Model Whirlpool KBFN502EBS06 – Common Parts &amp; Diagrams

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $18.76

8003RP Whirlpool Refrigerator 25' 1/4" Copper In Stock WPL 8003RP $31.53

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $4.82

W10273367 Whirlpool Refrigerator Door Hinge In Stock WPL W10273367 $23.49

W10569886 Whirlpool Refrigerator Slide Backorder WPL W10569886 $153.93

W10569891 Whirlpool Refrigerator Slide Backorder WPL W10569891 $156.43

W10633566 Whirlpool Ladder Backorder WPL W10633566 $70.19

W10782423 Whirlpool Refrigerator Ring Backorder WPL W10782423 $15.41

W10847927 Whirlpool Refrigerator Extension In Stock WPL W10847927 $50.90

NLA:TOUCH-UP Backorder WPL W10917540 $10.38

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $75.04

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $111.80

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $30.40

WPW10570404 Whirlpool Glass Shelf Backorder WPL WPW10570404 $224.62

1

W10529578 Whirlpool Refrigerator Crisper Draw Backorder WPL W10529578 $241.75

1

W11655239 Whirlpool Inverter Box In Stock WPL W11655239 $212.86

1

Backorder WPL W11747345 $405.17

2

W10744328 Whirlpool Refrigerator Support Asse In Stock WPL W10744328 $216.15

2

Front Assembly, Crisper Pan WPL W10529563 Contact Us For Availability

2

Cover, Upper Unit WPL W11708444 Contact Us For Availability

2

Screw WPL 489473 Contact Us For Availability

3

2307584 Whirlpool Refrigerator Grommet Backorder WPL 2307584 $13.64

3

W10529585 Whirlpool Refrigerator Crisper Draw Backorder WPL W10529585 $215.93

3

W10555476 Whirlpool Refrigerator Evaporator C Backorder WPL W10555476 $152.28

3

W10665413 Whirlpool Refrigerator Mat Backorder WPL W10665413 $178.59

3

W11557671 Whirlpool Refrigerator Compressor In Stock WPL W11557671 $548.98

3

Panel, Unit Back WPL W11708420 Contact Us For Availability

4

W10672300 Whirlpool Refrigerator Slide Assemb Backorder WPL W10672300 $47.99

4

W11435372 Whirlpool Cover-Unit In Stock WPL W11435372 $28.91

4

W11661567 Whirlpool Wire Harness Backorder WPL W11661567 $63.23

4

W11673500 Whirlpool Door Hinge In Stock WPL W11673500 $86.94

4

WPW10138054 Whirlpool Refrigerator Cabinet Ro In Stock WPL WPW10138054 $20.53

4

Front Assembly, Deli Pan WPL W10529567 Contact Us For Availability

4

Cover, Condenser Support WPL W11695783 Contact Us For Availability

5

W10569854 Whirlpool Support Backorder WPL W10569854 $54.38

5

W10672302 Whirlpool Refrigerator Slide Backorder WPL W10672302 $47.99

5

W11712700 Whirlpool Insulation Backorder WPL W11712700 $54.58

5

WPW10739408-includeCORE Whirlpool WPW10739408 Backorder WPL WPW10739408-includeCORE $227.12

