Model Whirlpool M16FN-10 MICROWAVE – Common Parts & Diagrams
02 - CONTROL PANEL
01 - BASE & CAVITY
04 - TURNTABLE
03 - DOOR
Common parts from model Whirlpool M16FN-10 MICROWAVE
1
BOARD, CONTROL MP16-10P WPL 01210057 Contact Us For Availability
1
BAFFLE WPL Y02320017 Contact Us For Availability
1
BEARING WPL Y02440001 Contact Us For Availability
1
CHOKE, FILLER WPL 02100149 Contact Us For Availability
2
CONTROL PANEL WPL 02100229 Contact Us For Availability
2
BLADE, BUSHING ASSY WPL 04021411 Contact Us For Availability
2
CHANNEL, BASE -L WPL 02090016 Contact Us For Availability
2
GLASS, DOOR WPL 02220111 Contact Us For Availability
3
PANEL, SWITCH WPL 02060368 Contact Us For Availability
3
MOTOR, BLOWER WPL 01110029 Contact Us For Availability
3
BRACKET, BLOWER WPL 02030124 Contact Us For Availability
3
HOUSING, BLOWER WPL 02170131 Contact Us For Availability
3
BLOWER ASSY WPL 04021299 Contact Us For Availability
3
WHEEL, BLOWER WPL Y01110017 Contact Us For Availability
3
CHANNEL, BASE -R WPL 02090017 Contact Us For Availability
3
LATCH, PAWL WPL 02190062 Contact Us For Availability
4
BRACKET WPL 02030123 Contact Us For Availability
4
COVER, MOTOR T/T WPL 02300052 Contact Us For Availability
4
DOOR, OUTER PANEL WPL 02100218 Contact Us For Availability
5
BUSHING WPL Y03140008 Contact Us For Availability
5
GEAR, TURNTABLE WPL Y02450002 Contact Us For Availability
5
PIN, LATCH PAWL WPL Y03070040 Contact Us For Availability
6
CABINET WPL 02140078 Contact Us For Availability
6
MOTOR, TURNTABLE WPL Y01110030 Contact Us For Availability
6
DOOR PLATE CHOKE ASSY WPL 04021503 Contact Us For Availability
7
CAP, RACK WPL 02100147 Contact Us For Availability
7
ROLLER WPL 02210010 Contact Us For Availability
7
SEAL, BOTTOM WPL Y02120162 Contact Us For Availability
8
SCREW WPL 03010151 Contact Us For Availability
8
SEAL HINGE WPL Y02120160 Contact Us For Availability
9
CAVITY WPL 04021566 Contact Us For Availability
9
SHELF ASSY WPL 02280042 Contact Us For Availability
9
SEAL, LATCH WPL Y02120159 Contact Us For Availability
10
PLATE, POPCORN WPL 02040094 Contact Us For Availability
10
TURNTABLE WPL 02460006 Contact Us For Availability
10
SEAL, TOP WPL Y02120161 Contact Us For Availability
11
SPRING WPL 03180032 Contact Us For Availability
12
HOLDER, FUSE WPL Y01100044 Contact Us For Availability
12
WINDOW, TEMPERED GLASS WPL 02220101 Contact Us For Availability
13
CLIP, STIRRER WPL 03110066 Contact Us For Availability
14
CORD WPL 01080053 Contact Us For Availability
15
COVER WPL 02140061 Contact Us For Availability
16
COVER, MAGNETRON WPL 02300034 Contact Us For Availability
16
COVER, INSULATION BOTTOM WPL 02300053 Contact Us For Availability
17
COVER, STIRRER WPL 02300056 Contact Us For Availability
18
DIODE ASSY. WPL Y04010219 Contact Us For Availability
19
DUCT, MAG EXHT WPL 02170134 Contact Us For Availability
20
ELEMENT, BROWNING WPL Y01270002 Contact Us For Availability
21
FOOT, BASE WPL Y02230008 Contact Us For Availability
22
FUSE 15A 125V WPL Y01050005 Contact Us For Availability
23
HINGE ASSY, LOWER WPL 04021343 Contact Us For Availability
23
BRACKET, HINGE (UPPER) WPL 04021344 Contact Us For Availability
24
INSULATION WPL 02480004 Contact Us For Availability
25
INSULATION WPL 02480011 Contact Us For Availability
26
INSULATION, BOTTOM WPL 02480012 Contact Us For Availability
27
INSULATION, LEFT WPL 02480009 Contact Us For Availability
28
INSULATION, RIGHT WPL 02480008 Contact Us For Availability
29
INSULATION, TOP WPL 02480007 Contact Us For Availability
30
INSULATION, WRAPPER WPL 02480010 Contact Us For Availability
31
WASHER WPL 03040038 Contact Us For Availability
32
LENS, BULB WPL Y02400007 Contact Us For Availability
33
BULB, LIGHT WPL Y01060024 Contact Us For Availability
34
MAGNETRON, MAGIC CHEF WPL 01040006 Contact Us For Availability
35
NUT, SHAFT STIRRER WPL 03050007 Contact Us For Availability
36
PAN, BROLIER WPL 02490001 Contact Us For Availability
37
REFLECTOR, HEAT WPL 02040089 Contact Us For Availability
38
PLATE, TAPPING WPL 02040091 Contact Us For Availability
39
TRANSFORMER, HV WPL 01130033 Contact Us For Availability
40
RACK, WIRE WPL 02410005 Contact Us For Availability
41
SHAFT, STIRRER WPL 02360058 Contact Us For Availability
42
LAMP SOCKET WPL 01100033 Contact Us For Availability
43
SUPPORT, RACK WPL 02010031 Contact Us For Availability
44
INTERLOCK SWITCH ASSY, UPPER WPL 01140063 Contact Us For Availability
44
INTERLOCK SWITCH ASSY, LOWER WPL 01140064 Contact Us For Availability
44
SWITCH, INTERLOCK WPL 04021412 Contact Us For Availability
45
SWITCH, TEMP LIMIT WPL 01180015 Contact Us For Availability
46
SWITCH, TEMP LIMIT WPL 01180016 Contact Us For Availability
46
WIRE HARNESS WPL 04010269 Contact Us For Availability
46
WIRE, LEAD HV WPL 04060538 Contact Us For Availability
46
WIRE, LEAD HV WPL 04060539 Contact Us For Availability
46
1/4X1/4 X 18`` WPL 8270P00360 Contact Us For Availability
46
1/2X1/2X18 FOAM TAPE WPL 8270P00560 Contact Us For Availability
46
1/2X1/2X36 FOAM TAPE WPL 8270P00660 Contact Us For Availability
47
MANUAL, USE & CARE WPL Y06030062 Contact Us For Availability
× ![]()
