Model LG HBLG7000H – Common Parts & Diagrams
Diagram 0
Diagram 1
Common parts from model LG HBLG7000H
135312
GRILLE ASSEMBLY,FRONT(SINGLE) LGE 3531A10128B Contact Us For Availability
135313
GRILLE,INLET LGE 3530A10027A Contact Us For Availability
137215
PANEL ASSEMBLY,CONTROL LGE 3721A10018K Contact Us For Availability
147581
LOUVER,HORIZONTAL LGE 4758A20002D Contact Us For Availability
147582
LOUVER,VERTICAL LGE 4758A30008A Contact Us For Availability
149410
KNOB ASSY LGE 4941A30011A Contact Us For Availability
149980
SHROUD LGE 4998A10001A Contact Us For Availability
249950
CONTROL BOX ASSEMBLY,SINGLE LGE 4995A20119N Contact Us For Availability
269310
THERMOSTAT LGE 2H01127B Contact Us For Availability
346811
MOTOR ASSY,SINGLE LGE 4681A20027A Contact Us For Availability
349600
MOUNT,MOTOR LGE 4960A20002A Contact Us For Availability
352113
TUBE,DISCHARGE LGE 5210A20119D Contact Us For Availability
352390
AIR GUIDE ASSEMBLY LGE 5239A30002N Contact Us For Availability
354210
EVAPORATOR ASSY LGE 5421A20036C Contact Us For Availability
552111
TUBE ASSY,CAPILLARY LGE 5211A30260D Contact Us For Availability
554030
CONDENSER ASSY,FIRST LGE 5403A20024B Contact Us For Availability
554160
COMPRESSOR SET LGE 2520UAEC2DA Contact Us For Availability
559010
FAN ASSEMBLY - AXIAL LGE 5900AR1167B Contact Us For Availability
731373
INSTALL PART ASSY WB-CHASSIS LGE 3127AR3403A Contact Us For Availability
753010
HEATER ASSEMBLY,ELECTRIC LGE 5301A20013A Contact Us For Availability
W0CZZ
CAPACITOR,DRAWING LGE 6120AR2359Y Contact Us For Availability
× ![]()
