Whirlpool JUR248RBCX00 REFRIGERATOR Parts List

1

Drain Pan WPL W10163193 Contact Us For Availability

View on Model

1

Door Assembly WPL W10167688 Contact Us For Availability

View on Model

1

GLASS, SHELF WPL 4344869 Contact Us For Availability

View on Model

2

HARNS-WIRE WPL W10310989 Contact Us For Availability

View on Model

2

Bracket, Defrost Timer WPL 4344773 Contact Us For Availability

View on Model

2

Bracket, Shelf (2) WPL 4344868 Contact Us For Availability

View on Model

3

W11609704 Whirlpool Refrigerator Defrost Time In Stock WPL W11609704 $71.46

View on Model

3

Door Bin WPL W10175958 Contact Us For Availability

View on Model

3

Trim, Rear WPL 4344872 Contact Us For Availability

View on Model

4

4344797 Whirlpool Screw Backorder WPL 4344797 $9.71

View on Model

4

W10239363 Whirlpool Refrigerator Door Hinge Backorder WPL W10239363 $54.13

View on Model

4

Shelf, Crisper WPL W10167588 Contact Us For Availability

View on Model

5

4344754 Whirlpool Refrigerator Door Hinge Backorder WPL 4344754 $56.51

View on Model

5

WP4344776 Whirlpool Refrigerator Start Device In Stock WPL WP4344776 $118.04

View on Model

5

Heater, Defrost WPL 4344746 Contact Us For Availability

View on Model

5

Ladder, Shelf (Left Side) WPL 4344842 Contact Us For Availability

View on Model

5

Ladder, Shelf (Right Side) WPL 4344843 Contact Us For Availability

View on Model

6

4344804 Whirlpool Spacer Backorder WPL 4344804 $11.97

View on Model

6

Mounting Plate, Compressor WPL W10175971 Contact Us For Availability

View on Model

6

SCREW WPL 4344794 Contact Us For Availability

View on Model

7

4344798 Whirlpool Spacer Backorder WPL 4344798 $11.97

View on Model

7

Grommet, Fan Motor WPL 4344778 Contact Us For Availability

View on Model

7

WASHER WPL 4344795 Contact Us For Availability

View on Model

8

WP4344779 Whirlpool Refrigerator Grommet Backorder WPL WP4344779 $4.82

View on Model

8

Actuator, Switch WPL 4344757 Contact Us For Availability

View on Model

8

Trim, Front WPL W10167590 Contact Us For Availability

View on Model

9

4344802 Whirlpool Bracket Assembly Backorder WPL 4344802 $13.02

View on Model

9

W10772873 Whirlpool Screw Backorder WPL W10772873 $34.85

View on Model

9

W11106296 Whirlpool Refrigerator Leveler Backorder WPL W11106296 $10.50

View on Model

9

SCREW W/WASHER WPL W10162986 Contact Us For Availability

View on Model

10

WPW10238068 Whirlpool Refrigerator Gasket In Stock WPL WPW10238068 $240.38

View on Model

10

WPW10299090 Whirlpool Refrigerator Condenser In Stock WPL WPW10299090 $156.85

View on Model

11

W11241702 Whirlpool Refrigerator Washer Backorder WPL W11241702 $8.39

View on Model

11

Control Box WPL 4344765 Contact Us For Availability

View on Model

11

Baffle, Air WPL 4344782 Contact Us For Availability

View on Model

12

GASKET-PUSH PLATE WPL W10163191 Contact Us For Availability

View on Model

12

Fan Blade WPL 4344783 Contact Us For Availability

View on Model

13

4344760 Whirlpool Refrigerator Washer Backorder WPL 4344760 $9.81

View on Model

13

4344771 Whirlpool Refrigerator Clip Backorder WPL 4344771 $73.02

View on Model

13

4344784 Whirlpool Bracket Backorder WPL 4344784 $158.99

View on Model

14

4344785 Whirlpool Bracket Backorder WPL 4344785 $125.42

View on Model

14

4344803 Whirlpool Spacer Backorder WPL 4344803 $122.27

View on Model

15

4344786 Whirlpool Back Cover Backorder WPL 4344786 $158.99

View on Model

15

W11176247 Whirlpool Refrigerator Thermostat Backorder WPL W11176247 $156.06

View on Model

16

4344796 Whirlpool Refrigerator Screw Backorder WPL 4344796 $10.30

View on Model

16

WP1188476 Whirlpool Air Conditioner Capacitor Backorder WPL WP1188476 $125.90

View on Model

17

WP4344767 Whirlpool Refrigerator Switch Backorder WPL WP4344767 $40.56

View on Model

17

WP4344836 Whirlpool Clip Backorder WPL WP4344836 $58.23

View on Model

17

Screw, Lower Hinge (Quantity 1) WPL 4344906 Contact Us For Availability

View on Model

18

W10163276 Whirlpool Refrigerator Trap Backorder WPL W10163276 $62.45

View on Model

18

SCREW WPL 4344827 Contact Us For Availability

View on Model

19

W10243123 Whirlpool Refrigerator Screw Backorder WPL W10243123 $10.30

View on Model

19

Power Cord WPL 4344830 Contact Us For Availability

View on Model

20

4344801 Whirlpool Refrigerator Screw Backorder WPL 4344801 $10.30

View on Model

20

4344829 Whirlpool Tie Wire Backorder WPL 4344829 $9.71

View on Model

21

WP4344828 Whirlpool Refrigerator Dryer Tube Backorder WPL WP4344828 $20.84

View on Model

21

SCREW WPL 4344825 Contact Us For Availability

View on Model

22

Bushing WPL 4344838 Contact Us For Availability

View on Model

23

4344820 Whirlpool Refrigerator Support Backorder WPL 4344820 $148.43

View on Model

23

4344821 Whirlpool Refrigerator Support Backorder WPL 4344821 $94.38

View on Model

23

Clip, Bushing WPL 4344831 Contact Us For Availability

View on Model

24

W10163274 Whirlpool Pad Backorder WPL W10163274 $83.23

View on Model

25

4344822 Whirlpool Refrigerator Wire Harness Backorder WPL 4344822 $214.32

View on Model

25

4344826 Whirlpool Refrigerator Screw Backorder WPL 4344826 $10.30

View on Model

27

4344792 Whirlpool Refrigerator Bi-Metal Backorder WPL 4344792 $79.15

View on Model

27

SCREW WPL W11380570 No Longer Available

View on Model

28

8201787 Whirlpool Refrigerator Compressor Backorder WPL 8201787 $374.42

View on Model

29

SCREW WPL 4344834 Contact Us For Availability

View on Model

30

WP90767 Whirlpool Screw In Stock WPL WP90767 $4.26

View on Model

31

4344907 Whirlpool Trim Backorder WPL 4344907 $148.72

View on Model

32

Evaporator Fan Motor WPL 4344865 Contact Us For Availability

View on Model

32

Support, Drain WPL 4344908 Contact Us For Availability

View on Model

33

Harness, Wire WPL 4344877 Contact Us For Availability

View on Model

36

4344899 Whirlpool Refrigerator Bracket Backorder WPL 4344899 $118.65

View on Model

NI

HOUS-CNTRL WPL W10235660 Contact Us For Availability

View on Model

NI

Installation Kit, Door Panel WPL 4344818 Contact Us For Availability

View on Model
