Model LG 72056 – Common Parts & Diagrams

35211A
TUBE ASSY,SUCTION SINGLE
TUBE ASSY,SUCTION SINGLE LGE 5211A10062B Contact Us For Availability
View on Model
130410
Base Assembly,Single
Base Assembly,Single LGE 3041A20093A Contact Us For Availability
View on Model
130910
CABINET ASSY,SINGLE
CABINET ASSY,SINGLE LGE 3091A10020D Contact Us For Availability
View on Model
135312
GRILLE ASSY,FRONT
GRILLE ASSY,FRONT LGE 3531A20021A Contact Us For Availability
View on Model
145200
LINK HOLDER PP JI-350 LW-A0512
LINK HOLDER PP JI-350 LW-A0512 LGE 4520AR3191A Contact Us For Availability
View on Model
147581
VANE,HORIZONTAL
VANE,HORIZONTAL LGE 5990A20001A Contact Us For Availability
View on Model
147582B
VANE,VERTICAL
VANE,VERTICAL LGE 5990A30005D Contact Us For Availability
View on Model
148000
BRACE
BRACE LGE 4800A30003A Contact Us For Availability
View on Model
149980
SHROUD
SHROUD LGE 4998A10008A Contact Us For Availability
View on Model
237200
PANEL,CONTROL
PANEL,CONTROL LGE 3720A20017A Contact Us For Availability
View on Model
238310
ESCUTCHEON
ESCUTCHEON LGE 3831A10001A Contact Us For Availability
View on Model
249950
CONTROL BOX ASSY,SINGLE
CONTROL BOX ASSY,SINGLE LGE 4995A20127C Contact Us For Availability
View on Model
268711A
PWB(PCB) ASSEMBLY,DISPLAY
PWB(PCB) ASSEMBLY,DISPLAY LGE 6871A20193C Contact Us For Availability
View on Model
268711B
PWB(PCB) ASSEMBLY,MAIN(AC)
PWB(PCB) ASSEMBLY,MAIN(AC) LGE 6871A20188M Contact Us For Availability
View on Model
346811
MOTOR ASSEMBLY,SINGLE
MOTOR ASSEMBLY,SINGLE LGE 4681A10002P Contact Us For Availability
View on Model
349480
ORIFICE
ORIFICE LGE 4948A10007A Contact Us For Availability
View on Model
352380A
AIR GUIDE, UPPER
AIR GUIDE, UPPER LGE 5238A20004B Contact Us For Availability
View on Model
352380B
AIR GUIDE
AIR GUIDE LGE 5238A20003A Contact Us For Availability
View on Model
354210
EVAPORATOR ASSY,FIRST
EVAPORATOR ASSY,FIRST LGE 5421A20016G Contact Us For Availability
View on Model
359012
FAN,TURBO
FAN,TURBO LGE 5900A10005A Contact Us For Availability
View on Model
552111
TUBE ASSY,CAPILLARY
TUBE ASSY,CAPILLARY LGE 5211AR3332R Contact Us For Availability
View on Model
554030
CONDENSER ASSY,FIRST
CONDENSER ASSY,FIRST LGE 5403A20009E Contact Us For Availability
View on Model
554160
COMPRESSOR
COMPRESSOR LGE 5416A20014D Contact Us For Availability
View on Model
559010
FAN,PROPELLER
FAN,PROPELLER LGE 5900A20017A Contact Us For Availability
View on Model
567480
THERMISTOR ASSY
THERMISTOR ASSY LGE 6323A20003D Contact Us For Availability
View on Model
567502
O.L.P
O.L.P LGE 6750A30001U Contact Us For Availability
View on Model
731373
INSTALL PART ASSY,SINGLE
INSTALL PART ASSY,SINGLE LGE 3127A20016B Contact Us For Availability
View on Model
W0CZZB
CAPACITOR
CAPACITOR LGE 6120AR2359V Contact Us For Availability
View on Model