5

Screw WPL W10061370 Contact Us For Availability

6

W10109030 Whirlpool Refrigerator Screw Backorder WPL W10109030 $9.35

6

W10529548 Whirlpool Refrigerator Cantilever B Backorder WPL W10529548 $176.84

6

W10569853 Whirlpool Support Backorder WPL W10569853 $54.38

6

W10839793 Whirlpool Refrigerator Nameplate In Stock WPL W10839793 $31.36

6

W11661108 Whirlpool Grommet Backorder WPL W11661108 $9.12

6

WP1163283 Whirlpool Air Conditioner Screw Backorder WPL WP1163283 $4.82

7

2309230 Whirlpool Refrigerator Clip Backorder WPL 2309230 $10.02

7

W10273369 Whirlpool Refrigerator Door Hinge Backorder WPL W10273369 $23.46

7

WP488729 Whirlpool Refrigerator Door Screw In Stock WPL WP488729 $3.46

7

WP488787 Whirlpool Refrigerator Screw Backorder WPL WP488787 $6.83

7

WP489399 Whirlpool Refrigerator Screw In Stock WPL WP489399 $3.46

7

Support, Condenser (Left Hand) WPL W11695311 Contact Us For Availability

8

2309231 Whirlpool Refrigerator Clip Backorder WPL 2309231 $35.25

8

W10215666 Whirlpool Refrigerator Screw Backorder WPL W10215666 $5.85

8

WP8281164 Whirlpool Refrigerator Screw In Stock WPL WP8281164 $6.29

8

Egg Bin Assembly WPL 2221071 Contact Us For Availability

8

Insulation, Unit Back Panel WPL W11244166 Contact Us For Availability

8

Support, Condenser (Right Hand) WPL W11695312 Contact Us For Availability

9

W10600690 Whirlpool Refrigerator Ice Pan Backorder WPL W10600690 $185.38

9

SUPPORT Backorder WPL W10699426 $17.03

9

W11247667 Whirlpool Refrigerator Cover Backorder WPL W11247667 $69.95

9

Cover, Safety Switch WPL W11356980 Contact Us For Availability

W10555493 Whirlpool Clip Backorder WPL W10555493 $13.99

W10600687 Whirlpool Front Pan Backorder WPL W10600687 $50.97

W11396715 Whirlpool Refrigerator Evaporator M In Stock WPL W11396715 $114.58

W11517121 Whirlpool Tube Assembly Backorder WPL W11517121 $42.16

W10555480 Whirlpool Refrigerator Shield Backorder WPL W10555480 $103.33

W10568445 Whirlpool Refrigerator Jumper Wire Backorder WPL W10568445 $46.61

W10600700 Whirlpool Refrigerator Pan Backorder WPL W10600700 $217.96

WP308544 Whirlpool Screw In Stock WPL WP308544 $4.82

WPW10624574-includeCORE Whirlpool WPW10624574 Backorder WPL WPW10624574-includeCORE $231.95

