Model Electrolux 790.60002400 Gas Range (Kenmore 79060002400) – Common Parts & Diagrams

1
Range Broil Drawer Bottom Panel
Range Broil Drawer Bottom Panel WCI 316110201 Contact Us For Availability
View on Model
2
Range Surface Burner Valve
Range Surface Burner Valve WCI 5303935237 Contact Us For Availability
View on Model
2
Range Broil Drawer Liner
Range Broil Drawer Liner WCI 316236401 Contact Us For Availability
View on Model
4
Range Storage Drawer Front Panel
Range Storage Drawer Front Panel WCI 316231211 Contact Us For Availability
View on Model
5
Range Leveling Leg
Range Leveling Leg WCI 316129200 Contact Us For Availability
View on Model
5
Range Broil Drawer Handle Push-In Nut
Range Broil Drawer Handle Push-In Nut WCI 316129100 Contact Us For Availability
View on Model
7
Range Oven Door Insulation
Range Oven Door Insulation WCI 316236801 Contact Us For Availability
View on Model
9
Range Broil Pan
Range Broil Pan WCI 316081900 Contact Us For Availability
View on Model
10
Range Broil Pan Insert
Range Broil Pan Insert WCI 316082000 Contact Us For Availability
View on Model
13
Oven Panel
Oven Panel WCI 316202603 Contact Us For Availability
View on Model
13B
Broil Glide
Broil Glide WCI 316111501 Contact Us For Availability
View on Model
16
Range Main Top Assembly
Range Main Top Assembly WCI 316104301 Contact Us For Availability
View on Model
17
Range Main Top Support
Range Main Top Support WCI 316066900 Contact Us For Availability
View on Model
17
Safety Valve
Safety Valve WCI 5303280593 Contact Us For Availability
View on Model
18
Oven Burner
Oven Burner WCI 5303280585 Contact Us For Availability
View on Model
18A
Range Main Top Hinge
Range Main Top Hinge WCI 08067746 Contact Us For Availability
View on Model
25
Range Oven Vent Cover (Chrome)
Range Oven Vent Cover (Chrome) WCI 316104500 Contact Us For Availability
View on Model
32
Range Thermostat Knob
Range Thermostat Knob WCI 316102321 Contact Us For Availability
View on Model
34
Cover
Cover WCI 3018607 Contact Us For Availability
View on Model
36
Tubing/therm
Tubing/therm WCI 316060800 Contact Us For Availability
View on Model
39
Range Broil Drawer Handle (White)
Range Broil Drawer Handle (White) WCI 316019511 Contact Us For Availability
View on Model
39
Tubing-top P
Tubing-top P WCI 5303211133 Contact Us For Availability
View on Model
41
Range Oven Door Hinge Cover, Right
Range Oven Door Hinge Cover, Right WCI 316233400 Contact Us For Availability
View on Model
42
Range Oven Burner Pilot Assembly
Range Oven Burner Pilot Assembly WCI 5303280589 Contact Us For Availability
View on Model
43
Range Oven Burner Pilot Tube
Range Oven Burner Pilot Tube WCI 3203398 Contact Us For Availability
View on Model
49
Gibson Range Oven Door Handle End Cap
Gibson Range Oven Door Handle End Cap WCI 316137000 Contact Us For Availability
View on Model
58A
Range Oven Insulation
Range Oven Insulation WCI 3017142 Contact Us For Availability
View on Model
73
Range Broil Drawer Base
Range Broil Drawer Base WCI 316109902 Contact Us For Availability
View on Model
85
Range Broil Drawer Rack
Range Broil Drawer Rack WCI 316115600 Contact Us For Availability
View on Model
NI
Range Screw
Range Screw WCI 316021108 Contact Us For Availability
View on Model
NI
Range Oven Meat Probe Hole Plug
Range Oven Meat Probe Hole Plug WCI 316246400 Contact Us For Availability
View on Model
NI
Range Screw
Range Screw WCI 5303280311 Contact Us For Availability
View on Model
