Model GE TBX22ZPKRWH Refrigerator – Common Parts & Diagrams
0
1
2
Common parts from model GE TBX22ZPKRWH Refrigerator
1
GEN SR2612 GEN SR2612 Contact Us For Availability
3
GEN WR02X3757 GEN WR02X3757 Contact Us For Availability
4
GEN WR77X0519 GEN WR77X0519 Contact Us For Availability
5
GEN WR12X0561 GEN WR12X0561 Contact Us For Availability
6
STIFFENER HANDLE GEN WR12X0574 Contact Us For Availability
7
GEN WR12X0598 GEN WR12X0598 Contact Us For Availability
8
SHIM DOOR HANDLE WHITE GEN WR02X8089 Contact Us For Availability
12
CHANNEL HANDLE FRZ GEN WR12X0572 Contact Us For Availability
13
GEN WR02X7787 GEN WR02X7787 Contact Us For Availability
14
SHIM HANDLE DOOR GEN WR02X7789 Contact Us For Availability
15
GEN WR02X8259 GEN WR02X8259 Contact Us For Availability
16
GEN WR01X1724 GEN WR01X1724 Contact Us For Availability
24
GEN WR17X2237 GEN WR17X2237 Contact Us For Availability
25
GEN WR17X2239 GEN WR17X2239 Contact Us For Availability
26
GEN WR02X7681 GEN WR02X7681 Contact Us For Availability
28
GEN WR02X7627 GEN WR02X7627 Contact Us For Availability
29
GEN WR02X8087 GEN WR02X8087 Contact Us For Availability
30
SCREW GEN WR01X5475 Contact Us For Availability
32
GEN WR72X0103 GEN WR72X0103 Contact Us For Availability
33
GEN WR72X0102 GEN WR72X0102 Contact Us For Availability
34
GEN WR01X1764 GEN WR01X1764 Contact Us For Availability
35
GEN WR12X0715 GEN WR12X0715 Contact Us For Availability
40
GEN WR02X7858 GEN WR02X7858 Contact Us For Availability
40
GEN WR02X8482 GEN WR02X8482 Contact Us For Availability
100
GEN WR02X7688 GEN WR02X7688 Contact Us For Availability
103
GEN WR77X0517 GEN WR77X0517 Contact Us For Availability
107
GEN WR22X0350 GEN WR22X0350 Contact Us For Availability
107
GEN WR22X0374 GEN WR22X0374 Contact Us For Availability
109
GEN WR71X2148 GEN WR71X2148 Contact Us For Availability
111
GEN WR02X7610 GEN WR02X7610 Contact Us For Availability
112
NAMEPLATE DR RSV(WH) GEN WR04X0180 Contact Us For Availability
113
GEN WR02X7611 GEN WR02X7611 Contact Us For Availability
115
GEN WR17X2238 GEN WR17X2238 Contact Us For Availability
118
GEN WR19X5003 GEN WR19X5003 Contact Us For Availability
121
GEN WR12X0713 GEN WR12X0713 Contact Us For Availability
123
GEN WR02X7615 GEN WR02X7615 Contact Us For Availability
124
GEN WR12X0721 GEN WR12X0721 Contact Us For Availability
125
GEN WR04X0193 GEN WR04X0193 Contact Us For Availability
125
GEN WR12X0575 GEN WR12X0575 Contact Us For Availability
128
GEN WR02X7983 GEN WR02X7983 Contact Us For Availability
156
GEN WR32X1144 GEN WR32X1144 Contact Us For Availability
157
GEN WR32X1190 GEN WR32X1190 Contact Us For Availability
199
GEN WR02X7670 GEN WR02X7670 Contact Us For Availability
201
GEN WR17X2228 GEN WR17X2228 Contact Us For Availability
202
GEN WR02X7019 GEN WR02X7019 Contact Us For Availability
203
GEN WR14X0352 GEN WR14X0352 Contact Us For Availability
204
GEN WR02X7822 GEN WR02X7822 Contact Us For Availability
204
GEN WR02X7823 GEN WR02X7823 Contact Us For Availability
206
GEN WR71X2029 GEN WR71X2029 Contact Us For Availability
207
GEN WR17X2164 GEN WR17X2164 Contact Us For Availability
208
GEN WR38X1134 GEN WR38X1134 Contact Us For Availability
209
GEN WR02X7015 GEN WR02X7015 Contact Us For Availability
210
GEN WR02X6261 GEN WR02X6261 Contact Us For Availability
212
GEN WR30X0286 GEN WR30X0286 Contact Us For Availability
215
GEN WR32X0898 GEN WR32X0898 Contact Us For Availability