W10555484 Whirlpool Refrigerator Housing Backorder WPL W10555484 $130.96

W10600696 Whirlpool Refrigerator Front Panel Backorder WPL W10600696 $50.97

W11500952 Whirlpool Refrigerator Hinge Bushin Backorder WPL W11500952 $20.37

WP2203075 Whirlpool Refrigerator Spacer Backorder WPL WP2203075 $11.67

2256328 Whirlpool Bracket Assembly Backorder WPL 2256328 $46.45

W10538315 Whirlpool Refrigerator Housing Backorder WPL W10538315 $56.87

W10600736 Whirlpool Refrigerator Spacer Backorder WPL W10600736 $190.94

W10633565 Whirlpool Refrigerator Ladder Backorder WPL W10633565 $67.70

W11291510 Whirlpool Refrigerator Valve Backorder WPL W11291510 $47.00

W10600734 Whirlpool Refrigerator Spacer Backorder WPL W10600734 $231.49

W10826105 Whirlpool Refrigerator Pro Service Backorder WPL W10826105 $98.89

W11661569 Whirlpool Thermistor Backorder WPL W11661569 $66.93

WP965173 Whirlpool Dishwasher Screw Backorder WPL WP965173 $6.51

W10710401 Whirlpool Refrigerator Deflector Backorder WPL W10710401 $91.21

W11484836 Whirlpool Refrigerator Module In Stock WPL W11484836 $15.94

WP489069 Whirlpool Compactor Screw In Stock WPL WP489069 $4.99

WPW10568583 Whirlpool Refrigerator Glass Shel Backorder WPL WPW10568583 $230.04

2005032 Whirlpool Refrigerator Leveler In Stock WPL 2005032 $126.45

W10127710 Whirlpool Refrigerator Plate Backorder WPL W10127710 $15.88

W11678257 Whirlpool Fan Backorder WPL W11678257 $191.00

HEATER-PAN Backorder WPL W11797349 $337.52

WP2006346 Whirlpool Refrigerator Washer In Stock WPL WP2006346 $6.87

WPW10570403 Whirlpool Refrigerator Glass Shel Backorder WPL WPW10570403 $211.55

Condenser WPL W11601407 Contact Us For Availability

2318189 Whirlpool Refrigerator Drip Pan Backorder WPL 2318189 $96.75

W10538317 Whirlpool Refrigerator Housing Backorder WPL W10538317 $56.49

W10701859 Whirlpool Refrigerator Wine Rack Backorder WPL W10701859 $13.15

WP2316859 Whirlpool Refrigerator Bushing In Stock WPL WP2316859 $37.95

Wire Assembly, HV WPL W11442534 Contact Us For Availability

2306117 Whirlpool Refrigerator Slide Backorder WPL 2306117 $189.57

W10311524 Whirlpool Refrigerator FreshFlow Ai In Stock WPL W10311524 $6.24

W11218690 Whirlpool Refrigerator Door Hinge In Stock WPL W11218690 $47.39

WPW10578274 Whirlpool Refrigerator Glass Shel In Stock WPL WPW10578274 $250.91

Tube, Heat Loop WPL W11602253 Contact Us For Availability

2306116 Whirlpool Refrigerator Slide Backorder WPL 2306116 $210.17

W10569850 Whirlpool Spacer Backorder WPL W10569850 $46.16

GROMMET Backorder WPL W10587113 $10.00

SCREW Backorder WPL W10808291 $7.82

W10852725 Whirlpool Refrigerator Grommet In Stock WPL W10852725 $5.99

W11246413 Whirlpool Refrigerator Inlet Valve In Stock WPL W11246413 $120.11

2310195 Whirlpool Refrigerator Wire Jumper Backorder WPL 2310195 $80.03

SCREW Backorder WPL 8533950 $7.53

W10529544 Whirlpool Refrigerator Cantilever B Backorder WPL W10529544 $191.90

W10569847 Whirlpool Refrigerator Track Backorder WPL W10569847 $71.65

WP2004994 Whirlpool Refrigerator Hinge Bushin Backorder WPL WP2004994 $4.82

2006617 Whirlpool Refrigerator Bracket Backorder WPL 2006617 $59.25

520965 Whirlpool Refrigerator Support Backorder WPL 520965 $19.90

W10569887 Whirlpool Refrigerator Slide Backorder WPL W10569887 $153.93

W10600630 Whirlpool Refrigerator Support Backorder WPL W10600630 $94.84

W11109499 Whirlpool Refrigerator Tube In Stock WPL W11109499 $25.05

22

W10414681 Whirlpool Bracket Backorder WPL W10414681 $51.21

22

W10585157 Whirlpool Refrigerator Support Backorder WPL W10585157 $249.45

22

W11403572 Whirlpool Refrigerator Bracket Backorder WPL W11403572 $42.99

23

W10569892 Whirlpool Refrigerator Slide Backorder WPL W10569892 $156.43

23

W11127829 Whirlpool Refrigerator Condenser Mo In Stock WPL W11127829 $124.81

