Model Electrolux FRFG2011AV00 – Common Parts &amp; Diagrams

*

TUBE Backorder WCI 140031581121 $11.80

*

242200102 Frigidaire Refrigerator Clip Backorder WCI 242200102 $7.86

*

5304519089 Frigidaire Refrigerator Screw Backorder WCI 5304519089 $4.20

*

5304523053 Frigidaire Refrigerator Connector Backorder WCI 5304523053 $17.94

*

5304534887 Frigidaire Clamp Backorder WCI 5304534887 $5.84

*

DOOR ADJUST KIT Backorder WCI 5304538857 $2.93

*

Screw, PF AB PFZ PF, 3.5x1.27x19 WCI 808337901 Contact Us For Availability

1

140018267090 Frigidaire Cover Backorder WCI 140018267090 $4.57

1

EVAPORATOR Backorder WCI 140040632048 $61.27

1

SHELF Backorder WCI 140293841015 $51.44

1

140296276029 Frigidaire Door Assembly In Stock WCI 140296276029 $160.53

1

5304536682 Frigidaire Assembly Dispenser Backorder WCI 5304536682 $46.99

2

DEFROST HEATER Backorder WCI 140010582355 $81.60

2

COVER Backorder WCI 140056575024 $98.28

2

DOOR ASSEMBLY Backorder WCI 140296276011 $263.07

2

243297618 Frigidaire Ice Maker Backorder WCI 243297618 $94.36

2

5304519199 Frigidaire Refrigerator Spring Backorder WCI 5304519199 $4.21

2

COVER Backorder WCI 5304535279 $7.76

2A

Cover crisper, w/glass WCI 140056571015 Contact Us For Availability

2B

SUPPORT Backorder WCI 140293784025 $13.11

2C

SUPPORT Backorder WCI 140293784017 $13.11

2D

Support, crisper, center WCI 5304529190 Contact Us For Availability

2E

GASKET Backorder WCI 140026444038 $8.37

3

EVAPORATION Backorder WCI 140053997015 $42.51

3

5304511146 Frigidaire Refrigerator Nameplate In Stock WCI 5304511146 $32.54

3

5304529181 Frigidaire Hinge Backorder WCI 5304529181 $13.64

3

5304536683 Frigidaire Paddle Backorder WCI 5304536683 $8.81

4

5304519124 Frigidaire Roller Assembly Backorder WCI 5304519124 $11.62

4

5304529142 Frigidaire Support Backorder WCI 5304529142 $7.94

4

5304529182 Frigidaire Hinge Assembly Backorder WCI 5304529182 $17.02

4

BEARING Backorder WCI 5304529298 $6.29

5

5304529184 Frigidaire Switch Backorder WCI 5304529184 $14.70

5

CONTROL-ELECTRICAL Backorder WCI 973925060998003 $114.52

5

Bearing, upper, RH door WCI 5304529296 Contact Us For Availability

5

Water tube, inlet, w/connection, IM, 360 mm WCI 140031581022 Contact Us For Availability