219
GEN WR51X0318 GEN WR51X0318 Contact Us For Availability
226
GEN WR02X7640 GEN WR02X7640 Contact Us For Availability
228
GEN WR38X1673 GEN WR38X1673 Contact Us For Availability
229
GEN WR71X2190 GEN WR71X2190 Contact Us For Availability
230
GEN WR32X1207 GEN WR32X1207 Contact Us For Availability
231
GEN WR02X8424 GEN WR02X8424 Contact Us For Availability
231
GEN WR38X1657 GEN WR38X1657 Contact Us For Availability
232
GEN WR72X0096 GEN WR72X0096 Contact Us For Availability
233
GEN WR02X7018 GEN WR02X7018 Contact Us For Availability
233
GEN WR72X0097 GEN WR72X0097 Contact Us For Availability
236
PAN MEAT GEN WR32X0928 Contact Us For Availability
237
GEN WR17X2797 GEN WR17X2797 Contact Us For Availability
237
GEN WR17X2798 GEN WR17X2798 Contact Us For Availability
238
GEN WR17X2400 GEN WR17X2400 Contact Us For Availability
239
GEN WR14X0343 GEN WR14X0343 Contact Us For Availability
239
GEN WR14X0389 GEN WR14X0389 Contact Us For Availability
239
GEN WR72X0174 GEN WR72X0174 Contact Us For Availability
239
SLIDE VEG PAN SIDE R/S GEN WR72X0176 Contact Us For Availability
239
SLIDE VEG PAN SIDE L/S GEN WR72X0177 Contact Us For Availability
240
GEN WR32X1158 GEN WR32X1158 Contact Us For Availability
241
GEN WR14X0371 GEN WR14X0371 Contact Us For Availability
241
GEN WR17X2866 GEN WR17X2866 Contact Us For Availability
242
GEN WR32X1187 GEN WR32X1187 Contact Us For Availability
243
GEN WR32X1126 GEN WR32X1126 Contact Us For Availability
244
GEN WR17X2256 GEN WR17X2256 Contact Us For Availability
246
GEN WR17X2532 GEN WR17X2532 Contact Us For Availability
247
GEN WR17X2536 GEN WR17X2536 Contact Us For Availability
249
SUPPORT TWIST VP CVR GEN WR02X8379 Contact Us For Availability
250
GEN WR17X2843 GEN WR17X2843 Contact Us For Availability
253
GEN WR02X8446 GEN WR02X8446 Contact Us For Availability
256
GEN WR23X0309 GEN WR23X0309 Contact Us For Availability
260
GEN WR02X7773 GEN WR02X7773 Contact Us For Availability
261
GEN WR02X6087 GEN WR02X6087 Contact Us For Availability
263
GEN WR14X0400 GEN WR14X0400 Contact Us For Availability
263
GEN WR38X1590 GEN WR38X1590 Contact Us For Availability
265
GEN WR01X1774 GEN WR01X1774 Contact Us For Availability
266
GEN WR30X0288 GEN WR30X0288 Contact Us For Availability
267
GEN WR82X0320 GEN WR82X0320 Contact Us For Availability
268
GEN WR01X1805 GEN WR01X1805 Contact Us For Availability
269
GEN WR01X1803 GEN WR01X1803 Contact Us For Availability
275
GEN WR13X0626 GEN WR13X0626 Contact Us For Availability
276
GEN WR13X0585 GEN WR13X0585 Contact Us For Availability
277
GEN WR17X2236 GEN WR17X2236 Contact Us For Availability
279
GEN WR13X0587 GEN WR13X0587 Contact Us For Availability
280
GEN WR02X7656 GEN WR02X7656 Contact Us For Availability
282
GEN WR13X0596 GEN WR13X0596 Contact Us For Availability
283
GEN WR02X8457 GEN WR02X8457 Contact Us For Availability
284
GEN WR02X8069 GEN WR02X8069 Contact Us For Availability
287
GEN WR02X8381 GEN WR02X8381 Contact Us For Availability
288
GEN WR02X7646 GEN WR02X7646 Contact Us For Availability
288
GEN WR74X0202 GEN WR74X0202 Contact Us For Availability
295
GEN WR23X0315 GEN WR23X0315 Contact Us For Availability
296
GEN WR02X8444 GEN WR02X8444 Contact Us For Availability
297
GEN WR72X0099 GEN WR72X0099 Contact Us For Availability
297
GEN WR72X0100 GEN WR72X0100 Contact Us For Availability
297
GEN WR72X0108 GEN WR72X0108 Contact Us For Availability
297
