Model LG DH5010B – Common Parts & Diagrams
Diagram 0
Common parts from model LG DH5010B
![BASE ASSY,WELD[SINGLE]](https://d2923bgwwiylbi.cloudfront.net/media/catalog/product/placeholder/default/image-coming-soon.jpg)
BASE ASSY,WELD[SINGLE] LGE 3041AD2007D Contact Us For Availability
130900
CABINET LGE 3090A10001J Contact Us For Availability
135312
GRILLE ASSY,FRONT LGE 3531A20012B Contact Us For Availability
147910
LGE 4791A10002C LGE 4791A10002C Contact Us For Availability
148380
TANK,BUCKET LGE 4838A20005A Contact Us For Availability
149410
KNOB ASSY LGE 4941A30002A Contact Us For Availability
152302
FILTER(MECH),AIR LGE 5230AD3005A Contact Us For Availability
249950
CONTROL BOX ASSY,SINGLE LGE 4995A20085G Contact Us For Availability
252160
HUMIDISTAT LGE 5216A20001A Contact Us For Availability
264110
POWER CORD ASSY LGE 6411A20001Q Contact Us For Availability
266003
SWITCH,ROTARY LGE 6600A20001A Contact Us For Availability
266011
SWITCH ASSY,MICRO LGE 6600A30003C Contact Us For Availability
269130
LAMP,NEON LGE 6912A30001F Contact Us For Availability
346811
MOTOR ASSY,SINGLE LGE 4681A20040A Contact Us For Availability
349600
MOUNT,MOTOR LGE 4960A20009A Contact Us For Availability
352113
TUBE ASSY,DISCHARGE SINGLE LGE 5211A10070A Contact Us For Availability
354211
EVAPORATOR ASSY,FIRST LGE 5421A10009A Contact Us For Availability
359012
FAN,TURBO LGE 5900A20007A Contact Us For Availability
549990
SHROUD ASSY LGE 4999A10001A Contact Us For Availability
550140
BUSHING LGE 4830A30005A Contact Us For Availability
554030
CONDENSER ASSY,FIRST LGE 5403A10008A Contact Us For Availability
554160
<NLA> COMPRESSOR LGE 5416AR2179J Contact Us For Availability
W0CZZ
CAPACITOR,DRAWING LGE 0CZZA20001Q Contact Us For Availability
× ![]()
