Model Electrolux BGGF3042KFV GAS RANGE – Common Parts &amp; Diagrams

1

316408706 Frigidaire Oven Drawer Assembly In Stock WCI 316408706 $78.49

1

SHIELD, REAR WALL WCI 316557600 Contact Us For Availability

2

316560900 Frigidaire Range Valve Backorder WCI 316560900 $64.89

2

5304527988 Frigidaire Liner Backorder WCI 5304527988 $19.40

2A

5303935308 Frigidaire Range Valve Backorder WCI 5303935308 $55.47

2B

5303935306 Frigidaire Range Valve Backorder WCI 5303935306 $63.23

2C

5303935305 Frigidaire Range Valve Backorder WCI 5303935305 $57.53

2D

5303935309 Frigidaire Top Burner Valve In Stock WCI 5303935309 $64.37

3

316580615 Frigidaire Range Spark Ignition Swi In Stock WCI 316580615 $72.57

4

316452722 Frigidaire Range Glass In Stock WCI 316452722 $209.17

4

5304494412 Frigidaire Range Panel In Stock WCI 5304494412 $72.04

5

316272900 Frigidaire Oven Leg Levelling Plast In Stock WCI 316272900 $10.53

5A

5304509869 Frigidaire Oven Leveling Leg Assem In Stock WCI 5304509869 $12.28

6

316402316 Frigidaire Shield Backorder WCI 316402316 $64.89

6

316496201 Frigidaire Oven Rack In Stock WCI 316496201 $73.67

6B

316496205 Frigidaire Oven Rack In Stock WCI 316496205 $105.39

7

316403900 Frigidaire Insulation Backorder WCI 316403900 $56.58

7

316407402 Frigidaire Range Drawer Glide In Stock WCI 316407402 $14.94

7

316546300 Frigidaire Coupler Link Arm In Stock WCI 316546300 $15.05

8

316400603 Frigidaire Range Stove Bottom Panel In Stock WCI 316400603 $123.60

8

5304503232 Frigidaire Oven Inner Door Glass In Stock WCI 5304503232 $82.90

8

5304508269 Frigidaire Oven Range Spark Module In Stock WCI 5304508269 $76.06

9

PAN, BROILEROPTIONAL ACCESS0RY WCI 316081900 Contact Us For Availability

9

LINER, OVEN DOOR WCI 316423811 Contact Us For Availability

10

316438400 Frigidaire Range Sealed Burner, 16/ In Stock WCI 316438400 $60.63

10

SCREW, HANDLE MTG., 10-24 X 1.75", (2) WCI 316439500 Contact Us For Availability

10

INSERT, BROILER PANOPTIONAL ACCESS0RY WCI 316082000 Contact Us For Availability

10A

316438200 Frigidaire Range Sealed Burner, 5K In Stock WCI 316438200 $52.81

10B

316008401 Frigidaire Washer P-1 In Stock WCI 316008401 $8.85

10B

316438600 Frigidaire Range Sealed Burner, 14K Backorder WCI 316438600 $62.44

10C

316558300 Frigidaire Oven 9.5L Sealed Burner In Stock WCI 316558300 $49.04

10D

316559300 Frigidaire Range Burner Backorder WCI 316559300 $125.63

11

316536622 Frigidaire Igniter Orifice Assembly In Stock WCI 316536622 $126.20

11A

316536610 Frigidaire Igniter Assembly/Orifice In Stock WCI 316536610 $72.29

11B

316536616 Frigidaire Igniter/Orifice Assembly Backorder WCI 316536616 $110.72

11C

316536602 Frigidaire Range Igniter/Orifice As In Stock WCI 316536602 $88.11

11D

316536623 Frigidaire Igniter/Orifice Assembly In Stock WCI 316536623 $104.73

12

316445500 Frigidaire Oven Switch Backorder WCI 316445500 $47.16

12

316540900 Frigidaire Oven Screw In Stock WCI 316540900 $21.77

12

5304498835 Frigidaire Range Seal In Stock WCI 5304498835 $74.15

13

316489101 Frigidaire Suppl Tube-Manifold Backorder WCI 316489101 $79.87

