EFMC527UIW1

Model EFMC527UIW1 – Common Parts & Diagrams

Common parts from model EFMC527UIW1

131202300 Frigidaire Screw

131202300 Frigidaire Screw Out of Stock WCI 131202300 $10.53

131205500 Frigidaire Screw

131205500 Frigidaire Screw In Stock WCI 131205500 $12.11

134154100 Frigidaire/Electrolux Screw 10-32X.

134154100 Frigidaire/Electrolux Screw 10-32X. In Stock WCI 134154100 $10.55

137150200 Frigidaire Terminal

137150200 Frigidaire Terminal Out of Stock WCI 137150200 $24.95

5304500486 Frigidaire Seal

5304500486 Frigidaire Seal In Stock WCI 5304500486 $36.61

5304506746 Frigidaire Shield

5304506746 Frigidaire Shield Out of Stock WCI 5304506746 $33.28

5304513601 Frigidaire Screw

5304513601 Frigidaire Screw Out of Stock WCI 5304513601 $9.96

5304521235 Frigidaire Harness

5304521235 Frigidaire Harness Out of Stock WCI 5304521235 $167.51

5308027429 Frigidaire Dryer High Temperature

5308027429 Frigidaire Dryer High Temperature In Stock WCI 5308027429 $42.71

137114000 Frigidaire Dryer Dryer Heater

137114000 Frigidaire Dryer Dryer Heater Out of Stock WCI 137114000 $197.47

5304521513 Frigidaire Board Assembly

5304521513 Frigidaire Board Assembly In Stock WCI 5304521513 $189.68

5304521446 Frigidaire/Electrolux Knob Assembl

5304521446 Frigidaire/Electrolux Knob Assembl In Stock WCI 5304521446 $203.58

134792100 Frigidaire Bracket

134792100 Frigidaire Bracket Out of Stock WCI 134792100 $22.73

5304505074 Frigidaire Spacer

5304505074 Frigidaire Spacer Out of Stock WCI 5304505074 $17.73

5304505313 Frigidaire Gasket

5304505313 Frigidaire Gasket Out of Stock WCI 5304505313 $58.80

5304505318 Frigidaire Gasket

5304505318 Frigidaire Gasket In Stock WCI 5304505318 $12.75

5304521401 Frigidaire Duct Assembly

5304521401 Frigidaire Duct Assembly Out of Stock WCI 5304521401 $114.29

137285100 Frigidaire Screw

137285100 Frigidaire Screw Out of Stock WCI 137285100 $13.29

5304515233 Frigidaire Tube

5304515233 Frigidaire Tube In Stock WCI 5304515233 $42.68

134711401 Frigidaire Dryer Thermal Fuse

134711401 Frigidaire Dryer Thermal Fuse In Stock WCI 134711401 $23.30

134935200 Frigidaire Screw

134935200 Frigidaire Screw Out of Stock WCI 134935200 $10.50

137032600 Frigidaire Washer Dryer Thermal Lim

137032600 Frigidaire Washer Dryer Thermal Lim In Stock WCI 137032600 $31.06

137578600 Frigidaire Cover

137578600 Frigidaire Cover Out of Stock WCI 137578600 $9.40

5304534450 Frigidaire Dryer Lint Screen and D

5304534450 Frigidaire Dryer Lint Screen and D In Stock WCI 5304534450 $109.49

5304505259 Frigidaire Screw

5304505259 Frigidaire Screw In Stock WCI 5304505259 $10.50

5304513609 Frigidaire Washer Blower Wheel

5304513609 Frigidaire Washer Blower Wheel In Stock WCI 5304513609 $45.48

5304505339 Frigidaire/Electrolux Blower Assem

5304505339 Frigidaire/Electrolux Blower Assem Out of Stock WCI 5304505339 $108.13

131749800 Frigidaire Spacer

131749800 Frigidaire Spacer Out of Stock WCI 131749800 $33.40

5304505064 Frigidaire Diffuser

5304505064 Frigidaire Diffuser Out of Stock WCI 5304505064 $11.09

137031800 Frigidaire Cushion

