Common parts from model LG BD-101
135313
GRILLE,INLET LGE 3530A20020A Contact Us For Availability
147582-1
LOUVER,VERTICAL LGE 4758A20009A Contact Us For Availability
147582-2
LOUVER,VERTICAL LGE 4758A20009B Contact Us For Availability
147900
BARRIER,SINGLE LGE 4790A20024B Contact Us For Availability
152302
FILTER(MECH),A/C LGE 5230A20007A Contact Us For Availability
237200
PANEL,CONTROL LGE 3720A10128A Contact Us For Availability
238310
ESCUTCHEON LGE 3831A10044A Contact Us For Availability
249950
CONTROL BOX ASSEMBLY,SINGLE LGE 4995A10089M Contact Us For Availability
263230
THERMISTOR ASSEMBLY LGE 6323A20004E Contact Us For Availability
264110
POWER CORD ASSEMBLY LGE 6411A20028C Contact Us For Availability
267110
REMOTE CONTROLLER ASSEMBLY LGE 6711A20093A Contact Us For Availability
268712
PWB(PCB) ASSEMBLY,MAIN(AC) LGE 6871A20343C Contact Us For Availability
330720
SCROLL LGE 3072A20003B Contact Us For Availability
346811
MOTOR ASSEMBLY,SINGLE LGE 4681A20044F Contact Us For Availability
349001
DAMPER,VENTILATION LGE 4900A20001A Contact Us For Availability
352113
TUBE ASSEMBLY,DISCHARGE SINGLE LGE 5211A30588E Contact Us For Availability
352115
TUBE ASSEMBLY,EVAPORATOR IN LGE 5211A20289D Contact Us For Availability
352380
AIR GUIDE LGE 5238A20005A Contact Us For Availability
352390
AIR GUIDE ASSEMBLY LGE 5239A10002E Contact Us For Availability
354210
EVAPORATOR ASSEMBLY,FIRST LGE 5421A20071E Contact Us For Availability
435301
GRILLE,REAR LGE 3530A30002A Contact Us For Availability
552111
TUBE ASSEMBLY,CAPILLARY LGE 5211A20214L Contact Us For Availability
554031
CONDENSER ASSEMBLY,BENT LGE 5403A20040M Contact Us For Availability
554160
COMPRESSOR SET LGE 2520UKCC2CA Contact Us For Availability
559010
FAN "WC" CHASSIS LW-C1211/1011 LGE 5900AR1173A Contact Us For Availability
× ![]()
