Model Electrolux 790.42549311 Electric Range (Kenmore 79042549311) – Common Parts &amp; Diagrams

2

Range Warming Drawer Front Panel Liner (Black WCI 318303907 Contact Us For Availability

3

139023301 Frigidaire Oven Trim Backorder WCI 139023301 $37.79

3A

139014401 Frigidaire Oven Trim Backorder WCI 139014401 $22.56

4

Range Oven Door Outer Panel (Black) WCI 808950014 Contact Us For Availability

4

Frigidaire Range Oven Door Outer Panel (White WCI 808950013 Contact Us For Availability

5

Range Leveling Leg WCI 318175503 Contact Us For Availability

6

Range Oven Rack WCI 139011600 Contact Us For Availability

7

318297303 Frigidaire Oven Box In Stock WCI 318297303 $87.09

7

318372017 Frigidaire Insulation Backorder WCI 318372017 $12.06

7A

318372016 Frigidaire Insulation Backorder WCI 318372016 $13.11

8

318359500 Frigidaire Oven Panel Backorder WCI 318359500 $96.97

8

5304503232 Frigidaire Oven Inner Door Glass In Stock WCI 5304503232 $68.80

8A

Range Bake Element Bracket WCI 318313601 Contact Us For Availability

9

139000405 Frigidaire Liner Backorder WCI 139000405 $79.79

9

318138801 Frigidaire Oven Pan Backorder WCI 318138801 $72.96

10

316082001 Frigidaire Oven Insert Backorder WCI 316082001 $36.74

10

5304507924 Frigidaire Oven Screw In Stock WCI 5304507924 $5.24

11

807545502 Frigidaire Oven Seal Backorder WCI 807545502 $103.94

12

316445501 Frigidaire Oven Switch In Stock WCI 316445501 $68.89

13

Range Warming Drawer Glide, Right WCI 318259509 Contact Us For Availability

13A

Range Warming Drawer Glide, Left WCI 318259508 Contact Us For Availability

15

318178110 Frigidaire Oven Range 6" Surface El In Stock WCI 318178110 $86.36

15

5304528790 Frigidaire Lamp Assembly Appliance Backorder WCI 5304528790 $15.74

15A

316282103 Frigidaire Range Element Backorder WCI 316282103 $200.47

15B

ELEMENT HEATING In Stock WCI 8583165300028 $66.15

15C

140273621015 Frigidaire Warmer Element, Radia Backorder WCI 140273621015 $26.48

316446401 Frigidaire Oven Glass In Stock WCI 316446401 $86.61

318296602 Frigidaire Oven Console Backorder WCI 318296602 $222.73

Range Main Top Assembly WCI 139033808 Contact Us For Availability

Range Control Panel WCI 318296600 Contact Us For Availability

19A

Range Control Panel Support WCI 318289715 Contact Us For Availability

25

139075001 Frigidaire Range Cover Backorder WCI 139075001 $41.88

29

139023400 Frigidaire Oven Spacer Backorder WCI 139023400 $14.16

29

316517600 Frigidaire Oven Spacer Backorder WCI 316517600 $8.91

29

318147430 Frigidaire Oven Bumper Backorder WCI 318147430 $13.11

35

Range Surface Burner Knob Support WCI 318183105 Contact Us For Availability

36

5304494686 Frigidaire Range Knob In Stock WCI 5304494686 $23.09

36

Range Surface Element Knob (Black) WCI 5304494687 Contact Us For Availability

37

5304504897 Frigidaire Oven Temperature Sensor In Stock WCI 5304504897 $31.39

39

Range Oven Door Handle WCI 318372416 Contact Us For Availability

39

Range Oven Door Handle WCI 318372417 Contact Us For Availability

40

318242702 Frigidaire Oven Bracket Assembly Backorder WCI 318242702 $13.64

41

318370602 Frigidaire Oven Bracket Backorder WCI 318370602 $9.44

42

318382302 Frigidaire Bracket Backorder WCI 318382302 $35.16

46

Range Indicator Light Lens WCI 318228301 Contact Us For Availability

51

318044831 Frigidaire Oven Light Backorder WCI 318044831 $11.54

52

318122006 Frigidaire Small Element Mounting S Backorder WCI 318122006 $49.05

52A

318122011 Frigidaire Oven Spring Backorder WCI 318122011 $42.99

52B

318122010 Frigidaire Oven Spring Assembly Backorder WCI 318122010 $46.29

54

318293830 Frigidaire Oven Switch In Stock WCI 318293830 $65.98

54A

318191023 Frigidaire Oven Switch In Stock WCI 318191023 $45.28

54B

Range Turbo Boil Surface Element Control Swit WCI 316305101 Contact Us For Availability