13

316604011 Frigidaire Panel Backorder WCI 316604011 $115.24

14

316091711 Frigidaire Regulator Assembly In Stock WCI 316091711 $73.10

14

316116400 Frigidaire Oven Light Socket In Stock WCI 316116400 $49.48

14

316572700 Frigidaire Range Nameplate In Stock WCI 316572700 $63.78

15

316091600 Frigidaire Oven Bracket Backorder WCI 316091600 $53.82

15

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $22.72

15

CAP, BACKGUARD, BLACK, RH END WCI 316546702 Contact Us For Availability

15A

CAP, BACKGUARD, BLACK, LH END WCI 316546703 Contact Us For Availability

16

5304507348 Frigidaire Range Tube Backorder WCI 5304507348 $34.39

16

5304524341 Frigidaire Lens In Stock WCI 5304524341 $20.29

16

MAINTOP PANEL, (BLACK) WCI 316469653 Contact Us For Availability

17

316031501 Frigidaire Range Valve In Stock WCI 316031501 $210.02

17

316087500 Frigidaire Oven Retainer Backorder WCI 316087500 $44.37

17

5304504811 Frigidaire Glass Spacer In Stock WCI 5304504811 $18.29

18

316404400 Frigidaire Range Burner Backorder WCI 316404400 $85.94

18

316405800 Frigidaire Assembly Latch Backorder WCI 316405800 $47.16

18

LINK, DOOR, (2), AUTO RACK WCI 316547900 Contact Us For Availability

19

316572406 Frigidaire Control Panel Backorder WCI 316572406 $202.13

19

5304506545 Frigidaire Gas Oven Range Igniter In Stock WCI 5304506545 $89.47

316284100 Frigidaire Range Spacer Assembly In Stock WCI 316284100 $20.82

316499502 Frigidaire Range Grate In Stock WCI 316499502 $213.56

5304509231 Frigidaire Range Clock In Stock WCI 5304509231 $128.82

5304519024 Frigidaire Range Baffle In Stock WCI 5304519024 $58.77

20A

316419353 Frigidaire Oven Overlay In Stock WCI 316419353 $27.17

20A

316551802 Frigidaire Range Grate Backorder WCI 316551802 $240.28

21

Backorder WCI 154079601 $0.34

21

316408000 Frigidaire Oven Clip Assembly Backorder WCI 316408000 $13.29

21

316546605 Frigidaire Range Cap In Stock WCI 316546605 $52.34

22

316286300 Frigidaire Bodyside Bracket Backorder WCI 316286300 $13.86

22

5304507768 Frigidaire Range Tube Backorder WCI 5304507768 $36.61

22

5304508468 Frigidaire Oven Cap Assembly In Stock WCI 5304508468 $43.59

22A

5304508441 Frigidaire Oven Surface Burner Cap In Stock WCI 5304508441 $36.00

22B

5304508443 Frigidaire Oven Surface Burner Cap In Stock WCI 5304508443 $47.39

22C

5304508442 Frigidaire Oven Surface Burner Cap In Stock WCI 5304508442 $32.21

22D

316559604 Frigidaire Range Cap In Stock WCI 316559604 $56.55

23

316404302 Frigidaire Range Burner Backorder WCI 316404302 $81.50

23

316575906 Frigidaire Range Hinge Backorder WCI 316575906 $68.21

24

5304516894 Frigidaire Range Elbow Assembly Backorder WCI 5304516894 $63.78

25

316406200 Frigidaire Oven Shield Assembly Backorder WCI 316406200 $64.34

25

5304497666 Frigidaire Range Baffle Backorder WCI 5304497666 $68.76

26

316489403 Frigidaire Range Bake Igniter In Stock WCI 316489403 $107.45

26A

316498200 Frigidaire Oven Bracket Backorder WCI 316498200 $38.24

29

807047102 Frigidaire Oven Front Drawer Glide In Stock WCI 807047102 $17.45

