  • Electrolux 970149720 Parts List

Model Electrolux 970149720 FREEZER CHEST – Common Parts & Diagrams

*
Insulation-door, fiberglass, (bulk)
Insulation-door, fiberglass, (bulk) WCI 5303917276 Contact Us For Availability
View on Model
*
Screw, PH, 8-32 x 1/2, wiring harness
Screw, PH, 8-32 x 1/2, wiring harness WCI 216707801 Contact Us For Availability
View on Model
1
Gasket-door, white
Gasket-door, white WCI 216481001 Contact Us For Availability
View on Model
1
Catch-lock, white
Catch-lock, white WCI 297014100 Contact Us For Availability
View on Model
1
Condenser
Condenser WCI 5300120781 Contact Us For Availability
View on Model
2
Adapter, drain hose
Adapter, drain hose WCI 216269500 Contact Us For Availability
View on Model
2
Lock Assy
Lock Assy WCI 297090200 Contact Us For Availability
View on Model
3
Plug, drain, interior
Plug, drain, interior WCI 216502600 Contact Us For Availability
View on Model
4
Plug, drain, exterior
Plug, drain, exterior WCI 297013600 Contact Us For Availability
View on Model
5
Harness-main
Harness-main WCI 297034300 Contact Us For Availability
View on Model
7
Breaker-lock side, white
Breaker-lock side, white WCI 216855705 Contact Us For Availability
View on Model
9
Panel-inner door, frzr
Panel-inner door, frzr WCI 216967500 Contact Us For Availability
View on Model
10
Plug button, 1/4", white
Plug button, 1/4", white WCI 216923001 Contact Us For Availability
View on Model
18
Handle, white
Handle, white WCI 216884802 Contact Us For Availability
View on Model
40
Fastener, .330 dia stud, handle, (2)
Fastener, .330 dia stud, handle, (2) WCI 216922700 Contact Us For Availability
View on Model
86
Screw, 8-18 X 1/2
Screw, 8-18 X 1/2 WCI 216707701 Contact Us For Availability
View on Model