55

318402901 Frigidaire Oven Bushing Backorder WCI 318402901 $13.11

57

316283600 Frigidaire Range Cover In Stock WCI 316283600 $8.39

59

139027600 Frigidaire Oven Duct Backorder WCI 139027600 $63.51

64

318165800 Frigidaire Oven Door Glass Spacer w Backorder WCI 318165800 $13.11

66

5304521498 Frigidaire Element Backorder WCI 5304521498 $62.09

67

5304521880 Frigidaire Element Backorder WCI 5304521880 $79.79

70

139000601 Frigidaire Oven Shield Backorder WCI 139000601 $49.86

81

318255301 Frigidaire Oven Element Backorder WCI 318255301 $72.96

84

318005108 Frigidaire Appliance Thermostat Backorder WCI 318005108 $56.16

85

807328301 Frigidaire Oven Rack Backorder WCI 807328301 $60.36

86

318561100 Frigidaire Receptacle Backorder WCI 318561100 $14.69

88

5304506964 Frigidaire Oven Cover Backorder WCI 5304506964 $17.84

89

5304528836 Frigidaire Motor Backorder WCI 5304528836 $55.42

90

Range Glass Edge Protector WCI 318368001 Contact Us For Availability

90

Range Side Filler Panel, Right (Black) WCI 318296904 Contact Us For Availability

90

Panel Filler, Right WCI 318296902 Contact Us For Availability

90A

5304511890 Frigidaire Oven Panel Backorder WCI 5304511890 $56.16

90A

Range Panel WCI 318296903 Contact Us For Availability

91

903113-9010 Frigidaire Filler Kit Assembly Backorder WCI 903113-9010 $48.81

91

Crosley Range Main Top Filler Trim, Rear WCI 318304301 Contact Us For Availability

99A

318313231 Frigidaire Oven Gasket Backorder WCI 318313231 $56.69

107

139013903 Frigidaire Oven Vent Hood Cover Backorder WCI 139013903 $31.49

108

318575612 Frigidaire Oven Cooling Fan Motor In Stock WCI 318575612 $144.24

109

318398302 Frigidaire Stove Oven Range Convect In Stock WCI 318398302 $15.33

111

316136600 Frigidaire Oven Range Lock Nut Backorder WCI 316136600 $14.16

119

807144901 Frigidaire Thermostat Backorder WCI 807144901 $40.41

124

316105501 Frigidaire P-1 Glide Backorder WCI 316105501 $68.89

125

139008500 Frigidaire Oven Motor Backorder WCI 139008500 $151.97

127

139042600 Frigidaire Tube Assembly Backorder WCI 139042600 $32.01

131

139027700 Frigidaire Oven Duct Backorder WCI 139027700 $54.06

161

ELEMENT,CONVECTION,2500W -PUR Backorder WCI 8581390065036 $37.04

166

318298410 Frigidaire Oven Bracket Backorder WCI 318298410 $52.49

166

5304511884 Frigidaire Oven Bracket Assembly Backorder WCI 5304511884 $45.66

170

5304486410 Frigidaire Range Kit Backorder WCI 5304486410 $109.71

201

318298233 Frigidaire Oven Frame Backorder WCI 318298233 $33.59

272

139021700 Frigidaire Oven Tube Backorder WCI 139021700 $13.11

316001017 Frigidaire Screw Backorder WCI 316001017 $2.09

316021105 Frigidaire Oven Screw Backorder WCI 316021105 $8.38

316021109 Frigidaire Oven Screw In Stock WCI 316021109 $9.88

316205500 Frigidaire Oven Nut In Stock WCI 316205500 $8.39

316303501 Frigidaire Assembly Harness Backorder WCI 316303501 $62.88

316418900 Frigidaire Oven Screw Backorder WCI 316418900 $10.49

318264200 Frigidaire Oven Plate Backorder WCI 318264200 $16.26

318531701 Frigidaire Spacer Backorder WCI 318531701 $8.91

318946500 Frigidaire Oven Light Bulb Range/Wa Backorder WCI 318946500 $39.36

5303289910 Frigidaire Oven Screw Backorder WCI 5303289910 $4.19

5303300265 Frigidaire Oven Screw Backorder WCI 5303300265 $10.49

807633201 Frigidaire Range Harness Backorder WCI 807633201 $113.39

Appliance Cleaning Pad WCI 316459400 Contact Us For Availability
