Model Fisher &amp; Paykel RS3084FLJE1-26908-A Vertical Freezer – Common Parts &amp; Diagrams

1

SPACER COVER DRAIN ASSY FPA 848128 Contact Us For Availability

1

TERMINAL SYF-01T PKT 10 FPA 819607P Contact Us For Availability

1

KIT ALCOVE TRIM FPA 868352 Contact Us For Availability

2

842292P Fisher & Paykel Refrigerator Screw Wa In Stock FPA 842292P $21.38

2

848120P Fisher & Paykel Refrigerator M4x35 St Backorder FPA 848120P $47.64

2

PIN/TERM SYM-01T PKT 10 FPA 819609P Contact Us For Availability

2

DIVIDER PLINTH REAR FPA 843139 Contact Us For Availability

2

KIT DUAL INSTALL FPA 867910 Contact Us For Availability

3

847176 Fisher & Paykel Refrigerator Water Fil In Stock FPA 847176 $6.90

3

848748 Fisher & Paykel Refrigerator Lower Dra Backorder FPA 848748 $55.60

3

867898 Fisher & Paykel Refrigerator Joiner Fa Backorder FPA 867898 $18.18

3

JST SOCKET 2PIN YLR-02V FPA 819615 Contact Us For Availability

4

527679P Fisher & Paykel Dishwasher Door Corne Backorder FPA 527679P $55.74

4

819611 Fisher & Paykel Refrigerator JST Plug Backorder FPA 819611 $6.78

4

842456P Fisher & Paykel Refrigerator Washer M In Stock FPA 842456P $17.92

4

843934 Fisher & Paykel Refrigerator Anti-Tip Backorder FPA 843934 $23.78

4

SCREW ST #8X15-M6X12 WASHER KIT FPA 840421P Contact Us For Availability

4

COVER DIVIDER FRONT FPA 869486 Contact Us For Availability

5

838158P Fisher & Paykel Refrigerator Hex Nut In Stock FPA 838158P $18.95

5

CLIP EDGE EARTH TAB AR EPF255 FPA 846732P Contact Us For Availability

5

RETAINER 2 WAY YLS-02V FPA 819620 Contact Us For Availability

5

DIVIDER PLINTH VALVE MODULE FPA 869474 Contact Us For Availability

6

814460 Fisher & Paykel Earth Harness 100mm Backorder FPA 814460 $6.78

6

836929 Fisher & Paykel Refrigerator Ice Scoop Backorder FPA 836929 $6.90

6

843507P Fisher & Paykel Refrigerator Top Door Backorder FPA 843507P $78.12

7

DUCT CVR SEAL LWR SS RS30 ASSY FPA 849243P Contact Us For Availability

7

BLOCKER CONDSR AIRFLOW BYPASS FPA 845772 Contact Us For Availability

8

846179P Fisher & Paykel Refrigerator Dual Loc In Stock FPA 846179P $60.64

8

848745 Fisher & Paykel Refrigerator Upper Dra Backorder FPA 848745 $71.98

8

SCREW ST 8X1/2 SD TRS NIB PH P FPA 611977P Contact Us For Availability

9

KIT DUCT COVER SEAL UPR RS30W FPA 862712P Contact Us For Availability

9

GROMMET CONDNSR AIR B/PASS FPA 848130 Contact Us For Availability

10

844632 Fisher & Paykel Refrigerator Door Magn Backorder FPA 844632 $6.96

10

NAMEPLATE FP CHROME LETTERS FPA 847363 Contact Us For Availability

10

LOCKING PLATE REAR PLINTH 30 FPA 842251 Contact Us For Availability

11

839474 Fisher & Paykel Refrigerator M6-S Hing In Stock FPA 839474 $231.32

11

841568P Fisher & Paykel Refrigerator Screw M5 In Stock FPA 841568P $10.30

11

847876P Fisher & Paykel Condenser 260x177 1-P In Stock FPA 847876P $120.24

12

546692P Fisher & Paykel Dishwasher Screw St. Backorder FPA 546692P $10.28

12

843720 Fisher & Paykel Refrigerator Hinge Poc Backorder FPA 843720 $6.78

13

846688P Fisher & Paykel Refrigerator Sankyo V Backorder FPA 846688P $92.68

13

POCKET HINGE TOP LH FPA 843719 Contact Us For Availability

14

SPACER BRACKET HINGE TOP FPA 847537 Contact Us For Availability

14

CLIP SPIRE SIZE 8 FPA 841023P Contact Us For Availability

15

BRACKET HINGE TOP RS FPA 842944 Contact Us For Availability

15

COVER COMMS PORT FPA 884505 Contact Us For Availability

16

845428P Fisher & Paykel Refrigerator Screw M5 Backorder FPA 845428P $18.12

16

CORDSET PWR US FPA 885376P Contact Us For Availability

17

TUBE COPPER U-BEND FPA 845861 Contact Us For Availability

18

839692P Fisher & Paykel Refrigerator M6X16 Cs Backorder FPA 839692P $17.76

18

ASSY CTRL RS WIFI RX AC SVC FPA 885126P Contact Us For Availability

19

