Model LG RCMT5158B – Common Parts & Diagrams
Diagram 0
Diagram 1
Diagram 2
Diagram 3
Diagram 4
Diagram 5
Diagram 6
Common parts from model LG RCMT5158B
![MANUAL,[OWNERS]MWO](https://d2923bgwwiylbi.cloudfront.net/media/catalog/product/placeholder/default/image-coming-soon.jpg)
MANUAL,[OWNERS]MWO LGE 3828W5A0937 Contact Us For Availability
*02
MANUAL,SERVICE LGE 3828W5S0285 Contact Us For Availability
*10
BOX,[YELLOW] LGE 3890W2Y098A Contact Us For Availability
26638A
KEY MEMBRANE LGE 6638W2A088A Contact Us For Availability
33052A
LGE 3052W2A020A LGE 3052W2A020A Contact Us For Availability
33052A
CANOPY-L MS-151 S MS-153AM MS- LGE 3052W2A017A Contact Us For Availability
33112U
OUT CASE,[U-BENDING] LGE 3112W0U032L Contact Us For Availability
33390G
GLASS TRAY DIA 360MM T7MM WT1 LGE 1B71725A Contact Us For Availability
33550H
COVER,[HEATER] LGE 3550W2A076A Contact Us For Availability
34370T
TURN TABLE SHAFT MS-1715 TEFLO LGE 4370WRT001C Contact Us For Availability
34774U
HINGE PLATE-U MS-151 S MS-153A LGE 4774W3P010A Contact Us For Availability
35264A
AIR TUNNEL LGE 5264W1A007A Contact Us For Availability
35300A
HEATER,[MIRACLON] LGE 5300W2A006F Contact Us For Availability
35889A
ROTATING RING ASSY A 250,H 14, LGE 5889W2A005M Contact Us For Availability
36549S
LGE 2B72754F LGE 2B72754F Contact Us For Availability
43500A
BOARD LATCH MS-101 S 121 S 151 LGE 3500W1A004A Contact Us For Availability
43501A
HEATER ASSY LGE 5301W2A034F Contact Us For Availability
43501A
LGE 3501W1A003A LGE 3501W1A003A Contact Us For Availability
54810C
LGE 4810W4C003C LGE 4810W4C003C Contact Us For Availability
54974S
LGE 4974W1S016A LGE 4974W1S016A Contact Us For Availability
55262A
DUCT ASSY,[AIR DUCT] LGE 5263W2A015G Contact Us For Availability
55900A
PROPELLER LGE 2B72125A Contact Us For Availability
56021A
H.V. DIODE-CABLE ASM STANDARD LGE 3B73348B Contact Us For Availability
56021A
FILTER ASSY,NOISE LGE 3B74557A Contact Us For Availability
56170D
TRANSFORMER,HIGH VOLTAGE LGE 6010WRH008A Contact Us For Availability
56324A
MAGNETRON LGE 2B71732B Contact Us For Availability
56411A
LGE 2B73671A LGE 2B73671A Contact Us For Availability
56549F
LGE 2B73670A LGE 2B73670A Contact Us For Availability
56851C
Cable,Assembly LGE 3B74428D Contact Us For Availability
63302A
BASE PLATE LGE 3302W0A010B Contact Us For Availability
268711
PWB(PCB) ASSY,[MAIN] LGE 6871W2S111E Contact Us For Availability
348101
BRACKET,HEATER LGE 4810W3G082A Contact Us For Availability
348102
HEATER CONNECTOR LGE 4810W4G066A Contact Us For Availability
466001
Switch,Micro LGE 3B73362H Contact Us For Availability
568712
CONNECTOR ASSEMBLY LGE 6877W1T233A Contact Us For Availability
568771
LEADWIRE ASSY-SECOND MS-101 S/ LGE 6877W3T080E Contact Us For Availability
633303A
BASE PLATE ASSY LGE 3303W1A010B Contact Us For Availability
