General Electric AZ85E12DACW1 Parts List

1001

WJ82X10031 GE Air Conditioner Bottom Angle As Out of Stock GEN WJ82X10031 $229.13

View on Model

1004

DUCT INSULATOR Out of Stock GEN WJ45X10017 $97.97

View on Model

1005

DUCT INSULATOR Out of Stock GEN WJ45X10018 $434.75

View on Model

1006

WP01X10040 GE Air Conditioner Adjuster Out of Stock GEN WP01X10040 $7.54

View on Model

1010

WIRE HOLDER Out of Stock GEN WJ03X10007 $7.30

View on Model

1013

WJ89X10058 GE Air Conditioner Drain Tray Out of Stock GEN WJ89X10058 $16.46

View on Model

1027

MOTOR ANGLE Out of Stock GEN WP65X10017 $38.76

View on Model

1028

WJ73X10060 GE Air Conditioner Propeller Fan Out of Stock GEN WJ73X10060 $68.58

View on Model

1032

DAMPER LEVER Out of Stock GEN WJ14X10031 $6.64

View on Model

1035

WIRE HOLDER Out of Stock GEN WJ03X10033 $6.64

View on Model

1041

SPACER Out of Stock GEN WJ01X10043 $7.97

View on Model

1042

SPACER Out of Stock GEN WP01X10010 $6.64

View on Model

1043

SPACER Out of Stock GEN WJ01X10155 $6.64

View on Model

1044

DIVIDER L ASM Out of Stock GEN WP82X10315 $75.56

View on Model

1045

DIVIDER R ASM Out of Stock GEN WP81X10001 $67.20

View on Model

1046

DAMPER ASM Out of Stock GEN WP14X10040 $56.55

View on Model

1047

DAMPER FRAME Out of Stock GEN WJ70X10036 $12.48

View on Model

1049

ZONELINE MOTOR CUSHION Out of Stock GEN WP01X10027 $7.54

View on Model

1050

CLAMP Out of Stock GEN WJ01X10159 $67.97

View on Model

1051

WJ73X10059 GE Air Conditioner Centrifugal Fan Out of Stock GEN WJ73X10059 $148.31