6

SENSOR Backorder WCI 140217317019 $14.83

6

DRAWER Backorder WCI 140291856015 $46.35

6

COVER Backorder WCI 5304526830 $5.24

6

5304529163 Frigidaire Refrigerator Valve Asse Backorder WCI 5304529163 $92.30

6

Cover, main electronic, board, rear WCI 140014689016 Contact Us For Availability

7

SENSOR Backorder WCI 140026775019 $3.03

7

140222839072 Frigidaire Compressor Backorder WCI 140222839072 $175.63

7

5304529177 Frigidaire Hinge Assembly Backorder WCI 5304529177 $19.56

8

5304519066 Frigidaire Screw Backorder WCI 5304519066 $2.09

8

5304529157 Frigidaire Refrigerator Manifold Backorder WCI 5304529157 $65.95

8

5304529178 Frigidaire Pin Backorder WCI 5304529178 $6.81

8

811978901 Frigidaire Refrigerator Grommet Backorder WCI 811978901 $5.76

8

GASKET Backorder WCI 8119885567 $44.34

8

Shaft, telescopic rail WCI 140020925040 Contact Us For Availability

9

140025649033 Frigidaire Gear Assembly Backorder WCI 140025649033 $2.94

9

5304524607 Frigidaire Clamp Backorder WCI 5304524607 $2.09

9

Frigidaire EPTWFU01 PureSource Ultra II Refri In Stock WCI EPTWFU01 $65.16

140010465163 Frigidaire Bearing Backorder WCI 140010465163 $3.59

5304529172 Frigidaire Appliance Pad In Stock WCI 5304529172 $5.24

5304533534 Frigidaire Cover Backorder WCI 5304533534 $9.28

Backorder WCI 5304534879 $4.57

140010465148 Frigidaire Bearing Backorder WCI 140010465148 $4.23

CLAMP Backorder WCI 5304519152 $6.29

5304529176 Frigidaire Bracket Assembly Backorder WCI 5304529176 $25.17

Foot Assembly, cabinet WCI 5304537479 Contact Us For Availability

12

CONTROL Backorder WCI 140231161245 $119.48

12

5304529175 Frigidaire Bracket Backorder WCI 5304529175 $24.14

12

Cover, screw, water filter WCI 5304529187 Contact Us For Availability

13

VALVE Backorder WCI 140024774022 $76.15

13

5304519084 Frigidaire Screw Assembly Backorder WCI 5304519084 $2.09

13

5304529180 Frigidaire Refrigerator Mullion As Backorder WCI 5304529180 $90.26

13A

DRAIN PAN Backorder WCI 140012625038 $11.25

13A

Grommet, mullion WCI 8119728023 Contact Us For Availability

13B

TUBE COIL Backorder WCI 140028303067 $19.68

13B

Spring, flip mullion WCI 140013719012 Contact Us For Availability

13C

HEATER Backorder WCI 140217415011 $35.53

13D

BEARING Backorder WCI 140045805011 $0.89

13E

Hinge, flip mullion, center WCI 140013717024 Contact Us For Availability

AIR TOWER Backorder WCI 140007489168 $88.22

SEAL Backorder WCI 140224757033 $6.13

5304519080 Frigidaire Refrigerator Hinge Backorder WCI 5304519080 $7.89

Bracket, manifold WCI 5304529156 Contact Us For Availability

14A

DRAIN Backorder WCI 140012626010 $7.99

14B

TUBE Backorder WCI 140100808082 $14.92

14C

SPACER Backorder WCI 140036378010 $2.87

BIN DOOR Backorder WCI 140288984010 $22.81

5304529132 Frigidaire Refrigerator Harness Backorder WCI 5304529132 $15.05

Gasket, freezer door, magnet WCI 4055727905 Contact Us For Availability

Grommet, rear tube WCI 5304529159 Contact Us For Availability

16

5304529131 Frigidaire Refrigerator Damper Ass Backorder WCI 5304529131 $52.80

16

Cap, tubing WCI 5304529162 Contact Us For Availability

17

VALVE COVER Backorder WCI 140293895011 $22.44

17

Cover, screw, LH, air tower WCI 5304529134 Contact Us For Availability

17

Tube, jumper, heater WCI 140020522052 Contact Us For Availability

18

BIN DOOR Backorder WCI 140288983012 $23.81

18

DOOR ASSEMBLY Backorder WCI 140296276037 $178.05

18

COVER Backorder WCI 5304529135 $5.24

19

Filter, air WCI 242047809 Contact Us For Availability

5304529151 Frigidaire Refrigerator Tube Backorder WCI 5304529151 $6.29

5304529166 Frigidaire Screw Backorder WCI 5304529166 $4.21

Cover, air filter, fresh food WCI 140050812217 Contact Us For Availability

Tube Assembly, inlet water, w/connector WCI 5304538933 Contact Us For Availability

21

240396803 Frigidaire Clamp Backorder WCI 240396803 $5.24

21

5304519177 Frigidaire Refrigerator Clip Backorder WCI 5304519177 $5.76

21

811976001 Frigidaire Assembly-Valve In Stock WCI 811976001 $6.29

22

5304519178 Frigidaire Refrigerator Grommet Backorder WCI 5304519178 $5.24

22

5304536756 Frigidaire Cord Backorder WCI 5304536756 $27.60

22

811949503 Frigidaire Screw Backorder WCI 811949503 $2.09

23

809069207 Frigidaire Refrigerator Motor In Stock WCI 809069207 $87.56

24

5304529138 Frigidaire Grommet Backorder WCI 5304529138 $6.29

24

A19676501 Frigidaire Refrigerator Filter Drie In Stock WCI A19676501 $72.40

25

5304520944 Frigidaire Refrigerator Sensor In Stock WCI 5304520944 $15.15

25

GROMMET Backorder WCI 811972801 $5.25

26

811975001 Frigidaire Refrigerator Shroud Backorder WCI 811975001 $10.61

26

Base assembly compressor WCI 8588078227127 Contact Us For Availability

27

WASHER Backorder WCI 140242549016 $0.89

28

Blade, evaporator fan WCI 811699604 No Longer Available

29

COVER Backorder WCI 140059931059 $80.90

31

USER INTERFACE,DISPLAY,ASSEMBL Backorder WCI 140040668174 $87.71

32

Cover, grid, air return WCI 140008964052 Contact Us For Availability

33

SWITCH Backorder WCI 140205244027 $6.64

34

COVER Backorder WCI 807917002 $6.29

35

LED PCB Backorder WCI 140155609047 $12.83

36

LENS Backorder WCI 5304519099 $8.39

37

811949401 Frigidaire Refrigerator Screw In Stock WCI 811949401 $3.66

41

Screw, tapping PH, m4 x 16 WCI 5304529133 Contact Us For Availability

43

Harness, temperature, fresh food WCI 140126760044 Contact Us For Availability

44

FAN ASSEMBLY Backorder WCI 8588119754089 $80.77

45

COVER Backorder WCI 8588119716054 $0.24