137031800 Frigidaire Cushion Out of Stock WCI 137031800 $6.63

137087000 Frigidaire Screw

137087000 Frigidaire Screw In Stock WCI 137087000 $8.85

5304513571 Frigidaire Duct Assembly

5304513571 Frigidaire Duct Assembly Out of Stock WCI 5304513571 $107.04

134792900 Frigidaire Protector

134792900 Frigidaire Protector Out of Stock WCI 134792900 $10.53

131168200 Frigidaire Dryer Screw

131168200 Frigidaire Dryer Screw In Stock WCI 131168200 $11.07

5304505441 Frigidaire Screw

5304505441 Frigidaire Screw Out of Stock WCI 5304505441 $4.98

5304513591 Frigidaire Thermistor

5304513591 Frigidaire Thermistor In Stock WCI 5304513591 $31.14

5304520302 Frigidaire Thermistor

5304520302 Frigidaire Thermistor In Stock WCI 5304520302 $39.37

131017900 Frigidaire Screw

131017900 Frigidaire Screw Out of Stock WCI 131017900 $11.09

5304499489 Frigidaire Washer Felt Seal

5304499489 Frigidaire Washer Felt Seal In Stock WCI 5304499489 $52.16

5304505111 Frigidaire Gasket

5304505111 Frigidaire Gasket Out of Stock WCI 5304505111 $60.99

137610700 Frigidaire Drum

137610700 Frigidaire Drum Out of Stock WCI 137610700 $373.56

131601000 Frigidaire/Electrolux P-1 Spring-ID

131601000 Frigidaire/Electrolux P-1 Spring-ID Out of Stock WCI 131601000 $40.48

5304513563 Frigidaire Panel

5304513563 Frigidaire Panel In Stock WCI 5304513563 $217.98

134793511 Frigidaire Idler Arm Assembly

134793511 Frigidaire Idler Arm Assembly In Stock WCI 134793511 $39.37

5304505081 Frigidaire Top Panel

5304505081 Frigidaire Top Panel In Stock WCI 5304505081 $171.93

134719300 Frigidaire Dryer 5 Rib Belt

134719300 Frigidaire Dryer 5 Rib Belt In Stock WCI 134719300 $52.68

5304513568 Frigidaire/Electrolux Latch Assemb

5304513568 Frigidaire/Electrolux Latch Assemb In Stock WCI 5304513568 $19.61

134813663 Frigidaire Washer Switch

134813663 Frigidaire Washer Switch In Stock WCI 134813663 $39.19

5304505258 Frigidaire Harness

5304505258 Frigidaire Harness Out of Stock WCI 5304505258 $33.26

5304525687 Frigidaire Main Board

5304525687 Frigidaire Main Board In Stock WCI 5304525687 $272.47

SUBS DEPENDING ON MODEL

SUBS DEPENDING ON MODEL Out of Stock RPI STOP MORE INFO REQUIRED $0.03

134242400 Frigidaire Washer Clamp

134242400 Frigidaire Washer Clamp In Stock WCI 134242400 $14.40

134690203 Frigidaire Base

134690203 Frigidaire Base Out of Stock WCI 134690203 $214.11

134712696 Frigidaire Panel

134712696 Frigidaire Panel Out of Stock WCI 134712696 $174.17

134712796 Frigidaire Panel

134712796 Frigidaire Panel In Stock WCI 134712796 $174.17

137029801 Frigidaire Bracket

137029801 Frigidaire Bracket Out of Stock WCI 137029801 $25.52

137034500 Frigidaire Clip

137034500 Frigidaire Clip Out of Stock WCI 137034500 $33.82

137560425 Frigidaire Panel

137560425 Frigidaire Panel Out of Stock WCI 137560425 $178.06

5304529782 Frigidaire Motor

5304529782 Frigidaire Motor In Stock WCI 5304529782 $242.90

131205100 Frigidaire Screw

131205100 Frigidaire Screw In Stock WCI 131205100 $11.09

5304515406 Frigidaire/Electrolux Console Asse