View on Model

1051

WJ73X10067 GE Air Conditioner Blower Fan Out of Stock GEN WJ73X10067 $164.61

View on Model

1052

HOUSING COVER A Out of Stock GEN WJ79X10079 $22.83

View on Model

1053

HOUSING COVER B Out of Stock GEN WJ79X10075 $17.79

View on Model

1054

INSULATOR Out of Stock GEN WJ45X10024 $55.22

View on Model

1057

MOTOR RUBBER Out of Stock GEN WP01X10047 $16.46

View on Model

1058

FAN HOUSING Out of Stock GEN WJ76X10108 $123.19

View on Model

1059

FAN HOUSING B Out of Stock GEN WJ76X10109 $65.58

View on Model

1060

WJ76X10110 GE Air Conditioner Fan Housing C Out of Stock GEN WJ76X10110 $55.40

View on Model

1062

PROTECTOR SPRING Out of Stock GEN WJ02X10031 $6.64

View on Model

1063

TERMINAL COVER Out of Stock GEN WJ79X10204 $8.76

View on Model

1064

GASKET WASHER Out of Stock GEN WJ01X10288 $6.64

View on Model

1065

TERMINAL GASKET Out of Stock GEN WJ43X10061 $17.52

View on Model

1066

WJ01X10046 GE Air Conditioner Compressor Cush Out of Stock GEN WJ01X10046 $33.19

View on Model

1067

CORNER CAP Out of Stock GEN WJ01X10171 $6.64

View on Model

1068

FRONT PANEL Out of Stock GEN WJ71X10268 $103.01

View on Model

1069

WJ05X10029 GE Air Conditioner Filter Guide L Out of Stock GEN WJ05X10029 $22.83

View on Model

1070

WJ05X10030 GE Air Conditioner Filter Guide R Out of Stock GEN WJ05X10030 $22.83

View on Model

1071

BRACE Out of Stock GEN WP65X10016 $39.56

View on Model

1073

CORD HOLDER L Out of Stock GEN WP01X10009 $6.64

View on Model

1075

DRAIN COVER Out of Stock GEN WJ79X10076 $28.41

View on Model

1083

BULKHEAD INSULATOR Out of Stock GEN WJ40X10014 $10.09

View on Model

1084

BULKHEAD INSULATOR Out of Stock GEN WJ40X10015 $6.64

View on Model

1090

DRAIN TRAY Out of Stock GEN WJ70X10037 $28.67

View on Model

1091

DRAINING VALVE Out of Stock GEN WJ58X10043 $50.74

View on Model

1092

DAMPER WIRE Out of Stock GEN WJ37X10029 $7.54

View on Model

1094

PLATE ASS'Y Out of Stock GEN WJ11X10008 $32.92

View on Model

1095

TOP PLATE SEAL 2 Out of Stock GEN WJ11X10007 $43.53

View on Model

1096

TOP PLATE SEAL 1 Out of Stock GEN WJ60X10002 $6.64

View on Model

1101

HOUSING COVER Out of Stock GEN WJ79X10078 $22.30

View on Model

1105

FAN HOUSING SEAL C Out of Stock GEN WJ60X10006 $236.69

View on Model

1106

DUCT SEAL R Out of Stock GEN WJ60X10010 $42.37

View on Model

1107

DUCT SEAL L Out of Stock GEN WJ60X10009 $10.59

View on Model

2002

HEATER K Out of Stock GEN WJ70X10038 $585.16

View on Model

2003

WP28X10005 GE Air Conditioner Protector Out of Stock GEN WP28X10005 $43.78

View on Model

2004

WP28X10013 GE Air Conditioner Protector Heate In Stock GEN WP28X10013 $64.68

View on Model

2005

HEATER CONNECTOR Out of Stock GEN WJ37X10030 $92.93

View on Model

2007

MAIN CONTROL BOARD Out of Stock GEN WP29X10045 $163.65

View on Model

2007

WP29X10046 GE Air Conditioner Main Control Bo Out of Stock GEN WP29X10046 $142.18

View on Model

2008

WP29X10033 GE Air Conditioner Drive Board Ass Out of Stock GEN WP29X10033 $263.91

View on Model

2012

R-CAPA LEAD WIRE Out of Stock GEN WP37X10001 $7.17

View on Model

2014

LEAD WIRE Out of Stock GEN WP01X10049 $97.70

View on Model

2015

WJ20X10132 GE Air Conditioner Running Capacit Out of Stock GEN WJ20X10132 $29.21

View on Model

2015

RUNNING CAPACITOR Out of Stock GEN WP20X10033 $50.47

View on Model

2018

WP27X10068 GE Air Conditioner Transformer Out of Stock GEN WP27X10068 $94.52

View on Model

2019

WP94X10315 GE Air Conditioner Fan DC Motor Out of Stock GEN WP94X10315 $334.34

View on Model

2022

PROTECTOR Out of Stock GEN WP23X10033 $72.77

View on Model

2022

PROTECTOR Out of Stock GEN WP28X10016 $72.77

View on Model

2024

POWER SW Out of Stock GEN WP24X10001 $32.07

View on Model

2025

LEAD WIRE Out of Stock GEN WP01X10046 $20.44

View on Model

2091

WP23X10026 GE Air Conditioner Fuse Out of Stock GEN WP23X10026 $7.54

View on Model

2092

WP23X10032 GE Air Conditioner Fuse Out of Stock GEN WP23X10032 $24.53

View on Model

3004

EVAPORATOR ASM Out of Stock GEN WP87X10052 $266.83

View on Model

3004

EVAPORATOR ASM Out of Stock GEN WP87X10053 $315.02

View on Model

3005

WJ98X10265 GE Air Conditioner Compressor Out of Stock GEN WJ98X10265 $513.67

View on Model

4002

ADJUSTABLE NUT Out of Stock GEN WP01X10054 $6.90

View on Model

4003

ZONELINE STUD BOLT Out of Stock GEN WJ01X10031 $0.00

View on Model

4004

WJ01X10037 GE Air Conditioner Special Screw D Out of Stock GEN WJ01X10037 $11.68

View on Model

4005

WJ01X10041 GE Air Conditioner Special Nut Out of Stock GEN WJ01X10041 $7.54

View on Model

4006

SPECIAL SCREW W Out of Stock GEN WJ01X10056 $6.64

View on Model

4007

SPECIAL SCREW Out of Stock GEN WP01X10041 $7.17

View on Model

4009

SPECIAL NUT Out of Stock GEN WJ01X10286 $6.64

View on Model

4010

SPECIAL SCREW Out of Stock GEN WP01X10052 $6.64

View on Model

4011

SCREW Out of Stock GEN WB01X10409 $6.64

View on Model

4013

SPECIAL SCREW Out of Stock GEN WP01X10053 $6.64

View on Model

Model AZ85E12DACW1 – Common Parts & Diagrams

Common parts from model AZ85E12DACW1
