014
Capacitor,Ceramic,Ch LGE 0CK104BF56A Contact Us For Availability
C2032
CAPACITOR,FIXED CERA LGE 0CK105CD56A Contact Us For Availability
C3054
CAPACITOR,FIXED CERA LGE 0CK475CC94A Contact Us For Availability
C3057
Capacitor,Ceramic,Ch LGE 0CK106DC67A Contact Us For Availability
C4003
CAPACITOR,FIXED CERA LGE 0CK334CF56A Contact Us For Availability
C4008
CAPACITOR,FIXED CERA LGE 0CC270CK41A Contact Us For Availability
C4014
CAPACITOR,FIXED CERA LGE 0CC221CK41A Contact Us For Availability
C4032
CAPACITOR,FIXED ELECTROLYTIC LGE 0CE107WF6DC Contact Us For Availability
C4063
Capacitor,AL,Chip LGE EAE30840401 Contact Us For Availability
C4080
Capacitor,AL,Chip LGE EAE30840201 Contact Us For Availability
C4083
Capacitor,AL,Chip LGE EAE30840301 Contact Us For Availability
C4100
Capacitor,Ceramic,Chip LGE 0CK153CK51A Contact Us For Availability
C4101
Capacitor,Ceramic,Chip LGE 0CC561CK41A Contact Us For Availability
C4102
CAPACITOR,FIXED CERA LGE 0CK476FD67A Contact Us For Availability
C4113
CAPACITOR,FIXED CERA LGE 0CK104CK56A Contact Us For Availability
C5016
Capacitor,Ceramic,Chip LGE 0CK105DH56A Contact Us For Availability
C5030
CAPACITOR,CHIP[AL. E LGE 0CH8226F691 Contact Us For Availability
C5033
CAPACITOR,FIXED ELEC LGE 0CE476WH6DC Contact Us For Availability
C5044
CAPACITOR,FIXED ELEC LGE 0CE227WF6DC Contact Us For Availability
C5045
CAPACITOR,FIXED CERA LGE 0CK222CK56A Contact Us For Availability
C5075
CAPACITOR,CHIP[AL. E LGE 0CH8106F691 Contact Us For Availability
C5108
Capacitor,Ceramic,Chip LGE 0CH2474F566 Contact Us For Availability
C7002
CAPACITOR,FIXED ELEC LGE 0CE226WF6DC Contact Us For Availability
C7007
Capacitor,Ceramic,Chip LGE 0CC470CK41A Contact Us For Availability
C7041
CAPACITOR,FIXED CERA LGE 0CK225DH94A Contact Us For Availability
C7042
Capacitor,Ceramic,Chip LGE 0CK224CFG6A Contact Us For Availability
C7044
Capacitor,AL,Chip LGE 0CE106WH6DC Contact Us For Availability
C7045
Capacitor,AL,Chip LGE 0CE107WK6DC Contact Us For Availability
C7095
CAPACITOR,FIXED ELEC LGE 0CE106WFKDC Contact Us For Availability
C7099
Capacitor,Ceramic,Chip LGE 0CH5220K416 Contact Us For Availability
C7154
Capacitor,Ceramic,Ch LGE 0CK474DK56A Contact Us For Availability
C7159
CAPACITOR,FIXED ELEC LGE 0CE227WJ6DC Contact Us For Availability
D4002
DIODE,RECTIFIERS LGE 0DRSE00038A Contact Us For Availability
D4006
LED LGE 0DL233309AC Contact Us For Availability
D4007
DIODE,RECTIFIER LGE 0DR340009AA Contact Us For Availability
D4008
DIODE,SWITCHING LGE 0DSIH00018A Contact Us For Availability
D5015
DIODE,ZENERS LGE 0DZRM00178A Contact Us For Availability
IC1001
IC,Data Controller LGE 0IPRP00702A Contact Us For Availability
IC2003
IC,MEMORIES LGE 0IMMRHY060B Contact Us For Availability
IC2003
IC,DDR SDRAM LGE 0IMMRHY057E Contact Us For Availability
IC3001
IC,Analog Switch LGE EAN30267601 Contact Us For Availability
IC4001
IC,PERIPHERALS LGE 0IPRP00009A Contact Us For Availability
IC4004
IC,KEC LGE 0IKE702900G Contact Us For Availability
IC4006
IC,PERIPHERALS LGE 0IPRPFA015B Contact Us For Availability
