Model LG SDM-HX73 – Common Parts & Diagrams
Diagram 0
Common parts from model LG SDM-HX73
0
SCREW, LGE 1SZZTPP001B Contact Us For Availability
0
SCREW, LGE 1SZZTPP001C Contact Us For Availability
0
LGE 332-113E LGE 332-113E Contact Us For Availability
0
COVER LGE 3550TKK409A Contact Us For Availability
0
COVER LGE 3550TKK411A Contact Us For Availability
0
MARK LGE 3846TKK058C Contact Us For Availability
0
BAG,VINYL LGE 3880TKZ020F Contact Us For Availability
0
SCREW,DRAWING LGE 1SZZTEC001C Contact Us For Availability
0
COVER LGE 3550TKK417A Contact Us For Availability
0
LGE 3920TKP013A LGE 3920TKP013A Contact Us For Availability
0
SPEAKER ASSEMBLY LGE 6401TZZ035A Contact Us For Availability
0
CABLE,D-SUB LGE 6850TD9004G Contact Us For Availability
0
PWB(PCB) ASSEMBLY,MA LGE 6871TMT456B Contact Us For Availability
0
SCREW,DRAWING LGE 332-068U Contact Us For Availability
0
COVER LGE 3550TKS063A Contact Us For Availability
0
LGE 3890TSE468A LGE 3890TSE468A Contact Us For Availability
0
CONNECTOR ASSEMBLY LGE 6631T11016W Contact Us For Availability
0
CORD,A/V LGE 6852TAZ006P Contact Us For Availability
0
BACK COVER ASSEMBLY LGE 3809TKL061A Contact Us For Availability
0
LGE 4950TKS249A LGE 4950TKS249A Contact Us For Availability
0
LGE 6304FAU010A LGE 6304FAU010A Contact Us For Availability
0
SCREW,DRAWING LGE 1SZZTMF008A Contact Us For Availability
0
CABINET ASSEMBLY LGE 3091TKL089A Contact Us For Availability
0
SCREW LGE 332-095A Contact Us For Availability
0
LGE 3550TKK408A LGE 3550TKK408A Contact Us For Availability
0
LGE 3920TKP013B LGE 3920TKP013B Contact Us For Availability
0
LGE 4950TKK640A LGE 4950TKK640A Contact Us For Availability
0
CONNECTOR ASSEMBLY LGE 6631T10003G Contact Us For Availability
0
CABLE,DVI LGE 6866TDV004Q Contact Us For Availability
0
PWB(PCB) ASSEMBLY,PO LGE 6871TPT251B Contact Us For Availability
0
PWB(PCB) ASSEMBLY,SU LGE 6871TST423A Contact Us For Availability
0
LGE 1SZZTTC002E LGE 1SZZTTC002E Contact Us For Availability
0
DISKETTE ASSEMBLY LGE 3171TZ1338A Contact Us For Availability
0
SCREW ASSY LGE 339-006A Contact Us For Availability
0
LGE 4950TKS248B LGE 4950TKS248B Contact Us For Availability
0
POWER CORD LGE 6410TEW007A Contact Us For Availability
0
CONNECTOR ASSEMBLY LGE 6631T10003E Contact Us For Availability
0
PWB(PCB) ASSEMBLY,SU LGE 6871TST422A Contact Us For Availability
0
PWB(PCB) ASSEMBLY,SU LGE 6871TST424A Contact Us For Availability
0
LGE 1SZZTML004A LGE 1SZZTML004A Contact Us For Availability
0
SCREW, LGE 1SZZTPC001A Contact Us For Availability
0
SCREW, LGE 332-113D Contact Us For Availability
0
LGE 332-113J LGE 332-113J Contact Us For Availability
0
TILT SWIVEL ASSEMBLY LGE 3043TKK138A Contact Us For Availability
0
COVER ASSEMBLY LGE 3551TKK502A Contact Us For Availability
0
Bag LGE 373-071D Contact Us For Availability
C393
Capacitor,AL,Radial LGE 0CZZTAT005G Contact Us For Availability
C623
LGE 0CZZTAT008A LGE 0CZZTAT008A Contact Us For Availability
C660
CAPACITOR,FIXED CERA LGE 0CC221CK41A Contact Us For Availability
C661
CAPACITOR,FIXED CERA LGE 0CK105CD56A Contact Us For Availability
C666
LGE 0CZZTAT005H LGE 0CZZTAT005H Contact Us For Availability
C667
LGE 0CZZTAT005C LGE 0CZZTAT005C Contact Us For Availability
C682
CAPACITOR,FIXED CERA LGE 0CK562CK51A Contact Us For Availability
C686
Capacitor,AL,Chip LGE 0CZZTAT008C Contact Us For Availability
C703
CAPACITOR,FIXED CERA LGE 0CK104CK56A Contact Us For Availability
C731
CAPACITOR,FIXED CERA LGE 0CC680CK41A Contact Us For Availability
C801
CAPACITOR,FIXED CERA LGE 0CK103CK51A Contact Us For Availability
C820
Capacitor,AL,Radial LGE 0CZZTAT005B Contact Us For Availability
D608
