Model LG WG1204R WINDOW – Common Parts & Diagrams
Diagram 0
Diagram 1
Common parts from model LG WG1204R WINDOW
135312
GRILLE ASSEMBLY,FRONT(SINGLE) LGE 3531A21008A Contact Us For Availability
135313
GRILLE,INLET LGE 3530A10182A Contact Us For Availability
137215
PANEL,CONTROL LGE 3720A10003A Contact Us For Availability
147581
LOUVER,HORIZONTAL LGE 4758A20051A Contact Us For Availability
238310
ESCUTCHEON LGE 3831A20034X Contact Us For Availability
249950
CONTROL BOX ASSEMBLY,SINGLE LGE 4995A20326H Contact Us For Availability
263230
THERMISTOR ASSY LGE 6323A20003D Contact Us For Availability
264110
POWER CORD ASSY LGE 2H00677S Contact Us For Availability
267110
REMOTE CONTROLLER ASSY LGE 6711A20034A Contact Us For Availability
268712
PWB(PCB) ASSEMBLY,DISPLAY LGE 6871A20195D Contact Us For Availability
268714
PWB(PCB) ASSEMBLY,MAIN(AC) LGE 6871A20188F Contact Us For Availability
349001
DAMPER LGE 4900AR7024B Contact Us For Availability
349480
ORIFICE LGE 4948A10005A Contact Us For Availability
349600
MOUNT,MOTOR LGE 4960A20005A Contact Us For Availability
352111
LGE 5210A20248A LGE 5210A20248A Contact Us For Availability
352380
AIR GUIDE LGE 5238A20001A Contact Us For Availability
352390
AIR GUIDE ASSY LGE 5239AR1523K Contact Us For Availability
354210
EVAPORATOR ASSY,FIRST LGE 5421AR2910D Contact Us For Availability
554160
COMPRESSOR SET LGE 2520UKGC2BB Contact Us For Availability
W0CZZ
CAPACITOR,DRAWING LGE 0CZZA20001N Contact Us For Availability
× ![]()
