Model LG LS301CE – Common Parts & Diagrams
Diagram 0
Common parts from model LG LS301CE
135311
GRILLE ASSEMBLY,DISCHARGE(INDO LGE 3531A10056L Contact Us For Availability
135312
GRILLE ASSEMBLY,FRONT(INDOOR) LGE 3531A10058B Contact Us For Availability
135313
GRILLE ASSEMBLY,INLET LGE 3531A10060R Contact Us For Availability
135314
GRILLE,INLET LGE 3530A20087A Contact Us For Availability
135315
GRILLE ASSEMBLY,FRONT(SINGLE) LGE 3531A10250T Contact Us For Availability
137213-1
PANEL ASSEMBLY,SIDE LGE 1A00202F Contact Us For Availability
137213-2
Panel Assembly,Side LGE 3A02284N Contact Us For Availability
146811
MOTOR ASSY LGE 4681AR2727B Contact Us For Availability
152302
FILTER(MECH),A/C LGE 5230A10001A Contact Us For Availability
152313
FILTER ASSEMBLY,DEODORIZER LGE 5231A20032F Contact Us For Availability
159901
VANE,HORIZONTAL LGE 5990A20003A Contact Us For Availability
249951
CONTROL BOX ASSEMBLY,INDOOR LGE 4995A10115F Contact Us For Availability
263230
THERMISTOR ASSEMBLY INDOOR LGE 6323A20002C Contact Us For Availability
263230-1
THERMISTOR ASSEMBLY LGE 6323A20002L Contact Us For Availability
268712
PWB(PCB) ASSY,DISPLAY LGE 6871A20108A Contact Us For Availability
268714
PWB(PCB) ASSEMBLY,MAIN(DC) LGE 6871A20588B Contact Us For Availability
342801
BEARING LGE 4280A20001A Contact Us For Availability
346810
MOTOR ASSEMBLY,INDOOR LGE 4681A22002A Contact Us For Availability
352150
HOSE ASSY,DRAIN LGE 5251AR1222P Contact Us For Availability
352390-1
Guide Assembly,Air LGE 5239A10001A Contact Us For Availability
352390-2
Guide Assembly,Air LGE 5239A10001B Contact Us For Availability
354210
EVAPORATOR ASSY,FIRST LGE 5421A20058A Contact Us For Availability
359011-1
FAN ASSY,CROSS FLOW LGE 5901AR2441F Contact Us For Availability
359011-2
FAN ASSY,CROSS FLOW LGE 5901AR2441G Contact Us For Availability
430410
Base Assembly,Outdoor LGE 3041AP2741Z Contact Us For Availability
435301
GRILLE,DISCHARGE LGE 3530A20007J Contact Us For Availability
435511
COVER ASSY,CONTROL(OUTDOOR) LGE 3551AR7184T Contact Us For Availability
437210
PANEL ASSY,FRONT SUB_AGL32105602 is HCI Assem LGE 1A00197C Contact Us For Availability
447910
Barrier Assembly,Outdoor LGE 4791A30004G Contact Us For Availability
549610
Bracket Assembly,Motor(Outdoor) LGE 2A01035T Contact Us For Availability
552111
TUBE ASSEMBLY,CAPILLARY LGE 5211A20034X Contact Us For Availability
552203-1
VALVE,SERVICE LGE 2A00393H Contact Us For Availability
552203-2
VALVE,SERVICE LGE 2A00392N Contact Us For Availability
554031
Condenser Assembly,Bending LGE 6140AP2096A Contact Us For Availability
554160-1
COMPRESSOR SET LGE 2520UHAK2AA Contact Us For Availability
554160-2
COMPRESSOR SET LGE 2520UKVK2BA Contact Us For Availability
559010
Fan Assembly,Propeller LGE 1A00195G Contact Us For Availability
649950
CONTROL BOX ASSEMBLY,OUTDOOR LGE 4995A20383H Contact Us For Availability
668711
PWB(PCB) ASSEMBLY,MAIN(OUTDOOR LGE 6871A10184B Contact Us For Availability
733010
PLATE ASSY,INSTALL LGE 3301A10001A Contact Us For Availability
× ![]()
