Model Whirlpool RTP201UW GAS COOK-TOP – Common Parts & Diagrams

1
MAIN TOP, DARK COPPER
MAIN TOP, DARK COPPER WPL 069988C Contact Us For Availability
View on Model
1
MAIN TOP, GOLD
MAIN TOP, GOLD WPL 069988D Contact Us For Availability
View on Model
1
MAIN TOP, AVOCADO
MAIN TOP, AVOCADO WPL 069988V Contact Us For Availability
View on Model
1
MAIN TOP, ALMOND
MAIN TOP, ALMOND WPL 303382L Contact Us For Availability
View on Model
1
MAIN TOP, SNOW WHITE
MAIN TOP, SNOW WHITE WPL 303382W Contact Us For Availability
View on Model
2
KNOB, TOP BURNER
KNOB, TOP BURNER WPL Y0073115 Contact Us For Availability
View on Model
3
BURNER ASSY, LF
BURNER ASSY, LF WPL 0053536 Contact Us For Availability
View on Model
3
BURNER ASSY., L.F.
BURNER ASSY., L.F. WPL Y0068693 Contact Us For Availability
View on Model
3
TRIM RAIL
TRIM RAIL WPL Y0077038 Contact Us For Availability
View on Model
4
BURNER ASSY, RF & RR
BURNER ASSY, RF & RR WPL Y0053535 Contact Us For Availability
View on Model
4
BURNER ASSY, RF & RR
BURNER ASSY, RF & RR WPL Y0068692 Contact Us For Availability
View on Model
4
CATCH MAIN TOP
CATCH MAIN TOP WPL Y0099224 Contact Us For Availability
View on Model
5
BURNER ASSY, LR
BURNER ASSY, LR WPL Y0053537 Contact Us For Availability
View on Model
5
BURNER ASSY, LR
BURNER ASSY, LR WPL Y0068694 Contact Us For Availability
View on Model
5
WASHER SPRING
WASHER SPRING WPL 0099115 Contact Us For Availability
View on Model
6
SHOULDER BOLT
SHOULDER BOLT WPL 0099116 Contact Us For Availability
View on Model
8
GRATE, TOP BURNER
GRATE, TOP BURNER WPL 0099997 Contact Us For Availability
View on Model
9
BURNER BOWL CHROME (K)
BURNER BOWL CHROME (K) WPL Y0097083 Contact Us For Availability
View on Model
10
PRESSURE REGULATOR
PRESSURE REGULATOR WPL Y0069636 Contact Us For Availability
View on Model
11
FILTER ASSEMBLY
FILTER ASSEMBLY WPL Y0076499 Contact Us For Availability
View on Model
12
SUB 312896, KIT PILOT TUBE
SUB 312896, KIT PILOT TUBE WPL 0073632 Contact Us For Availability
View on Model
13
NAMEPLATE
NAMEPLATE WPL Y0304710 Contact Us For Availability
View on Model
14
MANIFOLD ASSEMBLY
MANIFOLD ASSEMBLY WPL 0303803 Contact Us For Availability
View on Model
15
WASHER ALUMINUM
WASHER ALUMINUM WPL 0097971 Contact Us For Availability
View on Model
16
COVER, INLET PIPE
COVER, INLET PIPE WPL Y0300823 Contact Us For Availability
View on Model
17
BURNER BOX
BURNER BOX WPL 68687CG Contact Us For Availability
View on Model
18
TOP PILOT LIGHTER CUP
TOP PILOT LIGHTER CUP WPL Y0020069 Contact Us For Availability
View on Model
19
1/8`` SLEEVE
1/8`` SLEEVE WPL Y0096789 Contact Us For Availability
View on Model
20
1/8`` COMPRESSION NUT
1/8`` COMPRESSION NUT WPL Y0097930 Contact Us For Availability
View on Model
21
ELBOW, PIPE-1/2`` X 90 DEGREE
ELBOW, PIPE-1/2`` X 90 DEGREE WPL Y0097408 Contact Us For Availability
View on Model
22
NIPPLE-1/2``-PRESSURE REGULATOR
NIPPLE-1/2``-PRESSURE REGULATOR WPL Y0097320 Contact Us For Availability
View on Model
23
SHIELD, BOTTOM
SHIELD, BOTTOM WPL Y0077031 Contact Us For Availability
View on Model
24
MOUNTING BRACKET
MOUNTING BRACKET WPL 0074342 Contact Us For Availability
View on Model
24
MOUNTING BRACKET
MOUNTING BRACKET WPL Y0073717 Contact Us For Availability
View on Model
25
HEAT SHIELD
HEAT SHIELD WPL 0068683 Contact Us For Availability
View on Model
NI
SUPPORT, MTG. BRKT
SUPPORT, MTG. BRKT WPL Y0068688 Contact Us For Availability
View on Model
NI
BOLT, SHOULDER
BOLT, SHOULDER WPL 0098549 Contact Us For Availability
View on Model
