Model LG R5208 – Common Parts & Diagrams
Diagram 0
Common parts from model LG R5208
130910
CABINET ASSY,SINGLE LGE 3091A10020C Contact Us For Availability
135302
GRILLE ASSY,FRONT(SINGLE) LGE 3530AR1615F Contact Us For Availability
135312
GRILLE ASSY,FRONT(SINGLE) LGE 3531AR1644M Contact Us For Availability
135313
GRILLE ASSEMBLY,INLET FINAL LGE 3531A20130A Contact Us For Availability
135500
LGE 3550A20026A LGE 3550A20026A Contact Us For Availability
135500-1
COVER,TERMINAL LGE 3550U-L006A Contact Us For Availability
147581
LINK HOLDER PP JI-350 LW-A0512 LGE 4520AR3191A Contact Us For Availability
148000
BRACE LGE 4800A30003A Contact Us For Availability
149410
KNOB ASSY LGE 4941AR7315D Contact Us For Availability
149980
SHROUD LGE 4998A10008A Contact Us For Availability
152302
FILTER(MECH),A/C LGE 5231AR2148G Contact Us For Availability
159900-1
VANE PP JI-350 LW-A0510/511/51 LGE 5990AR3190A Contact Us For Availability
249941
CONTROL BOX,SINGLE LGE 4994A20016A Contact Us For Availability
249950
CONTROL BOX ASSY,SINGLE LGE 4995A20126F Contact Us For Availability
264110
POWER CODE ASSY WA-CHASSIS, S LGE 2H00677P Contact Us For Availability
266003
SWITCH ROTARY SRB-315-4-2 LGE 2H00154H Contact Us For Availability
268630-1
CONDUCTOR ASM AWG18, UL1015 LGE 2H01045E Contact Us For Availability
268630-2
CONDUCTOR ASSY LGE 6631AR3843R Contact Us For Availability
269310
THERMOSTAT LGE 2H01109H Contact Us For Availability
346811
MOTOR ASSEMBLY,SINGLE LGE 4681A10012J Contact Us For Availability
349480
ORIFICE LGE 4948A10007A Contact Us For Availability
352115
TUBE ASSY,EVAPORATOR IN LGE 5211A10063A Contact Us For Availability
352390
AIR GUIDE ASSEMBLY LGE 5239A10005A Contact Us For Availability
352390
AIR GUIDE ASSY LGE 5239A30003A Contact Us For Availability
354210
EVAPORATOR ASSY,FIRST LGE 5421A10008B Contact Us For Availability
359012
FAN,TURBO LGE 5900A20005A Contact Us For Availability
552111
TUBE ASSEMBLY,CAPILLARY LGE 5211AR3332V Contact Us For Availability
554030
CONDENSER ASSY,FIRST LGE 5403AR6200C Contact Us For Availability
554160
COMPRESSOR SET LGE 2520UABC2EA Contact Us For Availability
559010
FAN,PROPELLER LGE 5900A20017A Contact Us For Availability
567502
O.L.P LGE 6750U-L050A Contact Us For Availability
648600
CLAMP CAPACITOR MJ/GA-1014LCM LGE 4H00442F Contact Us For Availability
731273
INSTALL PART ASSY,SINGLE LGE 3127A20016B Contact Us For Availability
738290
MANUAL,OWNERS LGE 3828A20139F Contact Us For Availability
749740
UPPER GUIDE LW-A0510/511CL LGE 5210AR3196C Contact Us For Availability
W1WZZ
GASKET-NUT <GA-0711HCR/0712HCM LGE 4H01058A Contact Us For Availability
× ![]()