GEN WR72X0109 GEN WR72X0109 Contact Us For Availability
300
GEN WR09X0411 GEN WR09X0411 Contact Us For Availability
301
GEN WR02X7146 GEN WR02X7146 Contact Us For Availability
304
GEN WR02X7650 GEN WR02X7650 Contact Us For Availability
304
GEN WR02X8363 GEN WR02X8363 Contact Us For Availability
306
GEN WR02X7652 GEN WR02X7652 Contact Us For Availability
306
GEN WR02X7669 GEN WR02X7669 Contact Us For Availability
306
GEN WR17X2166 GEN WR17X2166 Contact Us For Availability
308
GEN WR02X7768 GEN WR02X7768 Contact Us For Availability
313
GEN WR17X2554 GEN WR17X2554 Contact Us For Availability
314
GEN WR02X4516 GEN WR02X4516 Contact Us For Availability
315
GEN WR02X8150 GEN WR02X8150 Contact Us For Availability
315
GEN WR14X0346 GEN WR14X0346 Contact Us For Availability
323
GEN WR02X7767 GEN WR02X7767 Contact Us For Availability
355
GEN WR01X5744 GEN WR01X5744 Contact Us For Availability
400
GEN WR71X2173 GEN WR71X2173 Contact Us For Availability
401
GEN WR32X1067 GEN WR32X1067 Contact Us For Availability
402
GEN WR38X1672 GEN WR38X1672 Contact Us For Availability
402
GEN WR38X1674 GEN WR38X1674 Contact Us For Availability
403
GEN WR38X1651 GEN WR38X1651 Contact Us For Availability
403
GEN WR38X1654 GEN WR38X1654 Contact Us For Availability
409
GEN WR02X8453 GEN WR02X8453 Contact Us For Availability
450
GEN WR02 GEN WR02 Contact Us For Availability
551
SCREW GEN WZ04X0244 Contact Us For Availability
566
GEN WR01X1487 GEN WR01X1487 Contact Us For Availability
603
GEN WR17X2234 GEN WR17X2234 Contact Us For Availability
604
GEN WR17X2870 GEN WR17X2870 Contact Us For Availability
606
GEN WR17X2401 GEN WR17X2401 Contact Us For Availability
608
GEN WR17X2796 GEN WR17X2796 Contact Us For Availability
621
GEN WR02X7785 GEN WR02X7785 Contact Us For Availability
622
GEN WR14X0348 GEN WR14X0348 Contact Us For Availability
624
GEN WR17X2229 GEN WR17X2229 Contact Us For Availability
651
GEN WR01X1714 GEN WR01X1714 Contact Us For Availability
651
GEN WR01X1715 GEN WR01X1715 Contact Us For Availability
651
GEN WR60X0193 GEN WR60X0193 Contact Us For Availability
683
SCREW GEN WR01X1716 Contact Us For Availability
726
MACHINE LOW SIDE GEN WR85X0214 Contact Us For Availability
730
CONDENSER ASM GEN WR84X0132 Contact Us For Availability
733
GEN WR07X0195 GEN WR07X0195 Contact Us For Availability
734
GEN WR02X7928 GEN WR02X7928 Contact Us For Availability
734
GEN WR02X7929 GEN WR02X7929 Contact Us For Availability
735
GEN WR08X0098 GEN WR08X0098 Contact Us For Availability
736
GEN WR02X4998 GEN WR02X4998 Contact Us For Availability
737
GEN WR02X7238 GEN WR02X7238 Contact Us For Availability
751
GEN WR17X2418 GEN WR17X2418 Contact Us For Availability
752
GEN WR17X2417 GEN WR17X2417 Contact Us For Availability
753
GEN WR17X2084 GEN WR17X2084 Contact Us For Availability
754
GEN WR17X2437 GEN WR17X2437 Contact Us For Availability
755
GEN WR17X2227 GEN WR17X2227 Contact Us For Availability
756
GEN WR17X2161 GEN WR17X2161 Contact Us For Availability
762
GEN WR14X0313 GEN WR14X0313 Contact Us For Availability
764
GEN WR02X7667 GEN WR02X7667 Contact Us For Availability
830
GEN WR17X2575 GEN WR17X2575 Contact Us For Availability
830
GEN WR82X0318 GEN WR82X0318 Contact Us For Availability
900
FZ O.DOOR WH GEN WR78X7965 Contact Us For Availability
910
FF O.DOOR WH GEN WR78X7968 Contact Us For Availability
921
GEN WR02X7624 GEN WR02X7624 Contact Us For Availability
× ![]()
