Model LG R-8000A – Common Parts & Diagrams

130910
CABINET ASSY,SINGLE
CABINET ASSY,SINGLE LGE 3091A30005D Contact Us For Availability
View on Model
135312
GRILLE ASSEMBLY,FRONT(SINGLE)
GRILLE ASSEMBLY,FRONT(SINGLE) LGE 3531A10131D Contact Us For Availability
View on Model
135313
GRILLE,INLET
GRILLE,INLET LGE 3530A10028A Contact Us For Availability
View on Model
137215
PANEL ASSY,CONTROL
PANEL ASSY,CONTROL LGE 3721A20037A Contact Us For Availability
View on Model
147581
LOUVER,HORIZONTAL
LOUVER,HORIZONTAL LGE 4758A20002A Contact Us For Availability
View on Model
147582
LOUVER,VERTICAL
LOUVER,VERTICAL LGE 4758A30008A Contact Us For Availability
View on Model
149410
KNOB ASSY
KNOB ASSY LGE 4941A30011A Contact Us For Availability
View on Model
249950
CONTROL BOX ASSY,SINGLE
CONTROL BOX ASSY,SINGLE LGE 4995A20072A Contact Us For Availability
View on Model
266003
ROTARY SWITCH 20A 125/250V SHA_2H00598F IS NO
ROTARY SWITCH 20A 125/250V SHA_2H00598F IS NO LGE 2H00598E Contact Us For Availability
View on Model
269300
THERMOSTAT
THERMOSTAT LGE 2H01109L Contact Us For Availability
View on Model
346811
MOTOR ASSY,SINGLE
MOTOR ASSY,SINGLE LGE 4681A20027B Contact Us For Availability
View on Model
349480
ORIFICE
ORIFICE LGE 4948A30003B Contact Us For Availability
View on Model
349600
MOUNT,MOTOR
MOUNT,MOTOR LGE 4960A20002A Contact Us For Availability
View on Model
352111
Tube,Connector
Tube,Connector LGE 5210AR3400A Contact Us For Availability
View on Model
352113
TUBE,DISCHARGE
TUBE,DISCHARGE LGE 5210A20071A Contact Us For Availability
View on Model
352115
TUBE ASSY,EVAPORATOR IN
TUBE ASSY,EVAPORATOR IN LGE 5211A20131A Contact Us For Availability
View on Model
352390
AIR GUIDE ASSY
AIR GUIDE ASSY LGE 5239A30002A Contact Us For Availability
View on Model
354210
Evaporator Assembly,First
Evaporator Assembly,First LGE 5421A90035B Contact Us For Availability
View on Model
354210
EVAPORATOR ASSY
EVAPORATOR ASSY LGE 5421A20036C Contact Us For Availability
View on Model
359012
FAN ASSY,BLOWER
FAN ASSY,BLOWER LGE 5901A10005A Contact Us For Availability
View on Model
554030
CONDENSER ASSY
CONDENSER ASSY LGE 5403A20024C Contact Us For Availability
View on Model
554030
Condenser Assembly,First
Condenser Assembly,First LGE 5403A90043A Contact Us For Availability
View on Model
554160
COMPRESSOR ASSY,FINAL
COMPRESSOR ASSY,FINAL LGE 5417A20012B Contact Us For Availability
View on Model
559011
FAN ASSEMBLY - AXIAL
FAN ASSEMBLY - AXIAL LGE 5900AR1167B Contact Us For Availability
View on Model
731273
INSTALL PART ASSY WB-CHASSIS
INSTALL PART ASSY WB-CHASSIS LGE 3127AR3403A Contact Us For Availability
View on Model
W0CZZ
CAPACITOR
CAPACITOR LGE 6120AR2359V Contact Us For Availability
View on Model
W0CZZ
Capacitor,Unclassified
Capacitor,Unclassified LGE 0CZZA20003A Contact Us For Availability
View on Model
