Model LG CW-XC118HU WINDOW AC – Common Parts & Diagrams

130910
CABINET ASSY,SINGLE
CABINET ASSY,SINGLE LGE 3091AR2286Z Contact Us For Availability
View on Model
135301
GRILLE,FRONT
GRILLE,FRONT LGE 3530A10136B Contact Us For Availability
View on Model
135313
GRILLE,INLET
GRILLE,INLET LGE 3530A10137B Contact Us For Availability
View on Model
135316
GRILLE ASSEMBLY,FRONT(INDOOR)
GRILLE ASSEMBLY,FRONT(INDOOR) LGE 3531A10188B Contact Us For Availability
View on Model
135500
COVER,TERMINAL
COVER,TERMINAL LGE 3550U-L006A Contact Us For Availability
View on Model
147581
LOUVER,HORIZONTAL
LOUVER,HORIZONTAL LGE 4758AR2196B Contact Us For Availability
View on Model
147582
LOUVER
LOUVER LGE 4758AR3307C Contact Us For Availability
View on Model
147900
BARRIER,SINGLE
BARRIER,SINGLE LGE 4790A20022A Contact Us For Availability
View on Model
152302
Filter,Air
Filter,Air LGE 5231AR1152M Contact Us For Availability
View on Model
237200
PANEL,CONTROL
PANEL,CONTROL LGE 3720A10003A Contact Us For Availability
View on Model
238310
ESCUTCHEON
ESCUTCHEON LGE 3831A20031Z Contact Us For Availability
View on Model
249940
CONTROL BOX
CONTROL BOX LGE 4994AR1221A Contact Us For Availability
View on Model
249950
CONTROL BOX ASSEMBLY,SINGLE
CONTROL BOX ASSEMBLY,SINGLE LGE 4995A20104Z Contact Us For Availability
View on Model
263230
THERMISTOR ASSY
THERMISTOR ASSY LGE 6323A20003D Contact Us For Availability
View on Model
267110
REMOTE CONTROLLER ASSEMBLY
REMOTE CONTROLLER ASSEMBLY LGE 6711A90018C Contact Us For Availability
View on Model
268712
PWB(PCB) ASSEMBLY,DISPLAY
PWB(PCB) ASSEMBLY,DISPLAY LGE 6871A20195P Contact Us For Availability
View on Model
268714
PWB(PCB) ASSEMBLY,MAIN
PWB(PCB) ASSEMBLY,MAIN LGE 6871A10070K Contact Us For Availability
View on Model
349001
DAMPER
DAMPER LGE 4900AR7024B Contact Us For Availability
View on Model
349480
ORIFICE
ORIFICE LGE 4948A10005A Contact Us For Availability
View on Model
349600
MOUNT,MOTOR
MOUNT,MOTOR LGE 4960A20005A Contact Us For Availability
View on Model
352111
TUBE ASSEMBLY,CONNECTOR
TUBE ASSEMBLY,CONNECTOR LGE 5211AR7059W Contact Us For Availability
View on Model
352390
AIR GUIDE ASSEMBLY
AIR GUIDE ASSEMBLY LGE 5239A10006E Contact Us For Availability
View on Model
354210
EVAPORATOR ASSY,FIRST
EVAPORATOR ASSY,FIRST LGE 5421AR2912C Contact Us For Availability
View on Model
552111
TUBE ASSEMBLY,CAPILLARY
TUBE ASSEMBLY,CAPILLARY LGE 5211A20598E Contact Us For Availability
View on Model
554030
CONDENSER ASSY
CONDENSER ASSY LGE 5403AR2921A Contact Us For Availability
View on Model
554160
COMPRESSOR SET
COMPRESSOR SET LGE 2520UKQC2AA Contact Us For Availability
View on Model
558511
DRIER ASSEMBLY
DRIER ASSEMBLY LGE 5851A30001F Contact Us For Availability
View on Model
731273
INSTALL PART ASSEMBLY,SINGLE/REGISTERED TO MO
INSTALL PART ASSEMBLY,SINGLE/REGISTERED TO MO LGE 3127A10015G Contact Us For Availability
View on Model
738290
LGE 3828A20046E
LGE 3828A20046E LGE 3828A20046E Contact Us For Availability
View on Model
W0CZZ
CAPACITOR,DRAWING
CAPACITOR,DRAWING LGE 0CZZA20001N Contact Us For Availability
View on Model