647781
LEG LGE 4B73900A Contact Us For Availability
948501
CUSHION LGE 3B72244W Contact Us For Availability
AR4
RESISTOR ARRAY LGE 0RZ4702G610 Contact Us For Availability
BZ1
LGE 6908W3YA01A LGE 6908W3YA01A Contact Us For Availability
C01
CAPACITOR,FIXED CERAMIC(High d LGE 0CK1040K948 Contact Us For Availability
C02
CAPACITOR ELECTROLYTIC LGE 0CE1076K638 Contact Us For Availability
C03
CAPACITOR,FIXED ELECTROLYTIC LGE 0CE2276H638 Contact Us For Availability
C06
CAPACITOR ELECTROLYTIC CE,47MF LGE 0CE4766K638 Contact Us For Availability
C08
CAPACITOR,FIXED CERAMIC(High d LGE 0CK2230K948 Contact Us For Availability
C11
CAPACITOR CERAMIC (HIGH DIELE) LGE 0CK2210K518 Contact Us For Availability
CN1
LGE 6630W5V004B LGE 6630W5V004B Contact Us For Availability
CN2
LGE 6630W5V004A LGE 6630W5V004A Contact Us For Availability
CN3
LGE 6630W5YA19C LGE 6630W5YA19C Contact Us For Availability
D17
DIODE IN4002,MA-1354P,1554M *N LGE 0DD400209AA Contact Us For Availability
DP1
DIGITRON 6-BT-199GN(NEW DEMO) LGE 6302W5YA02A Contact Us For Availability
PT1
LGE 6010W2P037H LGE 6010W2P037H Contact Us For Availability
Q03
TRANSISTOR LGE 0TR319809AA Contact Us For Availability
Q04
TRANSISTOR KTA1266-TP-Y(KTA101 LGE 0TR126609AA Contact Us For Availability
R01
RESISTOR FIXED CARBON FILM 1.0 LGE 0RD1001G608 Contact Us For Availability
R02
RESISTOR FIXED CARBON FILM 22 LGE 0RD2202G608 Contact Us For Availability
R05
Resistor,Carbon Film LGE 0RD2701F608 Contact Us For Availability
R09
Resistor,Carbon Film LGE 0RD7500F608 Contact Us For Availability
R10
LGE 0RD1003G608 LGE 0RD1003G608 Contact Us For Availability
R11
FIXED CARBON FILM 1M-J *NSP LGE 0RD1004F608 Contact Us For Availability
R12
RESISTOR FIXED CARBON FILM LGE 0RD3901G608 Contact Us For Availability
R16
Resistor,Carbon Film LGE 0RD5600F608 Contact Us For Availability
R18
RESISTOR FIXED CARBON FILM 47K LGE 0RD4702F608 Contact Us For Availability
R22
RESISTOR FIXED CARBON FILM 3.9 LGE 0RD3901F608 Contact Us For Availability
R25
Resistor,Carbon Film LGE 0RD1501F608 Contact Us For Availability
R32
Resistor,Carbon Film LGE 0RD3302F608 Contact Us For Availability
R33
Resistor,Carbon Film LGE 0RD1202F608 Contact Us For Availability
R34
Resistor,Carbon Film LGE 0RD1002F608 Contact Us For Availability
R35
Resistor,Carbon Film LGE 0RD5601F608 Contact Us For Availability
R36
Resistor,Carbon Film LGE 0RD2700F608 Contact Us For Availability
R39
Resistor,Carbon Film LGE 0RD0471F608 Contact Us For Availability
RY1
RELAY LGE 6920W2D010B Contact Us For Availability
RY2
RELAY OZF-S-112LM1P DC12V MV-1 LGE 6920W2YD04A Contact Us For Availability
U01
LGE 0IZZW5A023A LGE 0IZZW5A023A Contact Us For Availability
ZD1
LGE 0DZ510009AA LGE 0DZ510009AA Contact Us For Availability
ZD2
DIODE ZENER LGE 0DZ750009AC Contact Us For Availability
× ![]()