23

WPW10121140 Whirlpool Refrigerator Housing In Stock WPL WPW10121140 $193.02

24

W10555472 Whirlpool Refrigerator Insulation Backorder WPL W10555472 $25.45

24

WPW10139483 Whirlpool Refrigerator Condenser In Stock WPL WPW10139483 $54.43

25

W11649687 Whirlpool Evaporator Backorder WPL W11649687 $192.21

25

Orifice, Condenser Fan WPL W11723572 Contact Us For Availability

26

W10740077 Whirlpool Refrigerator Gasket Backorder WPL W10740077 $17.61

26

W11751592 Whirlpool Sleeve In Stock WPL W11751592 $13.22

27

WP3400886 Whirlpool Refrigerator Screw Backorder WPL WP3400886 $4.82

27

WP8533993 Whirlpool Refrigerator Screw Backorder WPL WP8533993 $6.83

28

WP2210509 Whirlpool Refrigerator Tub Valve Backorder WPL WP2210509 $62.27

28

Bracket, 3-Way Valve WPL W11233715 Contact Us For Availability

W10337505 Whirlpool Refrigerator Door Hinge Backorder WPL W10337505 $85.24

W10628280 Whirlpool Trim Assembly Backorder WPL W10628280 $55.23

W11647768 Whirlpool Refrigerator Valve Backorder WPL W11647768 $85.68

WP488163 Whirlpool Refrigerator Screw In Stock WPL WP488163 $4.82

30

W10672548 Whirlpool Refrigerator Shim Backorder WPL W10672548 $13.30

30

Trim, Center Support (Grey, Crisper) WPL W10604673 Contact Us For Availability

30

Tube, Condenser/Drier WPL W11602254 Contact Us For Availability

31

CLIP Backorder WPL W10741189 $10.48

31

Tube, Process WPL W11482820 Contact Us For Availability

32

W11411871-includeCORE Whirlpool W11411871 Ref Backorder WPL W11411871-includeCORE $284.05

32

W11624204 Whirlpool Screw Backorder WPL W11624204 $8.89

32

WPW10188549 Whirlpool Refrigerator Front Gril Backorder WPL WPW10188549 $87.41

33

Stud Assembly, Shelf (Gray, Includes Screw) WPL W10789219 Contact Us For Availability

33

Wire Assembly, Humidity Sensor WPL W11534165 Contact Us For Availability

34

2310196 Whirlpool Refrigerator Power Cord Backorder WPL 2310196 $60.22

34

WP8533928 Whirlpool Refrigerator Screw In Stock WPL WP8533928 $6.60

35

Bracket, Control Assembly WPL W11435371 Contact Us For Availability

36

W11234470 Whirlpool Refrigerator Clamp Backorder WPL W11234470 $14.02

36

WP2320509 Whirlpool Refrigerator Door Cam Backorder WPL WP2320509 $19.11

37

Switch, Power Disconnect WPL W11311927 Contact Us For Availability

38

W11511844 Whirlpool Tube Backorder WPL W11511844 $42.16

39

W11238395 Whirlpool Refrigerator Filter Cap In Stock WPL W11238395 $43.41

39

Wire Assembly, LV WPL W11442533 Contact Us For Availability

40

W10550831 Whirlpool Refrigerator Housing Backorder WPL W10550831 $56.30

41

W10625259 Whirlpool Refrigerator Jumper Wire Backorder WPL W10625259 $129.79

42

Screw WPL W10068580 Contact Us For Availability

43

Waterline, Cust Connect WPL W10577944 Contact Us For Availability

43

Bracket, Condenser Bottom WPL W11695784 Contact Us For Availability

44

W11368839 Whirlpool Refrigerator Inverter Box In Stock WPL W11368839 $184.47

45

W11177574 Whirlpool Refrigerator Screw Backorder WPL W11177574 $8.89

46

2314023 Whirlpool Bushing Backorder WPL 2314023 $31.08

47

WP2221240 Whirlpool Refrigerator Heater In Stock WPL WP2221240 $125.15

48

W10482373 Whirlpool Refrigerator Jumper Wire In Stock WPL W10482373 $81.25

49

W10619899 Whirlpool Refrigerator Water Tube Backorder WPL W10619899 $28.21

50

2317847 Whirlpool Refrigerator Water Tube Backorder WPL 2317847 $52.95

51

WP1106508 Whirlpool Refrigerator Gasket Backorder WPL WP1106508 $6.17

52

W10635851 Whirlpool Refrigerator Water Tube In Stock WPL W10635851 $55.05

53

W11225845 Whirlpool Refrigerator Inlet Valve In Stock WPL W11225845 $120.11

57

W10782424 Whirlpool Refrigerator Ring Backorder WPL W10782424 $15.41

58

W11298172 Whirlpool Refrigerator Extension Backorder WPL W11298172 $54.25