IC4007
IC,STANDARD LOGIC LGE 0ISTLPH026A Contact Us For Availability
IC4008
IC,LDO Voltage Regul LGE 0IPMGS1006B Contact Us For Availability
IC4011
IC,MICRO CONTROLLER LGE 0IMCRRH001A Contact Us For Availability
IC4012
IC,MICRO CONTROLLER LGE 0IMCRAL021A Contact Us For Availability
IC4014
IC,MICRO CONTROLLER LGE 0IMCRAL006A Contact Us For Availability
IC4016
IC,MICRO CONTROLLER LGE 0IMCRFA010A Contact Us For Availability
IC4017
IC,DC,DC Converter LGE EAN31513601 Contact Us For Availability
IC5001
IC,Analog Switch LGE EAN30744301 Contact Us For Availability
IC5002
IC,Analog Switch LGE EAN30744401 Contact Us For Availability
IC5003
IC,SONY LGE 0ISO206900A Contact Us For Availability
IC5004
IC,PERIPHERALS LGE 0IPRPCI016A Contact Us For Availability
IC6004
IC,MICRO CONTROLLER LGE 0IMCRTH002A Contact Us For Availability
IC7001
IC,CRYSTAL SEMICONDUCTOR LGE 0ICB533100A Contact Us For Availability
IC7004
IC,PERIPHERALS LGE 0IPRP00696A Contact Us For Availability
IC7005
IC,MEMORIES LGE 0IMMRCS012B Contact Us For Availability
IC7010
IC,EEPROM LGE 0IMMRAL014D Contact Us For Availability
IC7015
IC,Receiver LGE 0IPRP00623A Contact Us For Availability
IC7017
IC,Audio Amplifier LGE 0IPRP00700A Contact Us For Availability
J4002
Jack,Complex LGE 6612J10024A Contact Us For Availability
J4003
JACK,PHONE LGE 6612F00099A Contact Us For Availability
J5007
Jack,RCA LGE 6612J10006K Contact Us For Availability
JK100
Jack,Fiber Optic LGE EAG32151101 Contact Us For Availability
JK101
JACK,RCA LGE 6612J10033A Contact Us For Availability
L2001
Filter,Bead LGE EAM38769502 Contact Us For Availability
L3002
INDUCTOR,CHIP LGE 0LC0233002A Contact Us For Availability
L4004
Filter,Bead LGE 6210TCE001E Contact Us For Availability
L4004
Filter,Bead LGE EAM42641602 Contact Us For Availability
L4007
FILTER(CIRC),EMC LGE 6200J000123 Contact Us For Availability
L4022
COIL,CHOKE LGE 6140TBZ047B Contact Us For Availability
L5003
Filter,Bead LGE EAM38769501 Contact Us For Availability
L7008
INDUCTOR,CHIP LGE 0LCML00020B Contact Us For Availability
L7025
FILTER(CIRC),EMC LGE 0LCML00003B Contact Us For Availability
L7029
COIL,ENERGY RECOVERY LGE 6140VR0008A Contact Us For Availability
L7039
Filter,Bead LGE EAM38769505 Contact Us For Availability
L7039
FILTER(CIRC),EMC LGE 6210TCE001S Contact Us For Availability
LED1
LED LGE 0DL200000CA Contact Us For Availability
P101
CONNECTOR (CIRC),WAF LGE 6602T20009J Contact Us For Availability
P102
CONNECTOR (CIRC),WAF LGE 6602T20009C Contact Us For Availability
P4003
WAFER LGE 6602T25008J Contact Us For Availability
P4004
WAFER LGE 6602T25008M Contact Us For Availability
P4005
CONNECTOR (CIRC),WAF LGE 6602T25008L Contact Us For Availability
P7004
CONNECTOR (CIRC),D-S LGE 6630G70016A Contact Us For Availability
P7010
Connector,Wafer LGE 6602T25008B Contact Us For Availability
Q5005
TRANSISTOR LGE 0TR150400BA Contact Us For Availability
Q7009
TRANSISTOR,BIPOLARS LGE 0TRIY80001A Contact Us For Availability
R101
RESISTOR CHIP 1.2K 1/10W 5 D. LGE 0RH1201D622 Contact Us For Availability