5304515406 Frigidaire/Electrolux Console Asse Out of Stock WCI 5304515406 $166.97

137610610 Frigidaire Vane

137610610 Frigidaire Vane In Stock WCI 137610610 $51.01

5304531882 Frigidaire/Electrolux VANE,DRUM,MI

5304531882 Frigidaire/Electrolux VANE,DRUM,MI In Stock WCI 5304531882 $17.50

3204267 Frigidaire Dryer Safety Thermostat

3204267 Frigidaire Dryer Safety Thermostat In Stock WCI 3204267 $84.85

5304523155 Frigidaire Washer Kit

5304523155 Frigidaire Washer Kit In Stock WCI 5304523155 $65.43

5304523154 Frigidaire Spacer

5304523154 Frigidaire Spacer In Stock WCI 5304523154 $17.75

5304523151 Frigidaire Shaft

5304523151 Frigidaire Shaft Out of Stock WCI 5304523151 $13.86

5304505133 Frigidaire/Electrolux Hinge Assemb

5304505133 Frigidaire/Electrolux Hinge Assemb Out of Stock WCI 5304505133 $118.68

5304523152 Frigidaire Washer Roller Wheel

5304523152 Frigidaire Washer Roller Wheel In Stock WCI 5304523152 $19.95

5304505121 Frigidaire Bulkhead

5304505121 Frigidaire Bulkhead Out of Stock WCI 5304505121 $165.29

134158001 Frigidaire Washer Levelling Leg

134158001 Frigidaire Washer Levelling Leg In Stock WCI 134158001 $14.97

5304515047 Frigidaire Bulkhead

5304515047 Frigidaire Bulkhead Out of Stock WCI 5304515047 $165.27

5304505010 Frigidaire Gasket

5304505010 Frigidaire Gasket In Stock WCI 5304505010 $72.65

5304505075 Frigidaire Bracket

5304505075 Frigidaire Bracket In Stock WCI 5304505075 $40.48

5304505115 Frigidaire Frame

5304505115 Frigidaire Frame In Stock WCI 5304505115 $132.58

5304505388 Frigidaire Frame

5304505388 Frigidaire Frame Out of Stock WCI 5304505388 $216.30

137241000 Frigidaire Screw

137241000 Frigidaire Screw In Stock WCI 137241000 $8.33

5304495002 Frigidaire Kit

5304495002 Frigidaire Kit In Stock WCI 5304495002 $51.01

131243700 Frigidaire Screw

131243700 Frigidaire Screw In Stock WCI 131243700 $1.65

137573900 Frigidaire/Electrolux Screw 1/4-14X

137573900 Frigidaire/Electrolux Screw 1/4-14X Out of Stock WCI 137573900 $5.55

5304504995 Frigidaire Inner Door

5304504995 Frigidaire Inner Door Out of Stock WCI 5304504995 $155.85

5304505012 Frigidaire Clamp

5304505012 Frigidaire Clamp Out of Stock WCI 5304505012 $14.63

5304504999 Frigidaire Dryer Door Glass

5304504999 Frigidaire Dryer Door Glass Out of Stock WCI 5304504999 $112.59

5304505119 Frigidaire Shield

5304505119 Frigidaire Shield Out of Stock WCI 5304505119 $90.40

5304521399 Frigidaire Lamp Assembly

5304521399 Frigidaire Lamp Assembly Out of Stock WCI 5304521399 $67.67

5304521476 Frigidaire Bracket

5304521476 Frigidaire Bracket Out of Stock WCI 5304521476 $14.42

137544800 Frigidaire Washer Valve

137544800 Frigidaire Washer Valve In Stock WCI 137544800 $62.10

137017200 Frigidaire Grommet

137017200 Frigidaire Grommet Out of Stock WCI 137017200 $2.78

5304529773 Frigidaire/Electrolux Nozzle Assem

5304529773 Frigidaire/Electrolux Nozzle Assem In Stock WCI 5304529773 $59.29

134742000 Frigidaire Plug

134742000 Frigidaire Plug Out of Stock WCI 134742000 $8.31

5304532444 Frigidaire Striker

5304532444 Frigidaire Striker Out of Stock WCI 5304532444 $8.44
