Whirlpool JUW248RBRS01 WINE CELLAR Parts List

1

Drain Pan WPL W10163193 Contact Us For Availability

View on Model

1

DOOR ASSEMBLY (INCLUDES GASKET) WPL W10163181 Contact Us For Availability

View on Model

1

WINE RACK TOP & MIDDLE WPL W10238032 Contact Us For Availability

View on Model

2

W11241702 Whirlpool Refrigerator Washer Backorder WPL W11241702 $8.39

View on Model

2

Bracket, Defrost Timer WPL 4344773 Contact Us For Availability

View on Model

2

RUBBER SUPPORT WPL 4344867 Contact Us For Availability

View on Model

3

W11609704 Whirlpool Refrigerator Defrost Time In Stock WPL W11609704 $71.46

View on Model

3

RAIL ASSEMBLY WPL W10238029 Contact Us For Availability

View on Model

3

GASKET-PUSH PLATE WPL W10163191 Contact Us For Availability

View on Model

4

4344797 Whirlpool Screw Backorder WPL 4344797 $9.71

View on Model

4

W10239363 Whirlpool Refrigerator Door Hinge Backorder WPL W10239363 $54.13

View on Model

4

Hinge, Bottom (Black) WPL W10163066 Contact Us For Availability

View on Model

4

WINE RACK, LOWER WPL W10187313 Contact Us For Availability

View on Model

5

4344754 Whirlpool Refrigerator Door Hinge Backorder WPL 4344754 $56.51

View on Model

5

WP4344776 Whirlpool Refrigerator Start Device In Stock WPL WP4344776 $118.04

View on Model

5

Heater, Defrost WPL 4344746 Contact Us For Availability

View on Model

5

Hinge, Top (Black) WPL W10162991 Contact Us For Availability

View on Model

5

Ladder, Shelf (Left Side) WPL 4344842 Contact Us For Availability

View on Model

5

Ladder, Shelf (Right Side) WPL 4344843 Contact Us For Availability

View on Model

6

4344755 Whirlpool Refrigerator Spacer Backorder WPL 4344755 $11.97

View on Model

6

MOUNTING PLATE, COMPRESSOR WPL W10238066 Contact Us For Availability

View on Model

6

SCREW WPL 4344794 Contact Us For Availability

View on Model

7

4344756 Whirlpool Refrigerator Spacer Backorder WPL 4344756 $12.68

View on Model

7

Grommet, Fan Motor WPL 4344778 Contact Us For Availability

View on Model

7

WASHER WPL 4344795 Contact Us For Availability

View on Model

8

WP4344779 Whirlpool Refrigerator Grommet Backorder WPL WP4344779 $4.82

View on Model

8

Actuator, Switch WPL 4344757 Contact Us For Availability

View on Model

8

SHELF SUPPORT WPL W10239365 Contact Us For Availability

View on Model

9

4344758 Whirlpool Refrigerator Bracket Backorder WPL 4344758 $11.47

View on Model

9

W10772873 Whirlpool Screw Backorder WPL W10772873 $34.85

View on Model

9

W11106296 Whirlpool Refrigerator Leveler Backorder WPL W11106296 $10.50

View on Model

9

Door Stop (Black) WPL W10163074 Contact Us For Availability

View on Model

9

SCREW WPL 4344851 Contact Us For Availability

View on Model

10

WPW10238068 Whirlpool Refrigerator Gasket Backorder WPL WPW10238068 $240.38

View on Model

10

WPW10299090 Whirlpool Refrigerator Condenser In Stock WPL WPW10299090 $156.85

View on Model

10

TRIM, TOP AND MIDDLE RACKS WPL W10239372 Contact Us For Availability

View on Model

11

Control Box WPL 4344898 Contact Us For Availability

View on Model

11

Handle, Door WPL W10163184 Contact Us For Availability

View on Model

11

Baffle, Air WPL 4344782 Contact Us For Availability

View on Model

11

RUBBER SUPPORT WPL 4344866 Contact Us For Availability

View on Model

12

Door Skin (Stainless Steel) WPL W10163185 Contact Us For Availability

View on Model

12

Door Skin (Black) WPL W10163187 Contact Us For Availability

View on Model

12

Fan Blade WPL 4344783 Contact Us For Availability

View on Model

12

Trim, Lower Rack WPL 4344884 Contact Us For Availability

View on Model

13

4344760 Whirlpool Refrigerator Washer Backorder WPL 4344760 $9.81

View on Model

13

4344771 Whirlpool Refrigerator Clip Backorder WPL 4344771 $73.02

View on Model

13

4344784 Whirlpool Bracket Backorder WPL 4344784 $158.99

View on Model

13

4344886 Whirlpool Support Backorder WPL 4344886 $139.24

View on Model

13

Support, Bumper (Left) WPL 4344885 Contact Us For Availability

View on Model

14

4344785 Whirlpool Bracket Backorder WPL 4344785 $125.42

View on Model

14

4344788 Whirlpool Refrigerator Spacer Backorder WPL 4344788 $119.11

View on Model

14

Screw (Right) WPL 4344914 Contact Us For Availability

View on Model

14

Screw (Left) WPL 4344915 Contact Us For Availability

View on Model

15

4344786 Whirlpool Back Cover Backorder WPL 4344786 $158.99

View on Model

