Model LG DH4010B – Common Parts & Diagrams
Diagram 0
Common parts from model LG DH4010B
![BASE ASSY,WELD[SINGLE]](https://d2923bgwwiylbi.cloudfront.net/media/catalog/product/placeholder/default/image-coming-soon.jpg)
BASE ASSY,WELD[SINGLE] LGE 3041AD2007D Contact Us For Availability
130900
CABINET LGE 3090A10001J Contact Us For Availability
135312
GRILLE ASSY,FRONT LGE 3531A20012B Contact Us For Availability
147910
LGE 4791A10002C LGE 4791A10002C Contact Us For Availability
148380
TANK,BUCKET LGE 4838A20005A Contact Us For Availability
149410
KNOB ASSY LGE 4941A30002A Contact Us For Availability
152302
FILTER(MECH),AIR LGE 5230AD3005A Contact Us For Availability
249950
CONTROL BOX ASSY,SINGLE LGE 4995A20085J Contact Us For Availability
252160
HUMIDISTAT LGE 5216A20001A Contact Us For Availability
264110
POWER CORD ASSY LGE 6411A20001Q Contact Us For Availability
266003
SWITCH,ROTARY LGE 6600A20001A Contact Us For Availability
266011
SWITCH ASSY,MICRO LGE 6600A30003C Contact Us For Availability
269120
LAMP,NEON LGE 6912A30001F Contact Us For Availability
269310
THERMOSTAT ASSY LGE 2H01127K Contact Us For Availability
346811
MOTOR ASSY,SINGLE LGE 4681A20040A Contact Us For Availability
349600
MOUNT,MOTOR LGE 4960A20009A Contact Us For Availability
352113
LGE 5211A10070C LGE 5211A10070C Contact Us For Availability
359012
FAN,TURBO LGE 5900A20007A Contact Us For Availability
549990
SHROUD ASSY LGE 4999A10001A Contact Us For Availability
550140
BUSHING LGE 4830A30005A Contact Us For Availability
552111
TUBE ASSY,CAPILLARY LGE 5211A10085D Contact Us For Availability
554030
CONDENSER ASSY,FIRST LGE 5403A10008C Contact Us For Availability
554160
COMPRESSOR SET LGE 2520UABC2FA Contact Us For Availability
W0CZZ
CAPACITOR,DRAWING LGE 0CZZA20001Q Contact Us For Availability
× ![]()
