Model Electrolux CGGF3054KFG RANGE – Common Parts &amp; Diagrams

1

316408706 Frigidaire Oven Drawer Assembly In Stock WCI 316408706 $82.61

1

WCI 316557600 WCI 316557600 Contact Us For Availability

2

5304527988 Frigidaire Liner Backorder WCI 5304527988 $19.40

2

WCI 5303935233 WCI 5303935233 Contact Us For Availability

2A

5303935308 Frigidaire Oven Valve Backorder WCI 5303935308 $55.47

2B

5303935307 Frigidaire Oven Valve In Stock WCI 5303935307 $70.98

2C

5303935305 Frigidaire Oven Valve Backorder WCI 5303935305 $60.47

2D

5303935309 Frigidaire Top Burner Valve Backorder WCI 5303935309 $64.37

3

316580614 Frigidaire Oven Wiring Harness In Stock WCI 316580614 $75.98

4

316452723 Frigidaire Oven Glass Backorder WCI 316452723 $175.82

5

316272900 Frigidaire Oven Leg Levelling Plast In Stock WCI 316272900 $10.53

5A

5304509869 Frigidaire Oven Leveling Leg Assem In Stock WCI 5304509869 $4.41

6

316402316 Frigidaire Shield Backorder WCI 316402316 $64.89

6

316496201 Frigidaire Oven Rack In Stock WCI 316496201 $73.67

6C

WCI 316425600 WCI 316425600 Contact Us For Availability

6D

WCI 316419400 WCI 316419400 Contact Us For Availability

7

316403900 Frigidaire Insulation Backorder WCI 316403900 $56.58

7

316407402 Frigidaire Range Drawer Glide In Stock WCI 316407402 $7.20

7

316546300 Frigidaire Coupler Link Arm In Stock WCI 316546300 $16.62

8

316400603 Frigidaire Oven Stove Bottom Panel Backorder WCI 316400603 $136.43

8

5304503232 Frigidaire Oven Inner Door Glass In Stock WCI 5304503232 $91.51

9

WCI 316081900 WCI 316081900 Contact Us For Availability

9

WCI 316423811 WCI 316423811 Contact Us For Availability

10

316438400 Frigidaire Range Sealed Burner, 16/ In Stock WCI 316438400 $60.63

10

Screw,handle mtg. ,10-24 x 1.75`` ,(2) WCI 316439500 Contact Us For Availability

10

Insert,broiler panOPTIONAL ACCESS0RY WCI 316082000 Contact Us For Availability

10A

316438200 Frigidaire Range Sealed Burner, 5K In Stock WCI 316438200 $44.37

10B

316008401 Frigidaire Washer P-1 In Stock WCI 316008401 $8.85

10B

316438600 Frigidaire Range Sealed Burner, 14K Backorder WCI 316438600 $62.12

10C

316558300 Frigidaire Oven 9.5L Sealed Burner In Stock WCI 316558300 $41.02

10D

WCI 316532001 WCI 316532001 Contact Us For Availability

11

316536622 Frigidaire Igniter Orifice Assembly In Stock WCI 316536622 $138.62

11A

316536610 Frigidaire Igniter Assembly/Orifice In Stock WCI 316536610 $72.11

11B

316536618 Frigidaire Igniter/Orifice Assembly Backorder WCI 316536618 $127.55

11C

316536602 Frigidaire Oven Igniter/Orifice Ass In Stock WCI 316536602 $97.06

11D

316532601 Frigidaire Igniter/Orifice Assembly Backorder WCI 316532601 $90.40

12

316445500 Frigidaire Oven Switch Backorder WCI 316445500 $47.16

12

316540900 Frigidaire Oven Screw In Stock WCI 316540900 $11.07

12

5304498835 Frigidaire Oven Seal In Stock WCI 5304498835 $78.74

13

WCI 316545700 WCI 316545700 Contact Us For Availability

14

316116400 Frigidaire Oven Light Socket In Stock WCI 316116400 $46.03

14

5304521339 Frigidaire Regulator In Stock WCI 5304521339 $72.10

15

316091600 Frigidaire Oven Bracket Backorder WCI 316091600 $53.82

15

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $14.94

15

316546710 Frigidaire Oven Cap Backorder WCI 316546710 $80.66

15A

WCI 316546703 WCI 316546703 Contact Us For Availability

5304507348 Frigidaire Oven Tube Backorder WCI 5304507348 $34.39

5304524341 Frigidaire Lens In Stock WCI 5304524341 $9.98

WCI 316117501 WCI 316117501 Contact Us For Availability

WCI 316469653 WCI 316469653 Contact Us For Availability

17

316087500 Frigidaire Oven Retainer Backorder WCI 316087500 $44.37

17

316404901 Frigidaire Oven Valve In Stock WCI 316404901 $284.43

17

5304504811 Frigidaire Glass Spacer In Stock WCI 5304504811 $18.29

18

316404400 Frigidaire Oven Burner In Stock WCI 316404400 $81.53

18

316405800 Frigidaire Assembly Latch Backorder WCI 316405800 $47.16

18

WCI 316547900 WCI 316547900 Contact Us For Availability

19

316572406 Frigidaire Control Panel Backorder WCI 316572406 $199.14

19

5304506545 Frigidaire Gas Oven Range Igniter In Stock WCI 5304506545 $88.16

316499502 Frigidaire Oven Grate In Stock WCI 316499502 $213.56

5304519024 Frigidaire Oven Baffle Backorder WCI 5304519024 $58.77

WCI 316560106 WCI 316560106 Contact Us For Availability

WCI 316408600 WCI 316408600 Contact Us For Availability

