Model Electrolux WGF323BADE RANGE – Common Parts &amp; Diagrams

*77523

SCREW, CUP PT, 8-18 X 3/8 WCI 316021108 Contact Us For Availability

*77528

SCREW, CR PAN HD SEMS, 8-32BP X 1.00 WCI 5303212671 Contact Us For Availability

*77529

5303271648 Frigidaire Oven Screw Backorder WCI 5303271648 $10.50

*77530

WCI 5303280311 WCI 5303280311 Contact Us For Availability

*77531

5303285179 Frigidaire Oven Door Screw Backorder WCI 5303285179 $10.53

*77532

131243700 Frigidaire Screw In Stock WCI 131243700 $2.65

1

DRAWER-BROILER WCI 3018608 Contact Us For Availability

2

LINER, BROILER DOOR WCI 3202803 Contact Us For Availability

3

WCI 316067802 WCI 316067802 Contact Us For Availability

3A

WCI 316032001 WCI 316032001 Contact Us For Availability

4

SCREW, HEX WASHER HEAD, 8-18(AB) X 1/2 (NOT I WCI 08067785 Contact Us For Availability

4

WCI 316067204 WCI 316067204 Contact Us For Availability

4

WCI 316056206 WCI 316056206 Contact Us For Availability

4

WCI 316089000 WCI 316089000 Contact Us For Availability

5

FASTENER-SPACER, PUSH-IN NUT, NYLON WCI 3131387 Contact Us For Availability

5A

SCREW-LEVELING WCI 5303203397 Contact Us For Availability

5B

WCI 3934058 WCI 3934058 Contact Us For Availability

5C

316116000 Frigidaire Screw Backorder WCI 316116000 $9.40

5D

NUT, T,TYPE, LEVELING SCREW (NOT ILLUSTRATED) WCI 5303288460 Contact Us For Availability

6

316067902 Frigidaire Oven Rack Backorder WCI 316067902 $73.09

6

WCI 316088403 WCI 316088403 Contact Us For Availability

7

GLIDE-BROILER WCI 3018610 No Longer Available

7

WCI 316076401 WCI 316076401 Contact Us For Availability

7A

Hinge,oven door ,(2) WCI 316007001 Contact Us For Availability

7B

3203010 Frigidaire Clip Backorder WCI 3203010 $11.64

8

WCI 316088600 WCI 316088600 Contact Us For Availability

8

NUT, PUSH-ON, (2) WCI 3131386 Contact Us For Availability

8A

PANEL-OVEN BOTTOM WCI 5303212540 Contact Us For Availability

8B

316064600 Frigidaire Oven Support Backorder WCI 316064600 $13.86

9

PAN-BROILER WCI 5303013568 Contact Us For Availability

9

WCI 316066610 WCI 316066610 Contact Us For Availability

5304506426 Frigidaire Oven Top Rear Burner In Stock WCI 5304506426 $69.81

5304506427 Frigidaire Oven Range Surface Burn In Stock WCI 5304506427 $72.75

SCREW-HANDLE MTG, WAFER HEAD, 10-24(F) X 3 WCI 5303281378 Contact Us For Availability

WCI 5303131356 WCI 5303131356 Contact Us For Availability

11

WCI 316066300 WCI 316066300 Contact Us For Availability

11

WCI 316066301 WCI 316066301 Contact Us For Availability

3016993 Frigidaire Oven Retainer Backorder WCI 3016993 $64.37

5303202011 Frigidaire Door Seal Backorder WCI 5303202011 $122.03

SPRING-BROILER, LH WCI 3018618 Contact Us For Availability

SPRING-BROILER, RH WCI 3018619 Contact Us For Availability

13

CHANNEL-BROILER WCI 3131153 Contact Us For Availability

14

316116400 Frigidaire Oven Light Socket In Stock WCI 316116400 $49.48

14

PLUG-BUTTON, GLIDE WCI 3206216 Contact Us For Availability

14A

WCI 316082900 WCI 316082900 Contact Us For Availability

14B

316021104 Frigidaire Oven Screw Assembly Backorder WCI 316021104 $6.09

15

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $22.72

16

MAIN TOP, ALMOND WCI 3131455 Contact Us For Availability

17

3203459 Frigidaire Oven Range Dual Gas Safety In Stock WCI 3203459 $135.09

17

WCI 316066900 WCI 316066900 Contact Us For Availability

18

BRACKET-HINGE,MAIN TOP LH WCI 08067746 Contact Us For Availability

18

WCI 3131439 WCI 3131439 Contact Us For Availability

18

BRACKET-HINGE,MAIN TOP RH WCI 08067747 Contact Us For Availability

20

WCI 316088900 WCI 316088900 Contact Us For Availability

21

Backorder WCI 154079601 $0.34

21

SPACER-BODYSIDE, (8) WCI 3014099 Contact Us For Availability

27

5303284616 Frigidaire Range Bulb Clip Thermos In Stock WCI 5303284616 $7.92

29

BUTTON-SELECTOR, CLOCK/TIMER, BLACK WCI 5303272305 Contact Us For Availability

29

WCI 3018614 WCI 3018614 Contact Us For Availability

30

INSULATION, BROILER DRAWER WCI 5303131258 Contact Us For Availability

32

WCI 3203441 WCI 3203441 Contact Us For Availability

33

WCI 316055601 WCI 316055601 Contact Us For Availability

34

WCI 3018607 WCI 3018607 Contact Us For Availability

35

316542102 Frigidaire Flue Gasket Backorder WCI 316542102 $8.85

36

KNOB-TOP VALVE, (4) WCI 316009008 No Longer Available

36

WCI 316083000 WCI 316083000 Contact Us For Availability

36

WCI 3131904 WCI 3131904 Contact Us For Availability

39

WCI 316019507 WCI 316019507 Contact Us For Availability

39

HANDLE-DOOR, BLACK, OVEN WCI 5303273127 Contact Us For Availability

39A

5304534377 Frigidaire Cord Backorder WCI 5304534377 $19.63

39B

WCI 08067961 WCI 08067961 Contact Us For Availability

41

WCI 3131570 WCI 3131570 Contact Us For Availability

43

316282700 Frigidaire Oven Screw Backorder WCI 316282700 $7.74

49

316137003 Frigidaire Range End Cap Backorder WCI 316137003 $35.50

52

WCI 316081303 WCI 316081303 Contact Us For Availability

54

WCI 5303271606 WCI 5303271606 Contact Us For Availability

58

INSULATION, OVEN WRAPPER WCI 3017142 Contact Us For Availability

58

INSULATION, OVEN BACK WCI 3203541 Contact Us For Availability

60

COVER-OVEN FRONT WCI 5303015372 Contact Us For Availability

73

WCI 5303281627 WCI 5303281627 Contact Us For Availability

93

WCI 316055501 WCI 316055501 Contact Us For Availability