33

316402500 Frigidaire Range Shield Backorder WCI 316402500 $94.27

34

WCI 316499900 WCI 316499900 Contact Us For Availability

35

316542102 Frigidaire Flue Gasket Backorder WCI 316542102 $8.85

36

316564509 Frigidaire Range Knob In Stock WCI 316564509 $96.49

37

316240600 Frigidaire Igniter Mounting Screw In Stock WCI 316240600 $16.62

37

316490000 Frigidaire Oven Range Temperature S In Stock WCI 316490000 $49.04

39

316554010 Frigidaire Stainless Steel Handle In Stock WCI 316554010 $129.25

39

5304534377 Frigidaire Cord Backorder WCI 5304534377 $19.63

40

WCI 316249087 WCI 316249087 Contact Us For Availability

42

316416204 Frigidaire Range Trim Backorder WCI 316416204 $32.17

43

316282700 Frigidaire Oven Screw Backorder WCI 316282700 $7.74

44

316517600 Frigidaire Oven Spacer Backorder WCI 316517600 $9.42

44

316527509 Frigidaire Oven 18.2K Burner Orific Backorder WCI 316527509 $15.49

44A

316527504 Frigidaire Oven Orifice Assembly In Stock WCI 316527504 $17.73

44B

316527511 Frigidaire Oven Orifice Backorder WCI 316527511 $15.49

44C

316527500 Frigidaire Oven Burner Orifice Asse In Stock WCI 316527500 $28.41

47

GRLP4 Frigidaire Oven LP Conversion Kit In Stock WCI GRLP4 $52.47

55

316408300 Frigidaire Range Bracket Backorder WCI 316408300 $15.51

56

316230708 Frigidaire Range Shield Backorder WCI 316230708 $48.25

58A

316403700 Frigidaire Insulation Backorder WCI 316403700 $237.95

58B

INSULATION, OVEN BACK WCI 316403600 Contact Us For Availability

58G

08067973 Frigidaire 0 Insulation Backorder WCI 08067973 $40.48

82

316400801 Frigidaire Range Shield Backorder WCI 316400801 $120.35

86

316441300 Frigidaire Receptacle In Stock WCI 316441300 $17.18

88

316232702 Frigidaire Rod Backorder WCI 316232702 $9.40

89

5304528973 Frigidaire Motor In Stock WCI 5304528973 $48.09

106

316404100 Frigidaire Oven Bracket Backorder WCI 316404100 $46.59

107

316026701 Frigidaire Oven Cover Assembly Backorder WCI 316026701 $290.34

108

316256900 Frigidaire Range Fan Motor In Stock WCI 316256900 $135.58

109

318398302 Frigidaire Stove Oven Range Convect In Stock WCI 318398302 $32.21

111

316136600 Frigidaire Oven Range Lock Nut Backorder WCI 316136600 $14.94

241853202 Frigidaire Refrigerator Screw Backorder WCI 241853202 $7.74

316001017 Frigidaire Screw Backorder WCI 316001017 $2.24

316021105 Frigidaire Oven Screw Backorder WCI 316021105 $8.85

316021109 Frigidaire Oven Screw In Stock WCI 316021109 $15.49

316089500 Frigidaire Oven Screw In Stock WCI 316089500 $10.53

316215600 Frigidaire Oven Screw In Stock WCI 316215600 $11.07

316418901 Frigidaire Oven Screw Backorder WCI 316418901 $11.09

5304494425 Frigidaire Range Harness Backorder WCI 5304494425 $63.21

SCREW, CUP PT, 8-18 X 0.375, CHROME WCI 316021108 Contact Us For Availability

WCI 316580330 WCI 316580330 Contact Us For Availability

NIA

316021104 Frigidaire Oven Screw Assembly Backorder WCI 316021104 $6.09

NIA

316401500 Frigidaire Range Cover Backorder WCI 316401500 $9.40

NIA

316418900 Frigidaire Oven Screw Backorder WCI 316418900 $11.09
