Model LG DMC24CA-1 – Common Parts & Diagrams
Diagram 0
Common parts from model LG DMC24CA-1
137213A
PANEL ASSEMBLY,SIDE LGE 1A00202F Contact Us For Availability
137213B
Panel Assembly,Side LGE 3A02284N Contact Us For Availability
263230B
Thermistor Assembly,NTC LGE EBG61107013 Contact Us For Availability
268711B
PCB Assembly,Main LGE 6871A21318D Contact Us For Availability
352113
Tube Assembly,Discharge LGE 5211A29916A Contact Us For Availability
435300
Grille,Rear LGE MDX59045502 Contact Us For Availability
435511
COVER ASSY,CONTROL(OUTDOOR) LGE 3550AR2886C Contact Us For Availability
435512
Cover Assembly,Top(Outdoor) LGE ACQ73019503 Contact Us For Availability
437210
PANEL ASSY,FRONT SUB_AGL32105602 is HCI Assem LGE 1A00197C Contact Us For Availability
437211
Panel Assembly,Front(Outdoor) LGE AGL32105602 Contact Us For Availability
447910
BARRIER ASSEMBLY,OUTDOOR LGE 4791A30004H Contact Us For Availability
546810
MOTOR ASSEMBLY,OUTDOOR LGE 4681A10030C Contact Us For Availability
548490
Accumulator LGE 4848A20006C Contact Us For Availability
552112
Tube Assembly,Condenser(In) LGE 5211A25715A Contact Us For Availability
552113
Tube Assembly,Condenser(Out) LGE 5211A25716A Contact Us For Availability
552117
Tube Assembly,Suction(Outdoor) LGE 5211A29913A Contact Us For Availability
552200
Valve,Expansion Body LGE 5220A90003B Contact Us For Availability
552203A
Valve,Service LGE MJX62472001 Contact Us For Availability
552203B
Valve,Service LGE MJX62451501 Contact Us For Availability
554160
Compressor Set,Korea LGE 2520UGKK2AA Contact Us For Availability
567480C
Thermistor,NTC LGE 6323A20028B Contact Us For Availability
649950
Case Assembly,Control(Outdoor) LGE 4995A10112M Contact Us For Availability
W0CZZA
CAPACITOR 400/35 GA-1015LC 121 LGE 3A00988B Contact Us For Availability
W6631
Harness,Single LGE 6631A20155P Contact Us For Availability
W6640A
Connector,Terminal Block LGE 3A00093A Contact Us For Availability
× ![]()
