Model LG 75144 – Common Parts &amp; Diagrams

130410

BASE ASSEMBLY,SINGLE LGE 3041A10046K Contact Us For Availability

130900

CABINET LGE 3090A20017D Contact Us For Availability

132100

FRAME LGE 3210A20075A Contact Us For Availability

135301

MDX62673201 LG Front Grille Backorder LGE MDX62673201 $42.17

135303

GRILLE,INLET LGE 3530A20095A Contact Us For Availability

135500

COVER,TERMINAL LGE 3550U-L006A Contact Us For Availability

145200

4520A20007A LG Link Backorder LGE 4520A20007A $3.64

147581

LOUVER,HORIZONTAL LGE 4758A20058A Contact Us For Availability

147582

4758A30045A LG Vertical Louver Backorder LGE 4758A30045A $3.64

147582

4758A30045B LG Vertical Louver Backorder LGE 4758A30045B $3.64

149980

4998A20003A LG Shroud Backorder LGE 4998A20003A $23.81

152302

5230A20041E LG Air Conditioner Filter In Stock LGE 5230A20041E $19.35

237200

PANEL,CONTROL LGE 3720A20251A Contact Us For Availability

238310

ESCUTCHEON LGE 3831A10037A Contact Us For Availability

249940

CONTROL BOX,SINGLE LGE 4994A20080A Contact Us For Availability

263230

6323A20004S LG THERMISTOR-NTC Backorder LGE 6323A20004S $8.52

264110

POWER CORD ASSEMBLY LGE 6411A20048J Contact Us For Availability

267110

REMOTE CONTROLLER ASSEMBLY LGE 6711A90028T Contact Us For Availability

268712

PWB(PCB) ASSEMBLY,DISPLAY LGE 6871A20448A Contact Us For Availability

268714

6871A01001B LG Main PCB Assembly Backorder LGE 6871A01001B $74.27

346811

4681A20041H LG Motor Backorder LGE 4681A20041H $255.17

349480

4948A20045A LG Orifice Backorder LGE 4948A20045A $28.39

349600

4960A20008A LG Motor Bracket Backorder LGE 4960A20008A $19.35

352113

TUBE ASSEMBLY,DISCHARGE SINGLE LGE 5211A21421B Contact Us For Availability

352380

AIR GUIDE LGE 5238A20033A Contact Us For Availability

354210

EVAPORATOR ASSEMBLY,FIRST LGE 5421A20071G Contact Us For Availability

359011

FAN "WC" CHASSIS LW-C1211/1011 LGE 5900AR1173A Contact Us For Availability

359012

5900A20009E LG Turbo Fan Backorder LGE 5900A20009E $37.13

3530A20033B LG Rear Grille Backorder LGE 3530A20033B $19.35

3530A20101A LG Rear Grille Backorder LGE 3530A20101A $23.81

GRILLE,REAR LGE 3530A30002A Contact Us For Availability

GRILLE,REAR LGE 3530A30015A Contact Us For Availability

550140

4H00982E LG Compressor Damper In Stock LGE 4H00982E $3.64

552113

TUBE ASSEMBLY,CONDENSER OUT LGE 5211A21809A Contact Us For Availability

554031

CONDENSER ASSEMBLY,BENT LGE 5403A20183H Contact Us For Availability

554160

COMPRESSOR SET,THAILAND LGE 2520UTBJ024 Contact Us For Availability

567502

6750U-L005A LG Overload Protector Backorder LGE 6750U-L005A $15.11

W0CZZ

CAPACITOR SH LGE 6120AR2194B Contact Us For Availability

W1NHA

1NHA0801206 LG Nut Common Backorder LGE 1NHA0801206 $3.64

W1NZZ

4H00947A LG Air Conditioner Common Nut Backorder LGE 4H00947A $3.64

W1WZZ

GASKET-NUT <GA-0711HCR/0712HCM LGE 4H01058A Contact Us For Availability

W4810

4810AR4155A LG Bracket Backorder LGE 4810AR4155A $3.64

W4986

4986U-L001G LG Gasket Backorder LGE 4986U-L001G $3.64

6631A10011K LG Single Harness Backorder LGE 6631A10011K $23.81

6631A30003A LG Multi Harness Backorder LGE 6631A30003A $5.63

6631A30012E LG Multi Harness Backorder LGE 6631A30012E $15.11

CONNECTOR ASSEMBLY LGE 6631A30027A Contact Us For Availability

W48602

3H02932B LG Air Conditioner Clamp Spring I.D. Backorder LGE 3H02932B $3.64
