Model LG GR-K243UG – Common Parts & Diagrams
Diagram 0
Diagram 1
Diagram 2
Diagram 3
Common parts from model LG GR-K243UG
104A
Leg,Adjust LGE 4778JA2016A Contact Us For Availability
125C
Door Assembly,Fresh Room LGE ADC30696701 Contact Us For Availability
147A
Bucket,Side Dish LGE 5074JA1044C Contact Us For Availability
147B
Bucket,Side Dish LGE 5074JA1062B Contact Us For Availability
147C
Cover Assembly,Bucket LGE 3551JA1053G Contact Us For Availability
148B
Cover,Tray LGE MCK30274601 Contact Us For Availability
155A
Supporter,Panel LGE 4980JA2095C Contact Us For Availability
155B
Supporter,Panel LGE 4980JA2095D Contact Us For Availability
155C
Cap,Decor Refrigerator LGE 5078JA2049P Contact Us For Availability
201A
Door Foam Assembly,Refrigerator LGE 5433JA1156J Contact Us For Availability
201B
Door Foam Assembly,Refrigerator LGE 5433JA1155J Contact Us For Availability
203B
GASKET ASSEMBLY,DOOR LGE 4987JA1023B Contact Us For Availability
204A
Holder Assembly,Bracket LGE AEJ30582701 Contact Us For Availability
206C
Cap,Decor Refrigerator LGE 5078JA2047L Contact Us For Availability
206F
Cap,Decor Refrigerator LGE 5078JA2048E Contact Us For Availability
206G
Cap,Decor Refrigerator LGE 5078JA2048F Contact Us For Availability
207A
Decor,Glass Door LGE MCR32155121 Contact Us For Availability
207B
Decor,Glass Door LGE MCR32155122 Contact Us For Availability
207C
Decor,Glass Door LGE MCR32155117 Contact Us For Availability
212A
Handle Assembly,Base LGE AED30709904 Contact Us For Availability
212B
Handle Assembly,Base LGE AED30711004 Contact Us For Availability
212G
MARK LGE 3846JD1007B Contact Us For Availability
231A
Door Assembly,Semi Refrigerator LGE ADC30708707 Contact Us For Availability
231B
Door Assembly,Semi Refrigerator LGE ADC30708607 Contact Us For Availability
234A
Cover,Lead Wire LGE MCK30268701 Contact Us For Availability
234B
Cover,Lead Wire LGE MCK30268601 Contact Us For Availability
236A
Decor,Case LGE 3806JA1176L Contact Us For Availability
236B
Decor,Case LGE 3806JA1176M Contact Us For Availability
236C
Decor,Door LGE 3806JA1181G Contact Us For Availability
236D
Decor,Door LGE 3806JA1181H Contact Us For Availability
241A
Basket,Door LGE 5004JA1207B Contact Us For Availability
242A
Cover Assembly,Bucket LGE ACQ30697301 Contact Us For Availability
242B
Roller LGE MHA30275101 Contact Us For Availability
242D
Handle,Refrigerator LGE MEB30203401 Contact Us For Availability
243A
Stopper,Door LGE MJB30230301 Contact Us For Availability
248A
Basket Assembly,Door LGE 5005JA1013V Contact Us For Availability
248B
Rail,Side LGE 5218JA2005A Contact Us For Availability
248C
GUIDE,DRAWER LGE 4974JA1095B Contact Us For Availability
248D
Bucket Assembly,Side Dish LGE 5075JA1025M Contact Us For Availability
248E
Bucket Assembly,Side Dish LGE 5075JA1025N Contact Us For Availability
248G
GUIDE,DRAWER LGE 4974JA1095A Contact Us For Availability
249A
COVER,BANK LGE 3550JA2274A Contact Us For Availability
249B
Basket,Door LGE 5004JA1148C Contact Us For Availability
249D
Basket,Door LGE 5004JA1150D Contact Us For Availability
249G
Basket Assembly,Door LGE AAP30653901 Contact Us For Availability
250A
Tray,Drawer LGE 3390JA1241B Contact Us For Availability
270A
Frame Assembly,Display LGE ADV30692103 Contact Us For Availability
281B
Cap,Hinge LGE MBL30229302 Contact Us For Availability
281C
Cap,Hinge LGE 5006JA2064C Contact Us For Availability
281D
Cap,Hinge LGE 5006JA2064D Contact Us For Availability
281E
Cap,Hinge LGE MBL30229301 Contact Us For Availability
304A
COVER ASSEMBLY,BACK-M/C LGE 3551JA1076B Contact Us For Availability
307A
Compressor,Set Assembly LGE 2521C-A5721 Contact Us For Availability
309A
Thermistor Assembly,PTC LGE 6748C-0001B Contact Us For Availability
310B
PIPE ASSEMBLY,JOINT LGE 5201JA1099D Contact Us For Availability
312A
RUBBER,SEAT LGE 5040JA3035A Contact Us For Availability
315A
COMP BASE ASSEMBLY,STD LGE 3103JA1038A Contact Us For Availability
318A
DRIER ASSEMBLY LGE 5851JA2005E Contact Us For Availability
319A
Tray,Drip LGE 3390JA0027B Contact Us For Availability
319C
Guide,Fan LGE 4974JA1093B Contact Us For Availability
323B
CONDENSER ASSEMBLY,WIRE LGE 5403JA1056A Contact Us For Availability
410H
CAPACITOR-S LGE J513-00012P Contact Us For Availability
411A
Power Cord Assembly LGE 6411JB2025V Contact Us For Availability
420A
MOTOR(MECH),COOLING LGE 4680JB1035U Contact Us For Availability
420B
Cooling Pack LGE 3005JA3001B Contact Us For Availability
500A
PCB Assembly,Main LGE 6871JB1246N Contact Us For Availability
502B
Case,PCB LGE 3110JA1100B Contact Us For Availability
604A
Deodorizer LGE 5986JA2004B Contact Us For Availability
604B
Cover,Deodorizer LGE MCK31780202 Contact Us For Availability
618A
BRACKET,MOTOR LGE 4810JA2109A Contact Us For Availability
618B
Bracket,Valve LGE 4810JA3174A Contact Us For Availability
619A
VALVE ASSEMBLY,GAS LGE 5221JB1001B Contact Us For Availability
× ![]()