15

WP4344859 Whirlpool Refrigerator Thermostat Backorder WPL WP4344859 $179.40

View on Model

15

Plate WPL W10178446 Contact Us For Availability

View on Model

15

SHELF SUPPORT WPL W10239366 Contact Us For Availability

View on Model

16

4344796 Whirlpool Refrigerator Screw Backorder WPL 4344796 $10.30

View on Model

16

WP1188476 Whirlpool Air Conditioner Capacitor Backorder WPL WP1188476 $125.90

View on Model

16

Screw (Black) WPL W10162988 Contact Us For Availability

View on Model

16

SHELF SUPPORT WPL W10239369 Contact Us For Availability

View on Model

17

WP4344767 Whirlpool Refrigerator Switch Backorder WPL WP4344767 $40.56

View on Model

17

WP4344836 Whirlpool Clip Backorder WPL WP4344836 $58.23

View on Model

17

Screw, Lower Hinge (Quantity 1) WPL 4344906 Contact Us For Availability

View on Model

17

SCREW, LOWER HINGE (QUANTITY 3) WPL W10243104 Contact Us For Availability

View on Model

17

SHELF SUPPORT WPL W10239370 Contact Us For Availability

View on Model

18

W10163276 Whirlpool Refrigerator Trap Backorder WPL W10163276 $62.45

View on Model

18

W10837731 Whirlpool Screw Assembly In Stock WPL W10837731 $5.02

View on Model

18

SCREW W/WASHER WPL W10162986 Contact Us For Availability

View on Model

19

W10243123 Whirlpool Refrigerator Screw Backorder WPL W10243123 $10.30

View on Model

19

Power Cord WPL 4344861 Contact Us For Availability

View on Model

19

TOP COVER WPL W10238187 Contact Us For Availability

View on Model

20

4344801 Whirlpool Refrigerator Screw Backorder WPL 4344801 $10.30

View on Model

20

4344829 Whirlpool Tie Wire Backorder WPL 4344829 $9.71

View on Model

20

BOTTOM COVER WPL W10238184 Contact Us For Availability

View on Model

21

W10163273 Whirlpool Refrigerator Tube Backorder WPL W10163273 $67.94

View on Model

21

W10238024 Whirlpool Wire Backorder WPL W10238024 $59.22

View on Model

21

Screw WPL W10163183 Contact Us For Availability

View on Model

22

4344907 Whirlpool Trim Backorder WPL 4344907 $148.72

View on Model

22

W10238026 Whirlpool Refrigerator Sensor Backorder WPL W10238026 $93.87

View on Model

23

4344820 Whirlpool Refrigerator Support Backorder WPL 4344820 $148.43

View on Model

23

4344821 Whirlpool Refrigerator Support Backorder WPL 4344821 $94.38

View on Model

23

W10238022 Whirlpool Refrigerator Clip Backorder WPL W10238022 $52.76

View on Model

23

W10238025 Whirlpool Refrigerator Sensor Backorder WPL W10238025 $89.15

View on Model

24

W10163274 Whirlpool Pad Backorder WPL W10163274 $83.23

View on Model

24

WPW10238180 Whirlpool Refrigerator Display Backorder WPL WPW10238180 $240.80

View on Model

25

TEMPERATURE SEPARATOR ASSY WPL W10282166 Contact Us For Availability

View on Model

26

4344826 Whirlpool Refrigerator Screw Backorder WPL 4344826 $10.30

View on Model

26

SCREW WPL 4344825 Contact Us For Availability

View on Model

27

4344792 Whirlpool Refrigerator Bi-Metal Backorder WPL 4344792 $79.15

View on Model

27

SCREW WPL W11380570 No Longer Available

View on Model

28

8201787 Whirlpool Refrigerator Compressor Backorder WPL 8201787 $374.42

View on Model

29

SCREW WPL 4344834 Contact Us For Availability

View on Model

30

WP90767 Whirlpool Screw In Stock WPL WP90767 $4.26

View on Model

31

TRANSFORMER WPL W10238070 Contact Us For Availability

View on Model

32

W10163278 Whirlpool Refrigerator Thermostat Backorder WPL W10163278 $182.85

View on Model

33

Harness, Wire WPL 4344877 Contact Us For Availability

View on Model

33

Bracket, Thermostat WPL 4344864 Contact Us For Availability

View on Model

38

4344858 Whirlpool Refrigerator Switch Backorder WPL 4344858 $73.48

View on Model

40

W10801436 Whirlpool Refrigerator Sensor Backorder WPL W10801436 $91.98

View on Model

41

W10244414 Whirlpool Refrigerator Bi-Metal Def Backorder WPL W10244414 $71.59

View on Model

NI

W10204809 Whirlpool Screw Backorder WPL W10204809 $55.35

View on Model

NI

CLEANER, STAINLESS STEEL (12 OZ) WPL 8171420 Contact Us For Availability

View on Model

NI

REFRIGERANT CHARGE (3.5 OUNCES (R-134A)) WPL NP Contact Us For Availability

View on Model

NI

LED SPACER WPL W10238031 Contact Us For Availability

View on Model

NI

SUPPORT WPL W10238189 Contact Us For Availability

View on Model

NI

SEAL WPL W10239384 Contact Us For Availability

View on Model

NI

SUPPORT SPACER WPL W10239385 Contact Us For Availability

View on Model
