Model Electrolux FCWD2727AWF WALL OVEN, ELECTRIC, DOUBLE – Common Parts &amp; Diagrams

2

139027805 Frigidaire Shield Backorder WCI 139027805 $50.46

2A

139015900 Frigidaire Shield Backorder WCI 139015900 $9.98

2B

139038901 Frigidaire Oven Housing Backorder WCI 139038901 $24.36

3A

5304525458 Frigidaire Trim Assembly Backorder WCI 5304525458 $29.21

5

BRACKET, CONDUIT MTG. WCI 5304530364 Contact Us For Availability

6

139011900 Frigidaire Oven Rack Backorder WCI 139011900 $43.79

6

139014203 Frigidaire Oven Baffle Backorder WCI 139014203 $89.84

7

318372017 Frigidaire Insulation Backorder WCI 318372017 $12.72

7

PANEL, SERVICE, MAIN BACK WCI 5304506960 Contact Us For Availability

7A

318372018 Frigidaire Insulation Backorder WCI 318372018 $11.07

8

139085803 Frigidaire Glass Backorder WCI 139085803 $56.76

9

LINER Backorder WCI 139002917 $83.22

10

5304414648 Frigidaire Oven Screw In Stock WCI 5304414648 $11.09

11

807545501 Frigidaire Oven Seal Backorder WCI 807545501 $58.25

12

808136601 Frigidaire Oven Switch Backorder WCI 808136601 $34.46

12A

807641201 Frigidaire Shield Assembly Backorder WCI 807641201 $50.49

13

DOOR ASMY Backorder WCI 5304525466 $229.61

13A

DOOR ASSEMBLY, OUTER, GLASS/STEEL, BLACK/WHIT WCI 5304525467 Contact Us For Availability

15

5304530343 Frigidaire Lamp Assembly Backorder WCI 5304530343 $25.49

17

318264735 Frigidaire Spacer Backorder WCI 318264735 $50.46

23

808930405 Frigidaire Hinge Assembly Backorder WCI 808930405 $73.38

29

316517600 Frigidaire Oven Spacer Backorder WCI 316517600 $9.42

37

5304525427 Frigidaire Probe In Stock WCI 5304525427 $38.85

39

HANDLE, DOOR, WHITE WCI 5304531835 Contact Us For Availability

56

TRIM, SIDE, WHITE, RH WCI 5304525445 Contact Us For Availability

56A

5303324184 Frigidaire Wall Oven Range Screw Backorder WCI 5303324184 $11.09

56A

TRIM, SIDE, WHITE, LH WCI 5304525446 Contact Us For Availability

57

5304506949 Frigidaire Box Backorder WCI 5304506949 $88.50

58

5304506952 Frigidaire Insulation Backorder WCI 5304506952 $56.46

58A

139001701 Frigidaire Insulation Backorder WCI 139001701 $47.70

58C

5304506954 Frigidaire Insulation Backorder WCI 5304506954 $27.73

58D

5304506965 Frigidaire Insulation Backorder WCI 5304506965 $9.33

58E

5304506966 Frigidaire Insulation Backorder WCI 5304506966 $10.48

59

139015700 Frigidaire Duct Backorder WCI 139015700 $34.37

59

139027600 Frigidaire Oven Duct Backorder WCI 139027600 $67.10

62

5304535277 Frigidaire Terminal Block Backorder WCI 5304535277 $2.92

66

5304514924 Frigidaire Element Backorder WCI 5304514924 $89.29

67

5304506946 Frigidaire Oven Element Backorder WCI 5304506946 $79.40

70

139000601 Frigidaire Oven Shield Backorder WCI 139000601 $52.66

71

139022001 Frigidaire Shield Backorder WCI 139022001 $48.83

80

139021101 Frigidaire Bracket Assembly Backorder WCI 139021101 $11.64

82

5304506947 Frigidaire Shield Backorder WCI 5304506947 $74.85

83

5304506951 Frigidaire Shield Appliance Backorder WCI 5304506951 $58.21

86

808930503 Frigidaire Receptacle Backorder WCI 808930503 $13.43

87

BRACKET, CABLE MTG. WCI 139021901 Contact Us For Availability

88

5304506963 Frigidaire Cover Assembly Backorder WCI 5304506963 $21.62

89

5304528835 Frigidaire Motor Backorder WCI 5304528835 $56.85

90

TRIM, OVEN BOTTOM, WHITE WCI 5304532943 Contact Us For Availability

99

318256201 Frigidaire Oven Bracket Backorder WCI 318256201 $44.35

107

5304527949 Frigidaire Cover Backorder WCI 5304527949 $145.58

108

139038303 Frigidaire Blower Assembly Backorder WCI 139038303 $78.68

109

5304525455 Frigidaire Blade Backorder WCI 5304525455 $10.53

111

316136600 Frigidaire Oven Range Lock Nut Backorder WCI 316136600 $14.94

119

5304538823 Frigidaire Safety Thermostat, 125C In Stock WCI 5304538823 $10.84

125

139008507 Frigidaire Motor Assembly Backorder WCI 139008507 $74.51

127

139042600 Frigidaire Tube Assembly Backorder WCI 139042600 $33.82

131

139027700 Frigidaire Oven Duct Backorder WCI 139027700 $57.12

142

SHEILD Backorder WCI 5304506953 $30.52

161

BRACKET Backorder WCI 5304535278 $6.57

185

318531800 Frigidaire Oven Spacer Backorder WCI 318531800 $9.96

264

139003501 Frigidaire Oven Trim Assembly Backorder WCI 139003501 $28.91

272

139021700 Frigidaire Oven Tube Backorder WCI 139021700 $13.86

316021109 Frigidaire Oven Screw In Stock WCI 316021109 $15.49

387856311 Frigidaire Screw Backorder WCI 387856311 $2.24

5304471184 Frigidaire Screw Assembly Backorder WCI 5304471184 $4.96

5304526533 Frigidaire Screw Backorder WCI 5304526533 $1.68

SCREW Backorder WCI 5304528293 $2.24

INSTALL KIT Backorder WCI 5304531542 $27.62

5304532392 Frigidaire Harness Backorder WCI 5304532392 $160.27

5304532405 Frigidaire Harness In Stock WCI 5304532405 $108.58

HARNESS Backorder WCI 5304532411 $32.19

5304535368 Frigidaire Harness Backorder WCI 5304535368 $109.62

WCI 5304532408 WCI 5304532408 Contact Us For Availability

WCI 5304532410 WCI 5304532410 Contact Us For Availability

139022101 Frigidaire Insulation Backorder WCI 139022101 $12.75

316001017 Frigidaire Screw Backorder WCI 316001017 $2.24

316418900 Frigidaire Oven Screw Backorder WCI 316418900 $11.09

318165800 Frigidaire Oven Door Glass Spacer w Backorder WCI 318165800 $13.86

WCI 387872717 WCI 387872717 Contact Us For Availability

NIB

316205500 Frigidaire Oven Nut In Stock WCI 316205500 $8.87

NIC

5303289910 Frigidaire Oven Screw Backorder WCI 5303289910 $4.41