847675P Fisher & Paykel Refrigerator Dual Loc In Stock FPA 847675P $21.96

19

TUBE ADAPTOR PROCESS RS FPA 842972 Contact Us For Availability

843717 Fisher & Paykel Refrigerator Top Trim Backorder FPA 843717 $51.16

SLIDE 224R SL FPA 843973 Contact Us For Availability

SLIDE 224L SL FPA 843972 Contact Us For Availability

TUBE ADAPTOR SUCTION RS FPA 842989 Contact Us For Availability

207411P Fisher & Paykel Refrigerator 115V Com Backorder FPA 207411P $381.22

BRACKET HCL LWR LH Backorder FPA 847043 $7.02

BRACKET SHELF LWR RH FPA 847044 Contact Us For Availability

BRACKET ALCOVE TOP LH FPA 847006 Contact Us For Availability

22

845758P Fisher & Paykel Dual 5 Gallon Dryer F In Stock FPA 845758P $35.68

22

SLIDE 337R SL FPA 843977 Contact Us For Availability

22

SLIDE 337L SL FPA 843976 Contact Us For Availability

23

844711 Fisher & Paykel Refrigerator Column Di Backorder FPA 844711 $16.08

23

LIGHT CEILING PANEL RS30 ASSY FPA 885792P Contact Us For Availability

23

GROMMET 26MM KIT FPA 843824P Contact Us For Availability

24

844551 Fisher & Paykel Refrigerator Fan Housi Backorder FPA 844551 $13.28

24

855270P Fisher & Paykel Refrigerator Compress Backorder FPA 855270P $21.10

24

END CAP UI RH RS FPA 844971 Contact Us For Availability

25

847484 Fisher & Paykel Gasket Ui End Cap Rs30 Backorder FPA 847484 $6.78

25

SCREW M4X16 PLASTITE PH T15 PK FPA 847532P Contact Us For Availability

25

POST COMP MTG 26MM PKT X4 FPA 841291P Contact Us For Availability

26

CLIP R COVER COMP M16 S4HPP16 Backorder FPA 207419 $6.90

26

MOD TFT DISP RS30 SVC FPA 885629P Contact Us For Availability

26

COVER INTEGRATED SIDE LIGHT GR FPA 848428 Contact Us For Availability

27

611933P Fisher & Paykel Refrigerator Screw 8X Backorder FPA 611933P $13.80

27

849937P Fisher & Paykel Refrigerator Side Lig Backorder FPA 849937P $61.64

27

COVER PROTECTOR VEM FPA 207310 Contact Us For Availability

28

207393 Fisher & Paykel Refrigerator Inverter In Stock FPA 207393 $191.58

28

844545P Fisher & Paykel Refrigerator D125 Fan Backorder FPA 844545P $112.56

28

END CAP UI LH RS FPA 844970 Contact Us For Availability

29

847483 Fisher & Paykel Gasket Ui End Cap Rs30 Backorder FPA 847483 $6.78

29

CLIP SENSOR FPA 845878 Contact Us For Availability

29

BRACKET INVERTER MOLEX CONN FPA 849714 Contact Us For Availability

30

813822P Fisher & Paykel Refrigerator Thermist Backorder FPA 813822P $106.00

30

837180 Fisher & Paykel Refrigerator Ice Tray In Stock FPA 837180 $6.90

30

842765 Fisher & Paykel Refrigerator Inverter Backorder FPA 842765 $17.50

31

321107 Fisher & Paykel Refrigerator Icemaker In Stock FPA 321107 $28.80

31

COVER PLUG TYCO FPA 821745 Contact Us For Availability

32

556082P Fisher & Paykel Screw M4x12 Xtite Hex Backorder FPA 556082P $6.78

32

836909 Fisher & Paykel Refrigerator Sensor Fo Backorder FPA 836909 $6.90

32

EVAP ASSY UPR 30 FC FPA 843060P Contact Us For Availability

33

841488 Fisher & Paykel Refrigerator Icemaker In Stock FPA 841488 $119.45

33

846242P Fisher & Paykel Refrigerator Heater D Backorder FPA 846242P $93.18

34

817825P Fisher & Paykel Refrigerator 8x22 Waf Backorder FPA 817825P $12.94

34

MOUNTING PLATE KICK STRIP 30 FPA 885712 Contact Us For Availability

35

820841 Fisher & Paykel Refrigerator Large Aut In Stock FPA 820841 $7.34

35

866753 Fisher & Paykel Refrigerator Toekick M In Stock FPA 866753 $35.74

35

SHIELD HEAT 30 UPR FC FPA 844107 Contact Us For Availability

36

HOUSING ICE MAKER FPA 860391 Contact Us For Availability

36

WIRE DRAIN HEATER RS FPA 847315 Contact Us For Availability

37

836910 Fisher & Paykel Refrigerator Ice Lever Backorder FPA 836910 $6.90

37

847371 Fisher & Paykel Refrigerator Fixed Gri Backorder FPA 847371 $57.30

37

HOUSING FAN ASSY WHITE FPA 862891 Contact Us For Availability