20A

316419821 Frigidaire Oven Overlay In Stock WCI 316419821 $27.17

20A

316551802 Frigidaire Oven Grate Backorder WCI 316551802 $240.28

21

316408000 Frigidaire Oven Clip Assembly Backorder WCI 316408000 $13.29

21

316546605 Frigidaire Oven Cap Backorder WCI 316546605 $51.57

21

5303013272 Frigidaire Oven Nut Backorder WCI 5303013272 $13.83

22

5304507768 Frigidaire Oven Tube Backorder WCI 5304507768 $36.61

22

5304508468 Frigidaire Oven Cap Assembly In Stock WCI 5304508468 $34.93

22A

5304508443 Frigidaire Oven Surface Burner Cap In Stock WCI 5304508443 $32.71

22B

5304508441 Frigidaire Oven Surface Burner Cap In Stock WCI 5304508441 $24.95

22C

5304508442 Frigidaire Oven Surface Burner Cap In Stock WCI 5304508442 $26.08

22D

WCI 316532103 WCI 316532103 Contact Us For Availability

23

316404304 Frigidaire Oven Burner Backorder WCI 316404304 $66.02

23

316575906 Frigidaire Oven Hinge Backorder WCI 316575906 $68.21

24

5304516894 Frigidaire Oven Elbow Assembly Backorder WCI 5304516894 $63.78

25

316406200 Frigidaire Oven Shield Assembly Backorder WCI 316406200 $64.34

25

WCI 316401301 WCI 316401301 Contact Us For Availability

26

316489403 Frigidaire Range Bake Igniter In Stock WCI 316489403 $107.45

26A

316498200 Frigidaire Oven Bracket Backorder WCI 316498200 $38.24

29

807047102 Frigidaire Oven Front Drawer Glide In Stock WCI 807047102 $8.85

33

316402500 Frigidaire Oven Shield Backorder WCI 316402500 $94.27

34

WCI 316499900 WCI 316499900 Contact Us For Availability

35

316542102 Frigidaire Flue Gasket Backorder WCI 316542102 $8.85

36

316564509 Frigidaire Oven Knob In Stock WCI 316564509 $96.49

36A

WCI 316564506 WCI 316564506 Contact Us For Availability

37

316240600 Frigidaire Igniter Mounting Screw In Stock WCI 316240600 $8.85

37

316490000 Frigidaire Oven Range Temperature S In Stock WCI 316490000 $44.90

42

316416204 Frigidaire Oven Trim Backorder WCI 316416204 $32.17

43

316282700 Frigidaire Oven Screw Backorder WCI 316282700 $7.74

44

316517600 Frigidaire Oven Spacer Backorder WCI 316517600 $9.42

44

316527509 Frigidaire Oven 18.2K Burner Orific Backorder WCI 316527509 $15.49

44A

316527504 Frigidaire Oven Orifice Assembly In Stock WCI 316527504 $17.73

44B

316527513 Frigidaire Oven Orifice In Stock WCI 316527513 $16.07

44C

316527500 Frigidaire Oven Burner Orifice Asse In Stock WCI 316527500 $16.62

44D

316237902 Frigidaire Orifice Top Burner In Stock WCI 316237902 $47.68

47

GRLP3 Frigidaire Oven LP Conversion Kit In Stock WCI GRLP3 $33.28

55

316408300 Frigidaire Oven Bracket Backorder WCI 316408300 $15.51

58A

316403700 Frigidaire Insulation Backorder WCI 316403700 $237.95

58B

WCI 316403600 WCI 316403600 Contact Us For Availability

58G

08067973 Frigidaire 0 Insulation Backorder WCI 08067973 $40.48

82

316400801 Frigidaire Oven Shield Backorder WCI 316400801 $120.35

86

316441300 Frigidaire Receptacle Backorder WCI 316441300 $17.18

88

316099500 Frigidaire Oven Pin Backorder WCI 316099500 $4.49

88

316232702 Frigidaire Rod Backorder WCI 316232702 $9.40

106

316404100 Frigidaire Oven Bracket Backorder WCI 316404100 $46.59

107

316026701 Frigidaire Oven Cover Assembly Backorder WCI 316026701 $305.62

108

316256900 Frigidaire Oven Fan Motor In Stock WCI 316256900 $136.99

109

318398302 Frigidaire Stove Oven Range Convect In Stock WCI 318398302 $18.84

111

316136600 Frigidaire Oven Range Lock Nut Backorder WCI 316136600 $14.94

161

316211603 Frigidaire Oven Element Backorder WCI 316211603 $200.23

241853202 Frigidaire Refrigerator Screw Backorder WCI 241853202 $7.74

316001017 Frigidaire Screw Backorder WCI 316001017 $2.24

316021104 Frigidaire Oven Screw Assembly Backorder WCI 316021104 $6.09

316021105 Frigidaire Oven Screw Backorder WCI 316021105 $8.85

316021109 Frigidaire Oven Screw In Stock WCI 316021109 $11.09

316089500 Frigidaire Oven Screw In Stock WCI 316089500 $9.31

316215600 Frigidaire Oven Screw Backorder WCI 316215600 $9.79

316401500 Frigidaire Oven Cover Backorder WCI 316401500 $9.40

316418900 Frigidaire Oven Screw In Stock WCI 316418900 $11.09

316418901 Frigidaire Oven Screw Backorder WCI 316418901 $11.09

5303285179 Frigidaire Oven Door Screw Backorder WCI 5303285179 $10.53

5304494425 Frigidaire Oven Harness Backorder WCI 5304494425 $63.21

Screw,cup pt ,8-18 x 0.375 ,chrome WCI 316021108 Contact Us For Availability