R105
RESISTOR CHIP 3.3K 1/10W 5 D. LGE 0RH3301D622 Contact Us For Availability
R105
RESISTOR CHIP 200 1/10W 5 TA C LGE 0RH2000D622 Contact Us For Availability
R1006
RESISTOR,METAL GLAZE LGE 0RJ2000D477 Contact Us For Availability
R1008
RESISTOR,METAL GLAZE LGE 0RJ0102D677 Contact Us For Availability
R1021
Resistor,Chip LGE 0RJ0562D477 Contact Us For Availability
R1046
RESISTOR,METAL GLAZE LGE 0RJ4990D477 Contact Us For Availability
R1047
Resistor,Chip LGE 0RH1504D622 Contact Us For Availability
R1085
Resistor,Chip LGE 0RJ0271D677 Contact Us For Availability
R1132
Resistor,Chip LGE 0RJ0752C678 Contact Us For Availability
R1137
RESISTOR,METAL GLAZE LGE 0RJ0392D677 Contact Us For Availability
R1159
Resistor,Chip LGE 0RJ3601D677 Contact Us For Availability
R1161
Resistor,Chip LGE 0RJ1001C678 Contact Us For Availability
R2022
Resistor,Chip LGE 0RJ0222C678 Contact Us For Availability
R3006
RESISTOR,METAL GLAZE LGE 0RJ2701C678 Contact Us For Availability
R3015
Resistor,Chip LGE 0RJ1501D477 Contact Us For Availability
R3017
RESISTOR,METAL GLAZE LGE 0RJ3000D677 Contact Us For Availability
R3030
RESISTOR,METAL GLAZE LGE 0RJ1001D677 Contact Us For Availability
R3127
Resistor,Chip LGE 0RJ4701C678 Contact Us For Availability
R3130
Resistor,Chip LGE 0RJ0000C678 Contact Us For Availability
R4015
RESISTOR,METAL GLAZE LGE 0RJ1202D677 Contact Us For Availability
R4048
RESISTOR,METAL GLAZE LGE 0RJ4300D677 Contact Us For Availability
R4090
RESISTOR,METAL GLAZE LGE 0RJ1502D677 Contact Us For Availability
R4137
Resistor,Chip LGE 0RJ6802D677 Contact Us For Availability
R4174
RESISTOR,METAL GLAZE LGE 0RJ1001D477 Contact Us For Availability
R5027
RESISTOR,METAL GLAZE LGE 0RJ1003D677 Contact Us For Availability
R5035
Resistor,Chip LGE 0RJ7500D677 Contact Us For Availability
R5055
RESISTOR,METAL GLAZE LGE 0RJ2200D677 Contact Us For Availability
R5105
Resistor,Chip LGE 0RJ2201D677 Contact Us For Availability
R5111
RESISTOR,METAL GLAZE LGE 0RJ4703D677 Contact Us For Availability
R5121
RESISTOR,METAL GLAZE LGE 0RJ0752D677 Contact Us For Availability
R5128
RESISTOR,METAL GLAZE LGE 0RJ2701D677 Contact Us For Availability
R7008
RESISTOR,METAL GLAZE LGE 0RJ2700D677 Contact Us For Availability
R7009
RESISTOR,METAL GLAZE LGE 0RJ0222D677 Contact Us For Availability
R7030
Resistor,Chip LGE 0RJ1002C678 Contact Us For Availability
R7043
RESISTOR,METAL GLAZE LGE 0RJ3900D677 Contact Us For Availability
R7058
RESISTOR,METAL GLAZE LGE 0RJ0682D677 Contact Us For Availability
R7059
Resistor,Chip LGE 0RJ0332C678 Contact Us For Availability
R7084
Resistor,Chip LGE 0RJ6801D677 Contact Us For Availability
R7220
Resistor,Chip LGE 0RJ0182D677 Contact Us For Availability
R7242
RESISTOR,METAL GLAZE LGE 0RJ1002D677 Contact Us For Availability
TU4001
Tuner,Analog/Digital LGE EBL32758001 Contact Us For Availability
X7001
CRYSTAL LGE 6202TST001A Contact Us For Availability
ZD1001
Diode,Zener LGE 0DZDI00078A Contact Us For Availability
ZD7002
DIODE,ZENERS LGE 0DZRM00218A Contact Us For Availability
× ![]()
Login and Registration Form