38

843298 Fisher & Paykel Refrigerator Grille Fi Backorder FPA 843298 $6.78

38

GEARBOX ICE MAKER FPA 836934 Contact Us For Availability

38

SHIELD HEAT 30 LWR FC FPA 844108 Contact Us For Availability

39

836948P Fisher & Paykel Refrigerator Stainles Backorder FPA 836948P $20.64

39

847541P Fisher & Paykel Refrigerator Moving G Backorder FPA 847541P $62.14

39

SHIELD DRAIN LWR 30PC FPA 844877 Contact Us For Availability

40

851045P Fisher & Paykel Refrigerator Lower Ev Backorder FPA 851045P $101.56

40

860640 Fisher & Paykel Refrigerator Ice Maker Backorder FPA 860640 $6.90

40

BLOCKER AIR BYPASS KICKSTRIP FPA 846405 Contact Us For Availability

41

TUBE ADAPTOR EVAP IN FPA 847463 Contact Us For Availability

41

TUBE DISCHARGE RS3084 FPA 842988 Contact Us For Availability

42

SHIELD DRAIN UPR 30 PC FPA 844876 Contact Us For Availability

42

BRACKET KICK STRIP ADJUSTING FPA 842018 Contact Us For Availability

43

842883 Fisher & Paykel Plinth Bracket Front L Backorder FPA 842883 $21.02

43

CLIP HARNESS HT 151-000367 FPA 845740P Contact Us For Availability

44

SCREW MC M5X12 HXW NIB ZP PKT10 FPA 845515P Contact Us For Availability

44

WASHER FLAT M6X12X1.2 PKT10 FPA 843453P Contact Us For Availability

45

BRACKET HINGE LOWER LH FPA 843027 Contact Us For Availability

46

837842 Fisher & Paykel Refrigerator Hinge K05 In Stock FPA 837842 $230.72

46

DRAIN PLINTH FPA 845859 Contact Us For Availability

47

BRACKET PLINTH FRONT RIGHT FPA 842882 Contact Us For Availability

47

TRAY WATER EVAP COLUMNS FPA 841476 Contact Us For Availability

48

846972 Fisher & Paykel Refrigerator Humidity Backorder FPA 846972 $6.78

48

DRAIN TUBE PLINTH UPPER RS30 FPA 845858 Contact Us For Availability

49

849237P Fisher & Paykel Refrigerator Screw #8 Backorder FPA 849237P $18.08

49

KIT MOD COMBI WIFIBT GEA US SP FPA 566390P Contact Us For Availability

50

843872 Fisher & Paykel Refrigerator Housing S In Stock FPA 843872 $6.78

50

KIT LEVELLING SYSTEM FNT LONG - POST 20 APR 2 FPA 869085P Contact Us For Availability

51

843475 Fisher & Paykel Refrigerator Back Leve Backorder FPA 843475 $25.88

52

HARNESS WIFI GEA WIRE FPA 862641 Contact Us For Availability

52

KIT LEVELLING SYSTEM REAR LONG - POST 20 APR FPA 869086P Contact Us For Availability

53

851352P Fisher & Paykel Refrigerator Hall Mod Backorder FPA 851352P $32.08

53

VALVE DUAL IW REF GND 120V FPA 885120 Contact Us For Availability

54

MOD GEA COMMS V3 COMB SVC FPA 885659P Contact Us For Availability

54

MANIFOLD FILTER FPWF1 COL ISO FPA 869601 Contact Us For Availability

55

851381P Fisher & Paykel Refrigerator Humidity Backorder FPA 851381P $53.82

55

VALVE INLET WTR REF GND 120V FPA 885118 Contact Us For Availability

840371P Fisher & Paykel Refrigerator 8G x 16 In Stock FPA 840371P $10.70

841651 Fisher & Paykel Braided Hose 7/16-24 U Backorder FPA 841651 $59.18

843662 Fisher & Paykel Refrigerator Limiting Backorder FPA 843662 $6.78

845432P Fisher & Paykel Refrigerator Mounting In Stock FPA 845432P $17.40

847200 Fisher & Paykel Refrigerator Water Fil In Stock FPA 847200 $104.28

848190P Fisher & Paykel Kit Hinge Change RS30 Backorder FPA 848190P $177.10

867900 Fisher & Paykel Refrigerator Bracket P Backorder FPA 867900 $73.04

867906 Fisher & Paykel Installation Kit RS V2 Backorder FPA 867906 $242.36

SCREW CAP M5X20 NZ PKT10 FPA 847984P Contact Us For Availability

KIT INSTALL FASTENERS FPA 848192 Contact Us For Availability

BK IG INT RS2435 (DIGITAL ONLY) FPA 431813 Contact Us For Availability

431814 FPA 431814 Contact Us For Availability

431815 FPA 431815 Contact Us For Availability

432117 FPA 432117 Contact Us For Availability

432418 FPA 432418 Contact Us For Availability

432697 FPA 432697 Contact Us For Availability

432698 FPA 432698 Contact Us For Availability