LGE 0DRTW00089A LGE 0DRTW00089A Contact Us For Availability
D715
DIODE,SWITCHING LGE 0DS226009AA Contact Us For Availability
J601
Jack,Phone LGE 6612F00001B Contact Us For Availability
J701
CONNECTOR (CIRC),D-S LGE 6630TGA005B Contact Us For Availability
J710
CONNECTOR (CIRC),D-S LGE 6630TGA004A Contact Us For Availability
L605
FILTER(CIRC),EMC LGE 6210TCE001S Contact Us For Availability
L607
FILTER(CIRC),EMC LGE 6210TCE0016 Contact Us For Availability
LED1
LED,Chip LGE 0DLLT0208AA Contact Us For Availability
Q503
IC,KEC LGE 0IKE704200H Contact Us For Availability
Q704
TRANSISTOR LGE 0TR390609FA Contact Us For Availability
Q707
TRANSISTOR LGE 0TR390409AE Contact Us For Availability
R4
RESISTOR,METAL GLAZE LGE 0RJ1501D677 Contact Us For Availability
R207
RESISTOR,METAL GLAZE LGE 0RJ3900D677 Contact Us For Availability
R216
RESISTOR,METAL GLAZE LGE 0RJ0472D677 Contact Us For Availability
R624
Resistor,Chip LGE 0RJ2201D677 Contact Us For Availability
R628
Resistor,Chip LGE 0RJ1801D677 Contact Us For Availability
R629
Resistor,Chip LGE 0RJ6202D677 Contact Us For Availability
R631
Resistor,Chip LGE 0RJ1602D677 Contact Us For Availability
R633
Resistor,Chip LGE 0RJ4302D677 Contact Us For Availability
R636
Resistor,Chip LGE 0RJ8201D677 Contact Us For Availability
R639
RESISTOR,METAL GLAZE LGE 0RJ5101D677 Contact Us For Availability
R647
RESISTOR,METAL GLAZE LGE 0RJ7501D677 Contact Us For Availability
R648
RESISTOR,METAL GLAZE LGE 0RJ1502D677 Contact Us For Availability
R652
Resistor,Chip LGE 0RJ6802D677 Contact Us For Availability
R667
RESISTOR,METAL GLAZE LGE 0RJ1002D677 Contact Us For Availability
R671
RESISTOR,METAL GLAZE LGE 0RJ1003D677 Contact Us For Availability
R672
RESISTOR,METAL GLAZE LGE 0RJ1802D677 Contact Us For Availability
R676
Filter,Bead LGE 6210TCE001H Contact Us For Availability
R708
RESISTOR,METAL GLAZE LGE 0RJ2200D677 Contact Us For Availability
R709
RESISTOR,METAL GLAZE LGE 0RJ1211D477 Contact Us For Availability
R729
RESISTOR,METAL GLAZE LGE 0RJ0222D677 Contact Us For Availability
R756
RESISTOR,METAL GLAZE LGE 0RJ0682D677 Contact Us For Availability
R759
RESISTOR,METAL GLAZE LGE 0RJ0752D677 Contact Us For Availability
R767
RESISTOR,METAL GLAZE LGE 0RJ1001D677 Contact Us For Availability
R771
RESISTOR,METAL GLAZE LGE 0RJ4701D677 Contact Us For Availability
R785
RESISTOR CHIP LGE 0RH0472D622 Contact Us For Availability
R811
RESISTOR,METAL GLAZE LGE 0RJ2202D677 Contact Us For Availability
R812
RESISTOR,METAL GLAZE LGE 0RJ2001D677 Contact Us For Availability
R846
RESISTOR,METAL GLAZE LGE 0RJ0102D677 Contact Us For Availability
SW7
Switch,Tact LGE 6600R000002 Contact Us For Availability
U1
IC,Ambient Light Sensor LGE 0IPRPTX001A Contact Us For Availability
U201
IC,PERIPHERALS LGE 0IPRPM3010A Contact Us For Availability
U501
IC,DRAWING LGE 0IZZTSZ291A Contact Us For Availability
U502
IC,MEMORIES LGE 0IMMRSS040C Contact Us For Availability
U601
IC,PERIPHERALS LGE 0IPRPPZ001A Contact Us For Availability
U602
IC,PERIPHERALS LGE 0IPRPSG012A Contact Us For Availability
U603
IC,PERIPHERALS LGE 0IPRPTI036A Contact Us For Availability
U604
IC,PERIPHERALS LGE 0IPRPTI034A Contact Us For Availability
U703
IC,MEMORIES LGE 0IMMRSG036A Contact Us For Availability
U801
IC,Voltage Regulator LGE 0IKE780500X Contact Us For Availability
U803
IC,POWER MANAGEMENT LGE 0IPMGK2001C Contact Us For Availability
U805
TRANSISTOR,FETS LGE 0TFVI80023A Contact Us For Availability
U807
TRANSISTOR,FETS LGE 0TFFC80009A Contact Us For Availability
U808
IC,KEC LGE 0IKE780900H Contact Us For Availability
X501
RESONATOR,CRYSTAL LGE 6212AA2004A Contact Us For Availability
ZD713
DIODE,ZENERS LGE 0DZ560009GB Contact Us For Availability
× ![]()
